Utility tractorsSpec sheet
Massey Ferguson 396
The Massey Ferguson 396 is a utility tractor built for hard work on the farm. It has a strong Perkins engine with 6 cylinders and 89.4 horsepower. This engine is very powerful compared to other tractors. The tractor runs on diesel fuel and has a liquid-cooled system to keep it from getting too hot. This tractor has a 2-wheel drive system and power steering, making it easy to control. It has 12 forward gears and 4 reverse gears, giving the driver lots of options for different tasks. The hydraulic system is very strong, with high pressure that helps lift heavy loads. The tractor can be used with a cab or a roll-over protection system (ROPS) to keep the driver safe. It also has big agricultural tires that work well in fields.
ManufacturerMassey FergusonPower89.4 hp(66.7 kW)Class60–100 HP tractors →Engine6-cylinderTransmissionSelective gear fixed ratio
Key specifications
- Category
- Utility
- Engine power
- 89hp
- Transmission
- Selective gear fixed ratio
Category comparison
396 compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
89.4 hp · 77th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 396 ranks at the 77th percentile for engine power among recorded utility tractors.
Overview
About the Massey Ferguson 396
The Massey Ferguson 396 is a utility tractor built for hard work on the farm. It has a strong Perkins engine with 6 cylinders and 89.4 horsepower. This engine is very powerful compared to other tractors. The tractor runs on diesel fuel and has a liquid-cooled system to keep it from getting too hot. This tractor has a 2-wheel drive system and power steering, making it easy to control. It has 12 forward gears and 4 reverse gears, giving the driver lots of options for different tasks. The hydraulic system is very strong, with high pressure that helps lift heavy loads. The tractor can be used with a cab or a roll-over protection system (ROPS) to keep the driver safe. It also has big agricultural tires that work well in fields.
Full specifications
Recorded specifications
General
| Manufacturer | Massey Ferguson |
|---|---|
| Model | 396 |
| Category | Utility tractor |
| Type | 4x2 2WD |
Engine
| Make | Perkins |
|---|---|
| Model | 1006 |
| Power | 89.4hp(66.67 kW) |
| Cylinders | 6 |
| Displacement | 365ci(5.98 L) |
| Bore | 3.94in(100 mm) |
| Stroke | 5in(127 mm) |
Transmission
| Type | Selective gear fixed ratio |
|---|---|
| Forward gears | 12 |
| Reverse gears | 4 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power |
| Cab | ROPS / Cab |
Hydraulics
| Type | Open Center |
|---|---|
| Pump flow | 7.1gpm(26.88 L/min) |
| Pressure | 3,050psi(21,030 kPa) |
Dimensions
| Width | 87.2in(2,215 mm) |
|---|---|
| Height | 107.5in(2,731 mm) |
Capacities
| Cooling system | 5.3gal(20.06 L) |
|---|
Closest alternatives
396 compared with the nearest models by horsepower
The closest utility models to the Massey Ferguson 396 by rated horsepower are the John Deere 5100E and the Kioti DX9010. The John Deere 5100E matches it on rated power. The Kioti DX9010 matches it on rated power.
| Spec | Massey Ferguson 396 | John Deere 5100E | Kioti DX9010 |
|---|---|---|---|
| Engine power | 89.4 hp66.7 kW | 89.5 hp66.7 kW | 89.2 hp66.5 kW |
| Operating weight | - | 7,940 lb3,602 kg | 8,002 lb3,630 kg |
| Weight per hp | - | 89 lb/hp54 kg/kW | 90 lb/hp55 kg/kW |
| Displacement | 365 ci5.98 L | 276 ci4.52 L | 268.5 ci4.4 L |
| Cylinders | 6 | 4 | 4 |
| Transmission | Selective gear fixed ratio | Selective gear fixed ratio | Power shuttle |
| Drive | 2WD | - | 4WD |
Calculators
Calculators for the 396
PTO power
About 74 to 80 PTO hp
Estimated from the 89.4 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 89.4 hp tractor can run
Maximum size is about a 10.5 ft rotary cutter or a 9 ft tiller. The calculator also sizes discs, plows and balers.
Units
89.4 hp is 66.7 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
396 vs. Utility median
Massey Ferguson 396 compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 89.4 hp | 55 hp | +63% | 77th |
| Engine Displacement | 365 ci | 183 ci | +99% | 88th |
| Cylinders | 6 | 4 | +50% | 93rd |
| Forward Gears | 12 | 12 | at median | 50th |
| Width | 87.2 in | 66 in | +32% | 90th |
| Height | 108 in | 94.1 in | +14% | 83rd |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 3,933–5,720 models).
Same manufacturer
Other Massey Ferguson models
Other manufacturers
Models with similar horsepower
Gallery
Massey Ferguson 396 photos
FAQ
Frequently asked questions
How much horsepower does the Massey Ferguson 396 have?
The Massey Ferguson 396 produces 89.4 hp from its 6-cylinder engine. Engine displacement is 365 ci.
What transmission is in the Massey Ferguson 396?
Transmission on the Massey Ferguson 396 is Selective gear fixed ratio, with 12 forward speeds.
What type of hydraulic system does the Massey Ferguson 396 use?
Hydraulics on the Massey Ferguson 396 are Open Center, delivering 7.1 gpm of pump flow.
What hitch category is the Massey Ferguson 396?
The Massey Ferguson 396 uses a Category Category 3 hitch.
What maintenance does the Massey Ferguson 396 require?
The Massey Ferguson 396 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
