Iseki TL4500
The Iseki TL4500 is a utility tractor designed for farmers who need a reliable machine for various tasks. This 2WD tractor has a powerful Isuzu C240 diesel engine with 4 cylinders and 44.4 horsepower. The engine is liquid-cooled and naturally aspirated, making it dependable for long workdays. It has an average displacement of 144.6 cubic inches and runs at a high speed of 2600 rpm. This tractor features a manual transmission with 18 forward gears and 6 reverse gears, giving operators plenty of options for different jobs. The TL4500 has power steering for easy handling and comes with agricultural tires for good traction in fields. It measures 134.5 inches long, 61 inches wide, and 87.4 inches tall, with an average operating weight of 3792 pounds. The tractor is equipped with a Category 3 rear hitch, making it compatible with many farm implements. It has an open operator station with a ROPS (Roll-Over Protective Structure) for safety. The rear tread can be adjusted from 48 to 63.8 inches, allowing for use in different row spacings.
Key specifications
- Category
- Utility
- Engine power
- 44hp
- Operating weight
- 3,792 lb
- Transmission
- Manual
Category comparison
TL4500 compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
44.4 hp · 38th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The TL4500 ranks at the 38th percentile for engine power among recorded utility tractors.
Overview
About the Iseki TL4500
The Iseki TL4500 is a utility tractor designed for farmers who need a reliable machine for various tasks. This 2WD tractor has a powerful Isuzu C240 diesel engine with 4 cylinders and 44.4 horsepower. The engine is liquid-cooled and naturally aspirated, making it dependable for long workdays. It has an average displacement of 144.6 cubic inches and runs at a high speed of 2600 rpm. This tractor features a manual transmission with 18 forward gears and 6 reverse gears, giving operators plenty of options for different jobs. The TL4500 has power steering for easy handling and comes with agricultural tires for good traction in fields. It measures 134.5 inches long, 61 inches wide, and 87.4 inches tall, with an average operating weight of 3792 pounds. The tractor is equipped with a Category 3 rear hitch, making it compatible with many farm implements. It has an open operator station with a ROPS (Roll-Over Protective Structure) for safety. The rear tread can be adjusted from 48 to 63.8 inches, allowing for use in different row spacings.
Full specifications
Recorded specifications
General
| Manufacturer | Iseki |
|---|---|
| Model | TL4500 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Operating weight | 3,792lb(1,720 kg) |
Engine
| Make | Isuzu |
|---|---|
| Model | C240 |
| Power | 44.4hp(33.11 kW) |
| Cylinders | 4 |
| Displacement | 144.6ci(2.37 L) |
| Bore | 3.39in(86.11 mm) |
| Stroke | 4.02in(102.1 mm) |
Transmission
| Type | Manual |
|---|---|
| Forward gears | 18 |
| Reverse gears | 6 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power |
| Cab | Open; ROPS |
Dimensions
| Length | 134.5in(3,416 mm) |
|---|---|
| Width | 61in(1,549 mm) |
| Height | 87.4in(2,220 mm) |
| Operating weight | 3,792lb(1,720 kg) |
Closest alternatives
TL4500 compared with the nearest models by horsepower
By engine horsepower, the nearest utility models to the TL4500 are the Fiat 45-66 and the Fiat 45-66S. The Fiat 45-66 matches it on rated power and weighs 460 lb more, so it carries more weight per horsepower, which helps traction in draft work. The Fiat 45-66S matches it on rated power and weighs 890 lb more, at 106 lb per horsepower against 85 lb. Of the 3 models, the TL4500 has the lowest weight per horsepower at 85 lb per hp.
| Spec | Iseki TL4500 | Fiat 45-66 | Fiat 45-66S |
|---|---|---|---|
| Engine power | 44.4 hp33.1 kW | 44.4 hp33.1 kW | 44.4 hp33.1 kW |
| Operating weight | 3,792 lb1,720 kg | 4,255 lb1,930 kg | 4,685 lb2,125 kg |
| Weight per hp | 85 lb/hp52 kg/kW | 96 lb/hp58 kg/kW | 106 lb/hp64 kg/kW |
| Displacement | 144.6 ci2.37 L | 165.4 ci2.71 L | 165.4 ci2.71 L |
| Cylinders | 4 | 3 | 3 |
| Transmission | Manual | Manual | Multiple (Gear, Shuttle, Creeper) |
| Drive | 2WD | 2WD | 2WD |
Calculators
Calculators for the TL4500
PTO power
About 37 to 40 PTO hp
Estimated from the 44.4 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 44.4 hp tractor can run
Maximum size is about a 5.5 ft rotary cutter or a 4.5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
99 lb per PTO hp as listed
Heavy draft work calls for 130 to 150 lb/hp. The calculator gives the ballast to add.
Units
44.4 hp is 33.1 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
TL4500 vs. Utility median
Iseki TL4500 compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 44.4 hp | 55 hp | -19% | 38th |
| Engine Displacement | 145 ci | 183 ci | -21% | 37th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 18 | 12 | +50% | 83rd |
| Operating Weight | 3,792 lb | 5,303 lb | -28% | 33rd |
| Length | 135 in | 137 in | -2% | 47th |
| Width | 61 in | 66 in | -8% | 39th |
| Height | 87.4 in | 94.1 in | -7% | 36th |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 3,933–5,720 models).
Same manufacturer
Other Iseki models
Other manufacturers
Models with similar horsepower
Gallery
Iseki TL4500 photos
FAQ
Frequently asked questions
How much horsepower does the Iseki TL4500 have?
The Iseki TL4500 produces 44.4 hp from its 4-cylinder engine. Engine displacement is 144.6 ci.
How much does the Iseki TL4500 weigh?
The Iseki TL4500 weighs about 3,792 lb in operating condition.
What transmission is in the Iseki TL4500?
Transmission on the Iseki TL4500 is Manual, with 18 forward speeds.
What hitch category is the Iseki TL4500?
The Iseki TL4500 uses a Category Category 3 hitch.
What maintenance does the Iseki TL4500 require?
The Iseki TL4500 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
