Utility tractorsSpec sheet
Kubota MX5200DTRC GEAR 2WD
The Kubota MX5200DTRC GEAR 2WD is a utility tractor built for farmers who need a reliable machine. It has a 2-wheel drive system and a gear transmission, making it easy to use in various farm tasks. The tractor is powered by a Kubota V2403-CR-E4 diesel engine with 4 cylinders and a turbocharger. This engine can produce 46.9 hp at 2700 rpm, which is about average for tractors in its class. One of the standout features of the MX5200DTRC GEAR 2WD is its three-point hitch at the rear. This hitch can lift up to 2866.1 lb, which is above average and great for handling heavy farm equipment. The tractor weighs 3470.1 lb, making it relatively light and easy to maneuver. Kubota is known for making durable and efficient tractors, and this model continues that tradition with its solid build and practical design.
Key specifications
- Category
- Utility
- Engine power
- 47hp
- Operating weight
- 3,470.1 lb
- Transmission
- Gear
Category comparison
MX5200DTRC GEAR 2WD compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
46.9 hp · 41st
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The MX5200DTRC GEAR 2WD ranks at the 41st percentile for engine power among recorded utility tractors.
Overview
About the Kubota MX5200DTRC GEAR 2WD
The Kubota MX5200DTRC GEAR 2WD is a utility tractor built for farmers who need a reliable machine. It has a 2-wheel drive system and a gear transmission, making it easy to use in various farm tasks. The tractor is powered by a Kubota V2403-CR-E4 diesel engine with 4 cylinders and a turbocharger. This engine can produce 46.9 hp at 2700 rpm, which is about average for tractors in its class. One of the standout features of the MX5200DTRC GEAR 2WD is its three-point hitch at the rear. This hitch can lift up to 2866.1 lb, which is above average and great for handling heavy farm equipment. The tractor weighs 3470.1 lb, making it relatively light and easy to maneuver. Kubota is known for making durable and efficient tractors, and this model continues that tradition with its solid build and practical design.
Full specifications
Recorded specifications
General
| Manufacturer | Kubota |
|---|---|
| Model | MX5200DTRC GEAR 2WD |
| Category | Utility tractor |
| Type | 4x2 |
| Operating weight | 3,470.1lb(1,574 kg) |
Engine
| Make | Kubota |
|---|---|
| Model | V2403-CR-E4 |
| Power | 46.9hp(34.97 kW) |
| Cylinders | 4 |
| Bore | 3.5in(88.9 mm) |
| Stroke | 4.1in(104.1 mm) |
Transmission
| Type | Gear |
|---|
Chassis & drive
| Chassis | 4x2 |
|---|---|
| Drive | 2WD |
Dimensions
| Operating weight | 3,470.1lb(1,574 kg) |
|---|
Closest alternatives
MX5200DTRC GEAR 2WD compared with the nearest models by horsepower
By engine horsepower, the nearest utility models to the MX5200DTRC GEAR 2WD are the Kubota MX4800 and the Claas Talos 120. The Kubota MX4800 matches it on rated power at almost the same operating weight. The Claas Talos 120 matches it on rated power and weighs 950 lb more, so it carries more weight per horsepower, which helps traction in draft work.
| Spec | Kubota MX5200DTRC GEAR 2WD | Kubota MX4800 | Claas Talos 120 |
|---|---|---|---|
| Engine power | 46.9 hp35 kW | 46.9 hp35 kW | 46.9 hp35 kW |
| Operating weight | 3,470 lb1,574 kg | 3,469 lb1,574 kg | 4,420 lb2,005 kg |
| Weight per hp | 74 lb/hp45 kg/kW | 74 lb/hp45 kg/kW | 94 lb/hp57 kg/kW |
| Displacement | - | 148.5 ci2.43 L | 152.6 ci2.5 L |
| Cylinders | 4 | 4 | 4 |
| Transmission | Gear | Synchronized shuttle | Synchromesh |
| Drive | 2WD | - | 4WD |
Calculators
Calculators for the MX5200DTRC GEAR 2WD
PTO power
About 39 to 42 PTO hp
Estimated from the 46.9 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 46.9 hp tractor can run
Maximum size is about a 5.5 ft rotary cutter or a 5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
86 lb per PTO hp as listed
Heavy draft work calls for 130 to 150 lb/hp. The calculator gives the ballast to add.
Units
46.9 hp is 35.0 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
MX5200DTRC GEAR 2WD vs. Utility median
Kubota MX5200DTRC GEAR 2WD compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 46.9 hp | 55 hp | -15% | 41st |
| Cylinders | 4 | 4 | at median | 50th |
| Operating Weight | 3,470 lb | 5,303 lb | -35% | 29th |
| 3-Point Hitch Capacity | 2,866 lb | 3,197 lb | -10% | 43rd |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 1,083–5,720 models).
Same manufacturer
Other Kubota models
Other manufacturers
Models with similar horsepower
Gallery
Kubota MX5200DTRC GEAR 2WD photos
FAQ
Frequently asked questions
How powerful is the Kubota MX5200DTRC GEAR 2WD?
The Kubota MX5200DTRC GEAR 2WD has an engine power output of 46.9 hp. It is powered by a 4-cylinder engine.
What is the working weight of the Kubota MX5200DTRC GEAR 2WD?
The operating weight of the Kubota MX5200DTRC GEAR 2WD is approximately 3,470.1 lb.
What type of transmission does the Kubota MX5200DTRC GEAR 2WD have?
The Kubota MX5200DTRC GEAR 2WD uses a Gear transmission.
What routine service does the Kubota MX5200DTRC GEAR 2WD need?
Regular maintenance for the Kubota MX5200DTRC GEAR 2WD includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
