Row Crop tractorsSpec sheet
Massey Ferguson 1024
The Massey Ferguson 1024 is a powerful row crop tractor built for tough farm work. It has a 4-wheel drive system and hydrostatic power steering, making it easy to control in the field. The tractor comes with a manual transmission that offers 12 forward gears and 4 reverse gears, giving farmers plenty of options for different tasks. Under the hood, the Massey Ferguson 1024 boasts a Perkins A6.354.4 engine. This 6-cylinder diesel engine is liquid-cooled and packs a punch with 127 horsepower. The engine has an average displacement of 353.9 cubic inches and runs at a very high 2400 rpm. The tractor's size is impressive, measuring 173.6 inches long and 111 inches tall. It weighs in at 11,025 pounds, which is about average for its class. With its strong engine and sturdy build, this tractor is well-suited for a variety of farm tasks.
ManufacturerMassey FergusonPower127 hp(94.7 kW)Class100–150 HP tractors →Engine6-cylinderTransmissionManual
Key specifications
- Category
- Row Crop
- Engine power
- 127hp
- Operating weight
- 11,025 lb
- Transmission
- Manual
Category comparison
1024 compared with its category
vs. Row Crop medianDistribution
Engine Power (hp)
All recorded Row Crop tractors
127 hp · 44th
This model
12
Median 138 hp
283
This modelRow Crop tractorsMediann = 1,206
The 1024 ranks at the 44th percentile for engine power among recorded row crop tractors.
Overview
About the Massey Ferguson 1024
The Massey Ferguson 1024 is a powerful row crop tractor built for tough farm work. It has a 4-wheel drive system and hydrostatic power steering, making it easy to control in the field. The tractor comes with a manual transmission that offers 12 forward gears and 4 reverse gears, giving farmers plenty of options for different tasks. Under the hood, the Massey Ferguson 1024 boasts a Perkins A6.354.4 engine. This 6-cylinder diesel engine is liquid-cooled and packs a punch with 127 horsepower. The engine has an average displacement of 353.9 cubic inches and runs at a very high 2400 rpm. The tractor's size is impressive, measuring 173.6 inches long and 111 inches tall. It weighs in at 11,025 pounds, which is about average for its class. With its strong engine and sturdy build, this tractor is well-suited for a variety of farm tasks.
Full specifications
Recorded specifications
General
| Manufacturer | Massey Ferguson |
|---|---|
| Model | 1024 |
| Category | Row Crop tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 11,025lb(5,001 kg) |
Engine
| Make | Perkins |
|---|---|
| Model | A6.354.4 |
| Power | 127hp(94.7 kW) |
| Cylinders | 6 |
| Displacement | 353.9ci(5.8 L) |
| Bore | 3.88in(98.42 mm) |
| Stroke | 5in(127 mm) |
Transmission
| Type | Manual |
|---|---|
| Forward gears | 12 |
| Reverse gears | 4 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
Dimensions
| Length | 173.6in(4,409 mm) |
|---|---|
| Height | 111in(2,819 mm) |
| Operating weight | 11,025lb(5,001 kg) |
Closest alternatives
1024 compared with the nearest models by horsepower
By engine horsepower, the nearest row crop models to the 1024 are the Massey Ferguson 3630 and the Landini 13000. The Massey Ferguson 3630 matches it on rated power and weighs 1,780 lb more, at 101 lb per horsepower against 87 lb. The Landini 13000 matches it on rated power and weighs 1,100 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft.
| Spec | Massey Ferguson 1024 | Massey Ferguson 3630 | Landini 13000 |
|---|---|---|---|
| Engine power | 127 hp94.7 kW | 127 hp94.7 kW | 127 hp94.7 kW |
| Operating weight | 11,025 lb5,001 kg | 12,800 lb5,806 kg | 9,921 lb4,500 kg |
| Weight per hp | 87 lb/hp53 kg/kW | 101 lb/hp61 kg/kW | 78 lb/hp48 kg/kW |
| Displacement | 353.9 ci5.8 L | 354 ci5.8 L | 353.9 ci5.8 L |
| Cylinders | 6 | 6 | 6 |
| Transmission | Manual | selective gear fixed ratio with partial (2) range operator-controlled powershift | Manual |
| Drive | 4WD | 2WD | 4WD |
Calculators
Calculators for the 1024
PTO power
About 105 to 114 PTO hp
Estimated from the 127 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 127 hp tractor can run
Maximum size is about a 15 ft rotary cutter or a 13 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
101 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
127 hp is 94.7 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
1024 vs. Row Crop median
Massey Ferguson 1024 compared with other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 127 hp | 138 hp | -8% | 44th |
| Engine Displacement | 354 ci | 391 ci | -9% | 38th |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 12 | 16 | -25% | 27th |
| Operating Weight | 11,025 lb | 12,307 lb | -10% | 39th |
| Length | 174 in | 180 in | -3% | 41st |
| Height | 111 in | 114 in | -2% | 40th |
Medians and percentiles are calculated from the row crop tractors in the database that have a recorded value for each specification (sample size 1,140–1,417 models).
Same manufacturer
Other Massey Ferguson models
Other manufacturers
Models with similar horsepower
Gallery
Massey Ferguson 1024 photos
FAQ
Frequently asked questions
What is the engine power output of the Massey Ferguson 1024?
Rated engine output for the Massey Ferguson 1024 is 127 hp, delivered by a 6-cylinder engine. The engine displaces 353.9 ci.
What is the operating weight of the Massey Ferguson 1024?
The Massey Ferguson 1024 has an operating weight of about 11,025 lb.
Which transmission does the Massey Ferguson 1024 use?
The Massey Ferguson 1024 is equipped with a Manual transmission with 12 forward gears.
How do I maintain a Massey Ferguson 1024?
Routine service for the Massey Ferguson 1024 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
