Utility tractorsSpec sheet
LS R4047H
The LS R4047H is a versatile utility tractor designed for various farm tasks. It features a powerful 4-cylinder Mitsubishi diesel engine that produces 47 horsepower. The engine has average displacement for its class and runs at a very high rated speed of 2600 rpm. This tractor is built with a 4x4 MFWD chassis, making it capable of handling tough terrain. One of the standout features of the R4047H is its hydrostatic transmission, which offers infinite forward and reverse speeds in three ranges. This gives operators excellent control and flexibility. The tractor has a compact size, measuring 132.2 inches long, 55.9 inches wide, and 95.1 inches tall. It has an average operating weight of 3813 pounds, making it suitable for a wide range of farm applications. The R4047H comes with a Category I hitch and a ROPS (Roll-Over Protective Structure) for operator safety. It also features hydrostatic power steering with a flow rate of 5.5 gallons per minute, ensuring smooth and responsive handling.
Key specifications
- Category
- Utility
- Engine power
- 47hp
- Operating weight
- 3,813 lb
- Transmission
- Hydrostatic
Category comparison
R4047H compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
47 hp · 41st
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The R4047H ranks at the 41st percentile for engine power among recorded utility tractors.
Overview
About the LS R4047H
The LS R4047H is a versatile utility tractor designed for various farm tasks. It features a powerful 4-cylinder Mitsubishi diesel engine that produces 47 horsepower. The engine has average displacement for its class and runs at a very high rated speed of 2600 rpm. This tractor is built with a 4x4 MFWD chassis, making it capable of handling tough terrain. One of the standout features of the R4047H is its hydrostatic transmission, which offers infinite forward and reverse speeds in three ranges. This gives operators excellent control and flexibility. The tractor has a compact size, measuring 132.2 inches long, 55.9 inches wide, and 95.1 inches tall. It has an average operating weight of 3813 pounds, making it suitable for a wide range of farm applications. The R4047H comes with a Category I hitch and a ROPS (Roll-Over Protective Structure) for operator safety. It also features hydrostatic power steering with a flow rate of 5.5 gallons per minute, ensuring smooth and responsive handling.
Full specifications
Recorded specifications
General
| Manufacturer | LS |
|---|---|
| Model | R4047H |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 3,813lb(1,730 kg) |
Engine
| Make | Mitsibishi |
|---|---|
| Model | S4QL |
| Power | 47hp(35.05 kW) |
| Cylinders | 4 |
| Displacement | 152.9ci(2.51 L) |
| Bore | 3.46in(87.88 mm) |
| Stroke | 4.06in(103.1 mm) |
Transmission
| Type | Hydrostatic |
|---|
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
| Cab | ROPS |
Dimensions
| Length | 132.2in(3,358 mm) |
|---|---|
| Width | 55.9in(1,420 mm) |
| Height | 95.1in(2,416 mm) |
| Operating weight | 3,813lb(1,730 kg) |
Closest alternatives
R4047H compared with the nearest models by horsepower
By engine horsepower, the nearest utility models to the R4047H are the LS K5047 and the LS KR50. The LS K5047 matches it on rated power and weighs 580 lb more, so it carries more weight per horsepower, which helps traction in draft work. The LS KR50 matches it on rated power and weighs 50 lb less.
| Spec | LS R4047H | LS K5047 | LS KR50 |
|---|---|---|---|
| Engine power | 47 hp35 kW | 47 hp35 kW | 47 hp35 kW |
| Operating weight | 3,813 lb1,730 kg | 4,392 lb1,992 kg | 3,759 lb1,705 kg |
| Weight per hp | 81 lb/hp49 kg/kW | 93 lb/hp57 kg/kW | 80 lb/hp49 kg/kW |
| Displacement | 152.9 ci2.51 L | 152.9 ci2.51 L | 152.9 ci2.51 L |
| Cylinders | 4 | 4 | 4 |
| Transmission | Hydrostatic | Sliding gear | Synchronized shuttle |
| Drive | 4WD | 4WD | 4WD |
Calculators
Calculators for the R4047H
PTO power
About 39 to 42 PTO hp
Estimated from the 47 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 47 hp tractor can run
Maximum size is about a 5.5 ft rotary cutter or a 5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
94 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
47 hp is 35.0 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
R4047H vs. Utility median
LS R4047H compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 47 hp | 55 hp | -15% | 41st |
| Engine Displacement | 153 ci | 183 ci | -16% | 40th |
| Cylinders | 4 | 4 | at median | 50th |
| Operating Weight | 3,813 lb | 5,303 lb | -28% | 34th |
| Length | 132 in | 137 in | -3% | 44th |
| Width | 55.9 in | 66 in | -15% | 29th |
| Height | 95.1 in | 94.1 in | +1% | 52nd |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 3,933–5,720 models).
Same manufacturer
Other LS models
Other manufacturers
Models with similar horsepower
Gallery
LS R4047H photos
FAQ
Frequently asked questions
What is the engine power output of the LS R4047H?
Rated engine output for the LS R4047H is 47 hp, delivered by a 4-cylinder engine. The engine displaces 152.9 ci.
Which transmission does the LS R4047H use?
The LS R4047H is equipped with a Hydrostatic transmission.
What hitch category is the LS R4047H?
The LS R4047H uses a Category I hitch.
What is the operating weight of the LS R4047H?
The LS R4047H has an operating weight of about 3,813 lb.
How do I maintain a LS R4047H?
Routine service for the LS R4047H covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
