Kubota MX4800DTRC
The Kubota MX4800DTRC is a versatile tractor designed for various farming tasks. It features a Kubota V2403CR engine with 4 cylinders and 49.3 hp, providing plenty of power for most jobs. The tractor has 8 forward and 8 reverse gears, giving operators good control over speed and performance. This model is compact yet capable, measuring 125.2 inches long and 96 inches tall. It weighs 3712.6 lb, making it sturdy enough for tough work. The tractor comes with a Category 3 hitch that can lift up to 2314.9 lb, which is great for handling heavy attachments. The PTO runs at 540 rpm, suitable for many farm implements. Additional features include a 45 A alternator, a pump flow capacity of 9.5 gal/min, and up to 3 remote control valves for extra versatility.
Key specifications
- Category
- Sub-Compact
- Engine power
- 49hp
- Operating weight
- 3,712.6 lb
Category comparison
MX4800DTRC compared with its category
vs. Sub-Compact medianDistribution
Engine Power (hp)
All recorded Sub-Compact tractors
49.3 hp · 89th
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The MX4800DTRC ranks at the 89th percentile for engine power among recorded sub-compact tractors.
Overview
About the Kubota MX4800DTRC
The Kubota MX4800DTRC is a versatile tractor designed for various farming tasks. It features a Kubota V2403CR engine with 4 cylinders and 49.3 hp, providing plenty of power for most jobs. The tractor has 8 forward and 8 reverse gears, giving operators good control over speed and performance. This model is compact yet capable, measuring 125.2 inches long and 96 inches tall. It weighs 3712.6 lb, making it sturdy enough for tough work. The tractor comes with a Category 3 hitch that can lift up to 2314.9 lb, which is great for handling heavy attachments. The PTO runs at 540 rpm, suitable for many farm implements. Additional features include a 45 A alternator, a pump flow capacity of 9.5 gal/min, and up to 3 remote control valves for extra versatility.
Full specifications
Recorded specifications
General
| Manufacturer | Kubota |
|---|---|
| Model | MX4800DTRC |
| Category | Sub-Compact tractor |
| Operating weight | 3,712.6lb(1,684 kg) |
Engine
| Make | Kubota |
|---|---|
| Model | V2403CR |
| Power | 49.3hp(36.76 kW) |
| Cylinders | 4 |
| Displacement | 148.6ci(2.44 L) |
Transmission
| Forward gears | 8 |
|---|---|
| Reverse gears | 8 |
Power take-off
| PTO speed | 540rpm |
|---|
Dimensions
| Length | 125.2in(3,180 mm) |
|---|---|
| Height | 96in(2,438 mm) |
| Operating weight | 3,712.6lb(1,684 kg) |
Closest alternatives
MX4800DTRC compared with the nearest models by horsepower
The closest sub-compact models to the Kubota MX4800DTRC by rated horsepower are the Carraro 520.5 and the Iseki TA505. The Carraro 520.5 matches it on rated power. The Iseki TA505 matches it on rated power and weighs 1,050 lb more, at 97 lb per horsepower against 75 lb.
| Spec | Kubota MX4800DTRC | Carraro 520.5 | Iseki TA505 |
|---|---|---|---|
| Engine power | 49.3 hp36.8 kW | 49.3 hp36.8 kW | 49.3 hp36.8 kW |
| Operating weight | 3,713 lb1,684 kg | - | 4,762 lb2,160 kg |
| Weight per hp | 75 lb/hp46 kg/kW | - | 97 lb/hp59 kg/kW |
| Displacement | 148.6 ci2.44 L | 174.3 ci2.86 L | 169.1 ci2.77 L |
| Cylinders | 4 | 3 | 4 |
Calculators
Calculators for the MX4800DTRC
PTO power
About 41 to 44 PTO hp
Estimated from the 49.3 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 49.3 hp tractor can run
Maximum size is about a 6 ft rotary cutter or a 5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
88 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
49.3 hp is 36.8 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
MX4800DTRC vs. Sub-Compact median
Kubota MX4800DTRC compared with other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 49.3 hp | 26.9 hp | +84% | 89th |
| Engine Displacement | 149 ci | 91.4 ci | +63% | 83rd |
| Cylinders | 4 | 3 | +33% | 90th |
| Forward Gears | 8 | 9 | -11% | 40th |
| Operating Weight | 3,713 lb | 2,700 lb | +38% | 71st |
| Length | 125 in | 113 in | +10% | 69th |
| Height | 96 in | 78.4 in | +22% | 89th |
| 3-Point Hitch Capacity | 2,315 lb | 1,433 lb | +62% | 69th |
Medians and percentiles are calculated from the sub-compact tractors in the database that have a recorded value for each specification (sample size 97–816 models).
Same manufacturer
Other Kubota models
Other manufacturers
Models with similar horsepower
Gallery
Kubota MX4800DTRC photos
FAQ
Frequently asked questions
How powerful is the Kubota MX4800DTRC?
The Kubota MX4800DTRC has an engine power output of 49.3 hp. It is powered by a 4-cylinder engine displacing 148.6 ci.
What hitch category is the Kubota MX4800DTRC?
The Kubota MX4800DTRC uses a Category Category 3 hitch with a lift capacity of 2,314.9 lb.
What is the working weight of the Kubota MX4800DTRC?
The operating weight of the Kubota MX4800DTRC is approximately 3,712.6 lb.
What routine service does the Kubota MX4800DTRC need?
Regular maintenance for the Kubota MX4800DTRC includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
