UtilityPerformance profile
Marshall 752
The Marshall 752 is a sturdy 2WD tractor built for farm work. It has a 4x2 chassis and uses hydrostatic power steering, making it easy to control. The tractor comes with a manual transmission that offers 15 forward gears and 5 reverse gears, giving farmers plenty of options for different tasks. Under the hood, the Marshall 752 has a Perkins 4.236 engine. This diesel engine is liquid-cooled and has 4 cylinders. It can produce 74 hp at 2200 rpm, which is enough power for most farm jobs. The engine has a displacement of 236 ci, which is about average for tractors of this size. The tractor's size is good for getting around the farm, measuring 153.4 inches long, 77 inches wide, and 104 inches tall. It has a wheelbase of 88.5 inches and 18 inches of ground clearance, helping it move over rough ground. The Marshall 752 also comes with a Category II hitch, useful for attaching various farm tools.
ManufacturerMarshallPower74 hpEngine4-cylTransManual
Quick specs
- Category
- Utility
- Engine Power Output
- 74hp
- Transmission
- Manual
At a glance
How the 752 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
74 hp · 66th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 752 ranks at the 66th percentile for engine power among recorded utility tractors.
Overview
About the Marshall 752
The Marshall 752 is a sturdy 2WD tractor built for farm work. It has a 4x2 chassis and uses hydrostatic power steering, making it easy to control. The tractor comes with a manual transmission that offers 15 forward gears and 5 reverse gears, giving farmers plenty of options for different tasks. Under the hood, the Marshall 752 has a Perkins 4.236 engine. This diesel engine is liquid-cooled and has 4 cylinders. It can produce 74 hp at 2200 rpm, which is enough power for most farm jobs. The engine has a displacement of 236 ci, which is about average for tractors of this size. The tractor's size is good for getting around the farm, measuring 153.4 inches long, 77 inches wide, and 104 inches tall. It has a wheelbase of 88.5 inches and 18 inches of ground clearance, helping it move over rough ground. The Marshall 752 also comes with a Category II hitch, useful for attaching various farm tools.
Full specifications
Every recorded spec
General
| Manufacturer | Marshall |
|---|---|
| Model | 752 |
| Category | Utility tractor |
| Type | 4x2 |
Engine
| Make | Perkins |
|---|---|
| Model | 4.236 |
| Power | 74hp |
| Cylinders | 4 |
| Displacement | 236ci |
| Bore | 3.88in |
| Stroke | 5in |
Transmission
| Type | Manual |
|---|---|
| Forward gears | 15 |
| Reverse gears | 5 |
Chassis & drive
| Chassis | 4x2 |
|---|---|
| Drive | 2WD |
| Steering | Hydrostatic power |
Dimensions
| Length | 153.4in |
|---|---|
| Width | 77in |
| Height | 104in |
Capacities
| Cooling system | 3.83gal |
|---|
Head to head
752 vs. Utility median
How the Marshall 752 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 74 hp | 55 hp | +35% | 66th |
| Engine Displacement | 236 ci | 183 ci | +29% | 65th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 15 | 12 | +25% | 64th |
| Length | 153 in | 137 in | +12% | 70th |
| Width | 77 in | 66 in | +17% | 75th |
| Height | 104 in | 94.1 in | +11% | 75th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Marshall tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Marshall 754 | 74 hp | — | — | Compare → |
| Marshall MP6 | 70 hp | — | — | Compare → |
| Marshall 802 | 82 hp | 6,550 lb | — | Compare → |
| Marshall 854 | 85 hp | — | — | Compare → |
| Marshall 954 | 94.5 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers D19 | 74.2 hp | 6,650 lb | 1961–1964 | Compare → |
| AGCO GT65 | 71 hp | 5,335 lb | — | Compare → |
| Agco GT65A | 71 hp | 5,864.3 lb | — | Compare → |
| Antonio Carraro SX 7800S | 71 hp | 4,773 lb | — | Compare → |
| Antonio Carraro TGF 7800S | 71 hp | 5,093 lb | — | Compare → |
Explore
Marshall siblings
Explore
Similar-spec models
Gallery
Marshall 752 photos
FAQ
Common questions
How powerful is the Marshall 752?
The Marshall 752 has an engine power output of 74 hp. It is powered by a 4-cylinder engine displacing 236 ci.
What hitch category is the Marshall 752?
The Marshall 752 uses a Category Category 3 hitch.
What type of transmission does the Marshall 752 have?
The Marshall 752 uses a Manual transmission offering 15 forward gears.
What routine service does the Marshall 752 need?
Regular maintenance for the Marshall 752 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
