Kubota M4-061
The Kubota M4-061 is a versatile utility tractor built for tough farm work. It has a strong 4-cylinder diesel engine that makes 65.4 horsepower. This engine is turbocharged and liquid-cooled, which helps it run smoothly. The tractor has four-wheel drive, which gives it good traction in different conditions. This Kubota model has a comfortable cab for the driver. It has a power shuttle transmission with 18 forward and 18 reverse gears, including creeper gears for slow-speed tasks. The tractor's hydraulic system is open center type, and it has a Category 3 hitch at the rear for attaching various tools. At 6,008 pounds, it's a solid machine that can handle heavy jobs. The M4-061 is about average in size for its class, measuring 142 inches long, 75.6 inches wide, and 101 inches tall.
ManufacturerKubotaPower65.4 hp(48.8 kW)Class60–100 HP tractors →Engine4-cylinderTransmissionPower shuttle, Creeper
Key specifications
- Category
- Utility
- Engine power
- 65hp
- Operating weight
- 6,008 lb
- Transmission
- Power shuttle, Creeper
Category comparison
M4-061 compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
65.4 hp · 59th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The M4-061 ranks at the 59th percentile for engine power among recorded utility tractors.
Overview
About the Kubota M4-061
The Kubota M4-061 is a versatile utility tractor built for tough farm work. It has a strong 4-cylinder diesel engine that makes 65.4 horsepower. This engine is turbocharged and liquid-cooled, which helps it run smoothly. The tractor has four-wheel drive, which gives it good traction in different conditions. This Kubota model has a comfortable cab for the driver. It has a power shuttle transmission with 18 forward and 18 reverse gears, including creeper gears for slow-speed tasks. The tractor's hydraulic system is open center type, and it has a Category 3 hitch at the rear for attaching various tools. At 6,008 pounds, it's a solid machine that can handle heavy jobs. The M4-061 is about average in size for its class, measuring 142 inches long, 75.6 inches wide, and 101 inches tall.
Full specifications
Recorded specifications
General
| Manufacturer | Kubota |
|---|---|
| Model | M4-061 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Years built | 2019+ |
| Operating weight | 6,008lb(2,725 kg) |
Engine
| Make | Kubota |
|---|---|
| Model | V3307-CR-TE4 |
| Power | 65.4hp(48.77 kW) |
| Cylinders | 4 |
| Displacement | 203ci(3.33 L) |
| Bore | 3.7in(93.98 mm) |
| Stroke | 4.7in(119.4 mm) |
Transmission
| Type | Power shuttle, Creeper |
|---|---|
| Forward gears | 18 |
| Reverse gears | 18 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
| Cab | Cab |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Length | 142in(3,607 mm) |
|---|---|
| Width | 75.6in(1,920 mm) |
| Height | 101in(2,565 mm) |
| Operating weight | 6,008lb(2,725 kg) |
Capacities
| Cooling system | 2.65gal(10.03 L) |
|---|
Closest alternatives
M4-061 compared with the nearest models by horsepower
By engine horsepower, the nearest utility models to the M4-061 are the Minneapolis-Moline M-5 and the Massey Ferguson 390T. The Minneapolis-Moline M-5 matches it on rated power and weighs 760 lb more, at 103 lb per horsepower against 92 lb. The Massey Ferguson 390T matches it on rated power and weighs 320 lb more. It entered production in 1989, 30 years before the M4-061. Of the 3 models, the M4-061 has the lowest weight per horsepower at 92 lb per hp.
| Spec | Kubota M4-061 | Minneapolis-Moline M-5 | Massey Ferguson 390T |
|---|---|---|---|
| Engine power | 65.4 hp48.8 kW | 65.6 hp48.9 kW | 65.2 hp48.6 kW |
| Operating weight | 6,008 lb2,725 kg | 6,765 lb3,069 kg | 6,325 lb2,869 kg |
| Weight per hp | 92 lb/hp56 kg/kW | 103 lb/hp63 kg/kW | 97 lb/hp59 kg/kW |
| Displacement | 203 ci3.33 L | 336 ci5.51 L | 236 ci3.87 L |
| Cylinders | 4 | 4 | 4 |
| Transmission | Power shuttle, Creeper | Partial Power Shift | Synchromesh, Synchronized shuttle, Two-speed power shift |
| Drive | 4WD | - | 2WD |
| Years built | 2019+ | - | 1989-1997 |
Calculators
Calculators for the M4-061
PTO power
About 54 to 59 PTO hp
Estimated from the 65.4 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 65.4 hp tractor can run
Maximum size is about a 8 ft rotary cutter or a 6.5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
107 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
65.4 hp is 48.8 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
M4-061 vs. Utility median
Kubota M4-061 compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 65.4 hp | 55 hp | +19% | 59th |
| Engine Displacement | 203 ci | 183 ci | +11% | 56th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 18 | 12 | +50% | 83rd |
| Operating Weight | 6,008 lb | 5,303 lb | +13% | 57th |
| Length | 142 in | 137 in | +4% | 57th |
| Width | 75.6 in | 66 in | +15% | 72nd |
| Height | 101 in | 94.1 in | +7% | 68th |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 3,933–5,720 models).
Same manufacturer
Other Kubota models
Other manufacturers
Models with similar horsepower
Gallery
Kubota M4-061 photos
FAQ
Frequently asked questions
What years was the Kubota M4-061 manufactured?
Production of the Kubota M4-061 began in 2019.
How powerful is the Kubota M4-061?
The Kubota M4-061 has an engine power output of 65.4 hp. It is powered by a 4-cylinder engine displacing 203 ci.
What is the working weight of the Kubota M4-061?
The operating weight of the Kubota M4-061 is approximately 6,008 lb.
What type of transmission does the Kubota M4-061 have?
The Kubota M4-061 uses a Power shuttle, Creeper transmission offering 18 forward gears.
What hydraulics does the Kubota M4-061 have?
The Kubota M4-061 uses an Open Center hydraulic system.
What three-point hitch category does the Kubota M4-061 use?
The Kubota M4-061 has a Category Category 3 three-point hitch.
What routine service does the Kubota M4-061 need?
Regular maintenance for the Kubota M4-061 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
