Brand siblingUtilityPerformance profile
Kubota KL36
The Kubota KL36 is a utility tractor that was made from 1999 to 2005. It's a strong helper on the farm with four-wheel drive and power steering. This tractor has a lot of gears - 24 forward and 16 reverse - which lets you choose the right speed for any job. Under the hood, the KL36 has a Kubota D1503 engine. It's a diesel engine with three cylinders that uses liquid to stay cool. The engine is about average in size for tractors like this, but it spins very fast at 2700 rpm. It can produce 35.5 horsepower, which is enough for many farm tasks. The tractor is quite light at 3318 pounds, making it easy to move around. It has big tires made for farm work, with 28-inch rear tires that help it grip the ground well. The KL36 also has a roll-over protection system (ROPS) to keep the driver safe.
ManufacturerKubotaPower35.5 hpEngine3-cyl
Quick specs
- Category
- Utility
- Engine Power Output
- 36hp
- Operating Weight
- 3,318 lb
At a glance
How the KL36 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
35.5 hp · 29th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The KL36 ranks at the 29th percentile for engine power among recorded utility tractors.
Overview
About the Kubota KL36
The Kubota KL36 is a utility tractor that was made from 1999 to 2005. It's a strong helper on the farm with four-wheel drive and power steering. This tractor has a lot of gears - 24 forward and 16 reverse - which lets you choose the right speed for any job. Under the hood, the KL36 has a Kubota D1503 engine. It's a diesel engine with three cylinders that uses liquid to stay cool. The engine is about average in size for tractors like this, but it spins very fast at 2700 rpm. It can produce 35.5 horsepower, which is enough for many farm tasks. The tractor is quite light at 3318 pounds, making it easy to move around. It has big tires made for farm work, with 28-inch rear tires that help it grip the ground well. The KL36 also has a roll-over protection system (ROPS) to keep the driver safe.
Full specifications
Every recorded spec
General
| Manufacturer | Kubota |
|---|---|
| Model | KL36 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Years built | 1999–2005 |
| Operating weight | 3,318lb |
Engine
| Make | Kubota |
|---|---|
| Model | D1503 |
| Power | 35.5hp |
| Cylinders | 3 |
| Displacement | 91.5ci |
| Bore | 3.27in |
| Stroke | 3.64in |
Transmission
| Forward gears | 24 |
|---|---|
| Reverse gears | 16 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
| Cab | ROPS |
Dimensions
| Length | 136.6in |
|---|---|
| Width | 57.9in |
| Height | 78in |
| Operating weight | 3,318lb |
Head to head
KL36 vs. Utility median
How the Kubota KL36 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 35.5 hp | 55 hp | -35% | 29th |
| Engine Displacement | 91.5 ci | 183 ci | -50% | 20th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 24 | 12 | +100% | 92nd |
| Operating Weight | 3,318 lb | 5,303 lb | -37% | 27th |
| Length | 137 in | 137 in | 0% | 50th |
| Width | 57.9 in | 66 in | -12% | 33rd |
| Height | 78 in | 94.1 in | -17% | 24th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Kubota tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Kubota GL368 | 35.5 hp | — | 1993–1995 | Compare → |
| Kubota KL360 | 35.5 hp | 3,285 lb | 2006–2007 | Compare → |
| Kubota L3300 | 35.1 hp | 2,610 lb | 1994–1999 | Compare → |
| Kubota L3410 | 35.1 hp | — | 1998–2002 | Compare → |
| Kubota L3430GST | 35.1 hp | 3,262.9 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Ag King AK3540 | 35 hp | 3,895 lb | — | Compare → |
| Antonio Carraro TTR 3800 | 36 hp | 2,150 lb | — | Compare → |
| Apollo 354 | 35 hp | — | — | Compare → |
| Barreiros R-335 S | 35 hp | — | — | Compare → |
| Barreiros R-350 S | 36 hp | — | — | Compare → |
Explore
Kubota siblings
Explore
Similar-spec models
Gallery
Kubota KL36 photos
FAQ
Common questions
When was the Kubota KL36 made?
The Kubota KL36 was manufactured from 1999 to 2005.
What is the operating weight of the Kubota KL36?
In working trim, the Kubota KL36 comes in at roughly 3,318 lb.
What hitch category is the Kubota KL36?
The Kubota KL36 uses a Category I hitch.
What is the engine power output of the Kubota KL36?
Rated engine output for the Kubota KL36 is 35.5 hp, delivered by a 3-cylinder engine. The engine displaces 91.5 ci.
How do I maintain a Kubota KL36?
Routine service for the Kubota KL36 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
