Sub-Compact tractorsSpec sheet
Kubota MX4800DTRC GEAR 2WD
The Kubota MX4800DTRC GEAR 2WD is a powerful and reliable tractor designed for farmers who need a sturdy machine for their fields. This tractor has a 2-wheel drive system and a manual transmission, making it easy to control. It's powered by a Kubota V2403-CR-E4 engine, which has 4 cylinders and is turbocharged for extra strength. The engine produces 46.9 hp at 2700 rpm, giving it plenty of power for various farm tasks. This tractor weighs 3470.1 lb, making it solid and stable on the ground. It has a Category 3 hitch that can lift up to 2866.1 lb, which is great for attaching and using different farm tools. The MX4800DTRC GEAR 2WD also has a PTO (Power Take-Off) that delivers 40.5 hp, allowing it to run many types of farm equipment. Kubota is known for making tough, long-lasting tractors, and this model continues that tradition with its strong build and reliable performance.
Key specifications
- Category
- Sub-Compact
- Engine power
- 47hp
- Operating weight
- 3,470.1 lb
- Transmission
- Manual
Category comparison
MX4800DTRC GEAR 2WD compared with its category
vs. Sub-Compact medianDistribution
Engine Power (hp)
All recorded Sub-Compact tractors
46.9 hp · 85th
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The MX4800DTRC GEAR 2WD ranks at the 85th percentile for engine power among recorded sub-compact tractors.
Overview
About the Kubota MX4800DTRC GEAR 2WD
The Kubota MX4800DTRC GEAR 2WD is a powerful and reliable tractor designed for farmers who need a sturdy machine for their fields. This tractor has a 2-wheel drive system and a manual transmission, making it easy to control. It's powered by a Kubota V2403-CR-E4 engine, which has 4 cylinders and is turbocharged for extra strength. The engine produces 46.9 hp at 2700 rpm, giving it plenty of power for various farm tasks. This tractor weighs 3470.1 lb, making it solid and stable on the ground. It has a Category 3 hitch that can lift up to 2866.1 lb, which is great for attaching and using different farm tools. The MX4800DTRC GEAR 2WD also has a PTO (Power Take-Off) that delivers 40.5 hp, allowing it to run many types of farm equipment. Kubota is known for making tough, long-lasting tractors, and this model continues that tradition with its strong build and reliable performance.
Full specifications
Recorded specifications
General
| Manufacturer | Kubota |
|---|---|
| Model | MX4800DTRC GEAR 2WD |
| Category | Sub-Compact tractor |
| Type | 4x2 |
| Operating weight | 3,470.1lb(1,574 kg) |
Engine
| Make | Kubota |
|---|---|
| Model | V2403-CR-E4 |
| Power | 46.9hp(34.97 kW) |
| Cylinders | 4 |
| Bore | 3.5in(88.9 mm) |
| Stroke | 4.1in(104.1 mm) |
Transmission
| Type | Manual |
|---|
Chassis & drive
| Chassis | 4x2 |
|---|---|
| Drive | 2WD |
Dimensions
| Operating weight | 3,470.1lb(1,574 kg) |
|---|
Closest alternatives
MX4800DTRC GEAR 2WD compared with the nearest models by horsepower
By engine horsepower, the nearest sub-compact models to the MX4800DTRC GEAR 2WD are the Kubota MX4800HSTRC and the New Holland T3030. The Kubota MX4800HSTRC matches it on rated power and weighs 260 lb more. The New Holland T3030 matches it on rated power and weighs 250 lb less.
| Spec | Kubota MX4800DTRC GEAR 2WD | Kubota MX4800HSTRC | New Holland T3030 |
|---|---|---|---|
| Engine power | 46.9 hp35 kW | 46.9 hp35 kW | 46.9 hp35 kW |
| Operating weight | 3,470 lb1,574 kg | 3,730 lb1,692 kg | 3,219 lb1,460 kg |
| Weight per hp | 74 lb/hp45 kg/kW | 80 lb/hp48 kg/kW | 69 lb/hp42 kg/kW |
| Displacement | - | 148.6 ci2.44 L | 133.6 ci2.19 L |
| Cylinders | 4 | 4 | 4 |
| Transmission | Manual | Hydrostatic | Synchro shuttle |
| Drive | 2WD | - | 4WD |
Calculators
Calculators for the MX4800DTRC GEAR 2WD
PTO power
About 39 to 42 PTO hp
Estimated from the 46.9 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 46.9 hp tractor can run
Maximum size is about a 5.5 ft rotary cutter or a 5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
86 lb per PTO hp as listed
Heavy draft work calls for 130 to 150 lb/hp. The calculator gives the ballast to add.
Units
46.9 hp is 35.0 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
MX4800DTRC GEAR 2WD vs. Sub-Compact median
Kubota MX4800DTRC GEAR 2WD compared with other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 46.9 hp | 26.9 hp | +75% | 85th |
| Cylinders | 4 | 3 | +33% | 90th |
| Operating Weight | 3,470 lb | 2,700 lb | +29% | 65th |
| 3-Point Hitch Capacity | 2,866 lb | 1,433 lb | +100% | 92nd |
Medians and percentiles are calculated from the sub-compact tractors in the database that have a recorded value for each specification (sample size 97–816 models).
Same manufacturer
Other Kubota models
Other manufacturers
Models with similar horsepower
Gallery
Kubota MX4800DTRC GEAR 2WD photos
FAQ
Frequently asked questions
How powerful is the Kubota MX4800DTRC GEAR 2WD?
The Kubota MX4800DTRC GEAR 2WD has an engine power output of 46.9 hp. It is powered by a 4-cylinder engine.
What hitch category is the Kubota MX4800DTRC GEAR 2WD?
The Kubota MX4800DTRC GEAR 2WD uses a Category Category 3 hitch with a lift capacity of 2,866.1 lb.
What is the working weight of the Kubota MX4800DTRC GEAR 2WD?
The operating weight of the Kubota MX4800DTRC GEAR 2WD is approximately 3,470.1 lb.
What type of transmission does the Kubota MX4800DTRC GEAR 2WD have?
The Kubota MX4800DTRC GEAR 2WD uses a Manual transmission.
What routine service does the Kubota MX4800DTRC GEAR 2WD need?
Regular maintenance for the Kubota MX4800DTRC GEAR 2WD includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
