Row CropPerformance profile
McCormick Intl MTX200
The McCormick Intl MTX200 is a powerful row crop tractor built for serious farming. It has a strong 4-wheel drive system and a smooth powershift transmission with 32 forward gears and 24 reverse gears. This gives farmers lots of options for different tasks. Under the hood, the MTX200 has a Cummins QSB diesel engine with 6 cylinders and 24 valves. The engine is turbocharged and liquid-cooled, producing 204 horsepower. This power output is above average compared to other tractors. The engine size is average, but it runs at a higher than average speed of 2200 rpm. The tractor is quite heavy, weighing 17000 lb, which is above average for its class. It has a Category III hitch for attaching large implements. This tractor is designed for comfort and ease of use. It has hydrostatic power steering and a pressure flow compensating hydraulic system. The MTX200 runs on 12-volt electrical systems and has an electric starter. With its mix of power and features, this McCormick tractor is well-suited for a variety of demanding farm tasks.
ManufacturerMcCormick IntlPower204 hpEngine6-cylTransPowershift
Quick specs
- Category
- Row Crop
- Engine Power Output
- 204hp
- Operating Weight
- 17,000 lb
- Transmission
- Powershift
At a glance
How the MTX200 compares
vs. Row Crop medianDistribution
Engine Power (hp)
Across all Row Crop tractors
204 hp · 77th
This model
12
Median 138 hp
283
This modelRow Crop tractorsMediann = 1,206
The MTX200 ranks at the 77th percentile for engine power among recorded row crop tractors.
Overview
About the McCormick Intl MTX200
The McCormick Intl MTX200 is a powerful row crop tractor built for serious farming. It has a strong 4-wheel drive system and a smooth powershift transmission with 32 forward gears and 24 reverse gears. This gives farmers lots of options for different tasks. Under the hood, the MTX200 has a Cummins QSB diesel engine with 6 cylinders and 24 valves. The engine is turbocharged and liquid-cooled, producing 204 horsepower. This power output is above average compared to other tractors. The engine size is average, but it runs at a higher than average speed of 2200 rpm. The tractor is quite heavy, weighing 17000 lb, which is above average for its class. It has a Category III hitch for attaching large implements. This tractor is designed for comfort and ease of use. It has hydrostatic power steering and a pressure flow compensating hydraulic system. The MTX200 runs on 12-volt electrical systems and has an electric starter. With its mix of power and features, this McCormick tractor is well-suited for a variety of demanding farm tasks.
Full specifications
Every recorded spec
General
| Manufacturer | McCormick Intl |
|---|---|
| Model | MTX200 |
| Category | Row Crop tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 17,000lb |
Engine
| Make | Cummins |
|---|---|
| Model | QSB |
| Power | 204hp |
| Cylinders | 6 |
| Displacement | 359ci |
| Bore | 4.02in |
| Stroke | 4.72in |
Transmission
| Type | Powershift |
|---|---|
| Forward gears | 32 |
| Reverse gears | 24 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
Hydraulics
| Type | Pressure flow compensating |
|---|
Dimensions
| Length | 205.91in |
|---|---|
| Operating weight | 17,000lb |
Head to head
MTX200 vs. Row Crop median
How the McCormick Intl MTX200 compares to other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 204 hp | 138 hp | +48% | 77th |
| Engine Displacement | 359 ci | 391 ci | -8% | 41st |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 32 | 16 | +100% | 91st |
| Operating Weight | 17,000 lb | 12,307 lb | +38% | 74th |
| Length | 206 in | 180 in | +15% | 81st |
Medians and percentiles are computed from the row crop tractors in our database with a recorded value for each spec (sample sizes 1,157–1,417 models).
Compare to tractors with similar specs
Commonly compared McCormick Intl tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| McCormick Intl MTX185 | 195.8 hp | 16,010 lb | — | Compare → |
| McCormick Intl XTX200 | 195.8 hp | 15,880 lb | — | Compare → |
| McCormick Intl TTX230 | 213 hp | 15,884 lb | — | Compare → |
| McCormick Intl X70.80 | 214 hp | 16,980 lb | — | Compare → |
| McCormick Intl XTX215 | 193 hp | 16,010 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH 8940 Magnum | 205 hp | 18,170 lb | 1997–1998 | Compare → |
| CaseIH 3594 | 202 hp | 17,590 lb | 1985–1988 | Compare → |
| AGCO RT165A | 200 hp | 17,460 lb | — | Compare → |
| CaseIH 9110 | 200 hp | 17,000 lb | — | Compare → |
| Allis Chalmers 7080 | 210 hp | 13,638 lb | 1975–1981 | Compare → |
Explore
McCormick Intl siblings
Explore
Similar-spec models
Gallery
McCormick Intl MTX200 photos
FAQ
Common questions
How much horsepower does the McCormick Intl MTX200 have?
The McCormick Intl MTX200 produces 204 hp from its 6-cylinder engine. Engine displacement is 359 ci.
How much does the McCormick Intl MTX200 weigh?
The McCormick Intl MTX200 weighs about 17,000 lb in operating condition.
What transmission is in the McCormick Intl MTX200?
Transmission on the McCormick Intl MTX200 is Powershift, with 32 forward speeds.
What hydraulics does the McCormick Intl MTX200 have?
The McCormick Intl MTX200 uses a Pressure flow compensating hydraulic system.
What three-point hitch category does the McCormick Intl MTX200 use?
The McCormick Intl MTX200 has a Category III three-point hitch.
What maintenance does the McCormick Intl MTX200 require?
Like any tractor, the McCormick Intl MTX200 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
