Utility tractorsSpec sheet
Kubota L5450
The Kubota L5450 is a versatile utility tractor built for tough farm work. It has a strong 4-wheel drive system that helps it handle rough terrain. The tractor is powered by a Kubota F2803-DI diesel engine with 5 cylinders. This engine produces 59.5 horsepower, which is above average for tractors in its class. The L5450 features a hydraulic shuttle transmission with 8 forward and 8 reverse gears. This makes it easy to change direction while working. The tractor has a three-point hitch at the rear, which can be used to attach various farm tools. It weighs 4,410 pounds and measures 137.4 inches long and 67.7 inches wide. The open operator station gives the driver a clear view of their surroundings. The tractor runs on agricultural tires, with larger ones at the back for better traction. Kubota is known for making reliable farm equipment, and the L5450 is no exception. It has an open center hydraulic system, which is good for running attachments. The engine is liquid-cooled to keep it running smoothly in hot weather. With its mix of power and features, the Kubota L5450 is a solid choice for farmers who need a dependable utility tractor.
ManufacturerKubotaPower59.5 hp(44.4 kW)Class40–60 HP tractors →Engine5-cylinderTransmissionHydraulic Shuttle
Key specifications
- Category
- Utility
- Engine power
- 60hp
- Operating weight
- 4,410 lb
- Transmission
- Hydraulic Shuttle
Category comparison
L5450 compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
59.5 hp · 53rd
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The L5450 ranks at the 53rd percentile for engine power among recorded utility tractors.
Overview
About the Kubota L5450
The Kubota L5450 is a versatile utility tractor built for tough farm work. It has a strong 4-wheel drive system that helps it handle rough terrain. The tractor is powered by a Kubota F2803-DI diesel engine with 5 cylinders. This engine produces 59.5 horsepower, which is above average for tractors in its class. The L5450 features a hydraulic shuttle transmission with 8 forward and 8 reverse gears. This makes it easy to change direction while working. The tractor has a three-point hitch at the rear, which can be used to attach various farm tools. It weighs 4,410 pounds and measures 137.4 inches long and 67.7 inches wide. The open operator station gives the driver a clear view of their surroundings. The tractor runs on agricultural tires, with larger ones at the back for better traction. Kubota is known for making reliable farm equipment, and the L5450 is no exception. It has an open center hydraulic system, which is good for running attachments. The engine is liquid-cooled to keep it running smoothly in hot weather. With its mix of power and features, the Kubota L5450 is a solid choice for farmers who need a dependable utility tractor.
Full specifications
Recorded specifications
General
| Manufacturer | Kubota |
|---|---|
| Model | L5450 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 4,410lb(2,000 kg) |
Engine
| Make | Kubota |
|---|---|
| Model | F2803-DI |
| Power | 59.5hp(44.37 kW) |
| Cylinders | 5 |
| Displacement | 167.6ci(2.75 L) |
| Bore | 3.4in(86.36 mm) |
| Stroke | 3.6in(91.44 mm) |
Transmission
| Type | Hydraulic Shuttle |
|---|---|
| Forward gears | 8 |
| Reverse gears | 8 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Cab | Open |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Length | 137.4in(3,490 mm) |
|---|---|
| Width | 67.7in(1,720 mm) |
| Operating weight | 4,410lb(2,000 kg) |
Capacities
| Cooling system | 2.13gal(8.06 L) |
|---|
Closest alternatives
L5450 compared with the nearest models by horsepower
The closest utility models to the Kubota L5450 by rated horsepower are the Kubota MX6000 and the Kubota M5970. The Kubota MX6000 matches it on rated power and weighs 680 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. The Kubota M5970 matches it on rated power and weighs 640 lb more, at 85 lb per horsepower against 74 lb.
| Spec | Kubota L5450 | Kubota MX6000 | Kubota M5970 |
|---|---|---|---|
| Engine power | 59.5 hp44.4 kW | 59.5 hp44.4 kW | 59.5 hp44.4 kW |
| Operating weight | 4,410 lb2,000 kg | 3,734 lb1,694 kg | 5,049 lb2,290 kg |
| Weight per hp | 74 lb/hp45 kg/kW | 63 lb/hp38 kg/kW | 85 lb/hp52 kg/kW |
| Displacement | 167.6 ci2.75 L | 148.6 ci2.44 L | 196.5 ci3.22 L |
| Cylinders | 5 | 4 | 3 |
| Transmission | Hydraulic Shuttle | Hydrostatic | Manual with dry disc clutch |
| Drive | 4WD | 2WD | 4WD |
Calculators
Calculators for the L5450
PTO power
About 49 to 54 PTO hp
Estimated from the 59.5 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 59.5 hp tractor can run
Maximum size is about a 7 ft rotary cutter or a 6 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
86 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
59.5 hp is 44.4 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
L5450 vs. Utility median
Kubota L5450 compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 59.5 hp | 55 hp | +8% | 53rd |
| Engine Displacement | 168 ci | 183 ci | -8% | 45th |
| Cylinders | 5 | 4 | +25% | 88th |
| Forward Gears | 8 | 12 | -33% | 23rd |
| Operating Weight | 4,410 lb | 5,303 lb | -17% | 42nd |
| Length | 137 in | 137 in | +1% | 51st |
| Width | 67.7 in | 66 in | +3% | 55th |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 3,933–5,720 models).
Same manufacturer
Other Kubota models
Other manufacturers
Models with similar horsepower
Gallery
Kubota L5450 photos
FAQ
Frequently asked questions
How much horsepower does the Kubota L5450 have?
The Kubota L5450 produces 59.5 hp from its 5-cylinder engine. Engine displacement is 167.6 ci.
What hitch category is the Kubota L5450?
The Kubota L5450 uses a Category II/I hitch.
How much does the Kubota L5450 weigh?
The Kubota L5450 weighs about 4,410 lb in operating condition.
What transmission is in the Kubota L5450?
Transmission on the Kubota L5450 is Hydraulic Shuttle, with 8 forward speeds.
What type of hydraulic system does the Kubota L5450 use?
Hydraulics on the Kubota L5450 are Open Center.
What maintenance does the Kubota L5450 require?
The Kubota L5450 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
