Sub-CompactPerformance profile
Kioti LK30
The Kioti LK30 is a compact but powerful tractor designed for various farm tasks. It features a 4-wheel drive system and hydrostatic power steering, making it easy to control in different conditions. The tractor has a synchronized shuttle transmission with 8 forward and 8 reverse gears, giving the operator plenty of options for different jobs. Under the hood, the LK30 boasts a Daedong 3A150LWB engine. This diesel engine has 3 cylinders and is liquid-cooled for better performance. It produces 30 horsepower at 2600 RPM, which is enough power for many farm tasks. The tractor measures 111.4 inches long, 51.4 inches wide, and 88.6 inches tall, with a weight of 2897 pounds. It comes equipped with a Category I rear hitch, making it compatible with various attachments. For safety, the LK30 features a ROPS (Roll-Over Protective Structure) operator station and starts easily with an electric starter.
ManufacturerKiotiPower30 hpEngine3-cylTransSynchronized shuttle
Quick specs
- Category
- Sub-Compact
- Engine Power Output
- 30hp
- Operating Weight
- 2,897 lb
- Transmission
- Synchronized shuttle
At a glance
How the LK30 compares
vs. Sub-Compact medianDistribution
Engine Power (hp)
Across all Sub-Compact tractors
30 hp · 57th
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The LK30 ranks at the 57th percentile for engine power among recorded sub-compact tractors.
Overview
About the Kioti LK30
The Kioti LK30 is a compact but powerful tractor designed for various farm tasks. It features a 4-wheel drive system and hydrostatic power steering, making it easy to control in different conditions. The tractor has a synchronized shuttle transmission with 8 forward and 8 reverse gears, giving the operator plenty of options for different jobs. Under the hood, the LK30 boasts a Daedong 3A150LWB engine. This diesel engine has 3 cylinders and is liquid-cooled for better performance. It produces 30 horsepower at 2600 RPM, which is enough power for many farm tasks. The tractor measures 111.4 inches long, 51.4 inches wide, and 88.6 inches tall, with a weight of 2897 pounds. It comes equipped with a Category I rear hitch, making it compatible with various attachments. For safety, the LK30 features a ROPS (Roll-Over Protective Structure) operator station and starts easily with an electric starter.
Full specifications
Every recorded spec
General
| Manufacturer | Kioti |
|---|---|
| Model | LK30 |
| Category | Sub-Compact tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 2,897lb |
Engine
| Make | Daedong |
|---|---|
| Model | 3A150LWB |
| Power | 30hp |
| Cylinders | 3 |
| Displacement | 91.5ci |
Transmission
| Type | Synchronized shuttle |
|---|---|
| Forward gears | 8 |
| Reverse gears | 8 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
| Cab | ROPS |
Dimensions
| Length | 111.4in |
|---|---|
| Width | 51.4in |
| Height | 88.6in |
| Operating weight | 2,897lb |
Tires
| Rear | 11.2-24 |
|---|
Head to head
LK30 vs. Sub-Compact median
How the Kioti LK30 compares to other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 30 hp | 26.9 hp | +12% | 57th |
| Engine Displacement | 91.5 ci | 91.4 ci | 0% | 51st |
| Cylinders | 3 | 3 | at median | 50th |
| Forward Gears | 8 | 9 | -11% | 40th |
| Operating Weight | 2,897 lb | 2,700 lb | +7% | 54th |
| Length | 111 in | 113 in | -2% | 47th |
| Width | 51.4 in | 50.7 in | +1% | 51st |
| Height | 88.6 in | 78.4 in | +13% | 72nd |
Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 584–816 models).
Compare to tractors with similar specs
Commonly compared Kioti tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Kioti CS2610 | 26 hp | 1,485 lb | — | Compare → |
| Kioti CK3520 | 34.9 hp | 2,679 lb | — | Compare → |
| Kioti LK3504 | 35 hp | 3,170 lb | — | Compare → |
| Kioti CK2620 | 24.5 hp | 2,635 lb | — | Compare → |
| Kioti CS2410 | 24.5 hp | 1,485 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO ST30 | 30.3 hp | 2,594 lb | — | Compare → |
| Allis Chalmers UC | 30.93 hp | 5,710 lb | — | Compare → |
| Allis Chalmers 5030 | 31 hp | 2,530 lb | 1979–1985 | Compare → |
| Allis Chalmers D12 | 31 hp | 2,800 lb | 1959–1968 | Compare → |
| Antonio Carraro Tigre 4000 | 31 hp | — | — | Compare → |
Explore
Kioti siblings
Explore
Similar-spec models
Gallery
Kioti LK30 photos
FAQ
Common questions
How much horsepower does the Kioti LK30 have?
The Kioti LK30 produces 30 hp from its 3-cylinder engine. Engine displacement is 91.5 ci.
How much does the Kioti LK30 weigh?
The Kioti LK30 weighs about 2,897 lb in operating condition.
What transmission is in the Kioti LK30?
Transmission on the Kioti LK30 is Synchronized shuttle, with 8 forward speeds.
What size tires does the Kioti LK30 use?
Factory rubber for the Kioti LK30 is 11.2-24 rear tires.
What maintenance does the Kioti LK30 require?
Like any tractor, the Kioti LK30 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
