UtilityPerformance profile
McCormick Intl CTJ23
The McCormick Intl CTJ23 is a compact utility tractor built for versatility and efficiency. It features a 4-wheel drive system and power steering, making it easy to handle in various conditions. The tractor uses a hydrostatic transmission with infinite forward and reverse speeds in two ranges, giving operators smooth and precise control. Under the hood, the CTJ23 is powered by a Mitsubishi S3L diesel engine. This 3-cylinder, liquid-cooled engine has a displacement of 68.7 cubic inches, which is below average for its class. It produces 23 horsepower at 2700 rpm, which is suitable for light to medium-duty tasks. The tractor's compact size, measuring 103 inches long, 46 inches wide, and 85 inches tall, allows it to work in tight spaces. With an operating weight of 1609 pounds, it's one of the lighter tractors in its category. The CTJ23 comes equipped with industrial tires, a rear Type I hitch, and an open operator station with a rollover protection structure (ROPS) for safety.
ManufacturerMcCormick IntlPower23 hpEngine3-cylTransHydrostatic
Quick specs
- Category
- Utility
- Engine Power Output
- 23hp
- Operating Weight
- 1,609 lb
- Transmission
- Hydrostatic
At a glance
How the CTJ23 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
23 hp · 12th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The CTJ23 ranks at the 12th percentile for engine power among recorded utility tractors.
Overview
About the McCormick Intl CTJ23
The McCormick Intl CTJ23 is a compact utility tractor built for versatility and efficiency. It features a 4-wheel drive system and power steering, making it easy to handle in various conditions. The tractor uses a hydrostatic transmission with infinite forward and reverse speeds in two ranges, giving operators smooth and precise control. Under the hood, the CTJ23 is powered by a Mitsubishi S3L diesel engine. This 3-cylinder, liquid-cooled engine has a displacement of 68.7 cubic inches, which is below average for its class. It produces 23 horsepower at 2700 rpm, which is suitable for light to medium-duty tasks. The tractor's compact size, measuring 103 inches long, 46 inches wide, and 85 inches tall, allows it to work in tight spaces. With an operating weight of 1609 pounds, it's one of the lighter tractors in its category. The CTJ23 comes equipped with industrial tires, a rear Type I hitch, and an open operator station with a rollover protection structure (ROPS) for safety.
Full specifications
Every recorded spec
General
| Manufacturer | McCormick Intl |
|---|---|
| Model | CTJ23 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 1,609lb |
Engine
| Make | Mitsubishi |
|---|---|
| Model | S3L |
| Power | 23hp |
| Cylinders | 3 |
| Displacement | 68.7ci |
| Bore | 3.07in |
| Stroke | 3.61in |
Transmission
| Type | Hydrostatic |
|---|
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
| Cab | Open with ROPS |
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 103in |
|---|---|
| Width | 46in |
| Height | 85in |
| Operating weight | 1,609lb |
Head to head
CTJ23 vs. Utility median
How the McCormick Intl CTJ23 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 23 hp | 55 hp | -58% | 12th |
| Engine Displacement | 68.7 ci | 183 ci | -62% | 9th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Operating Weight | 1,609 lb | 5,303 lb | -70% | 7th |
| Length | 103 in | 137 in | -25% | 10th |
| Width | 46 in | 66 in | -30% | 12th |
| Height | 85 in | 94.1 in | -10% | 33rd |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared McCormick Intl tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| McCormick Intl X10.25H | 22 hp | 2,138 lb | — | Compare → |
| McCormick Intl G25 | 21 hp | 1,323 lb | — | Compare → |
| McCormick Intl CTJ27 | 27 hp | 1,609 lb | — | Compare → |
| McCormick Intl CT28 | 28 hp | 2,645 lb | — | Compare → |
| McCormick Intl CTV28 | 28 hp | 2,645 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Bolens HT23 | 23 hp | 1,098 lb | 1979–1987 | Compare → |
| Allis Chalmers CA | 23.1 hp | 2,835 lb | 1950–1958 | Compare → |
| AGCO ST22A | 22.5 hp | 1,600 lb | — | Compare → |
| AGCO ST24A | 22.5 hp | 1,800 lb | — | Compare → |
| Ag King AK2840 | 24 hp | 2,900 lb | — | Compare → |
Explore
McCormick Intl siblings
Explore
Similar-spec models
Gallery
McCormick Intl CTJ23 photos
FAQ
Common questions
How powerful is the McCormick Intl CTJ23?
The McCormick Intl CTJ23 has an engine power output of 23 hp. It is powered by a 3-cylinder engine displacing 68.7 ci.
What type of hydraulic system does the McCormick Intl CTJ23 use?
Hydraulics on the McCormick Intl CTJ23 are Open center.
What is the working weight of the McCormick Intl CTJ23?
The operating weight of the McCormick Intl CTJ23 is approximately 1,609 lb.
What type of transmission does the McCormick Intl CTJ23 have?
The McCormick Intl CTJ23 uses a Hydrostatic transmission.
What routine service does the McCormick Intl CTJ23 need?
Regular maintenance for the McCormick Intl CTJ23 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
