McCormick Intl XTX165
The McCormick Intl XTX165 is a powerful 4WD tractor built for tough farm work. It has a strong diesel engine with 6 cylinders and 162 horsepower. This engine is turbocharged and liquid-cooled, which helps it run smoothly in various conditions. The tractor has a partial power shift transmission with 48 forward gears and 40 reverse gears, giving the driver lots of options for different tasks. This tractor is big and sturdy, measuring 205 inches long, 98 inches wide, and 114 inches tall. It weighs 14,330 pounds, making it a heavy-duty machine. The XTX165 has large 38-inch tires on both the front and back, which helps it handle rough terrain. It also has a closed center hydraulic system and a category 3 hitch at the rear for attaching various farm tools. The driver sits in a comfortable cab, protected from the elements while working.
ManufacturerMcCormick IntlPower162 hpEngine6-cylTransPartial Power Shift
Quick specs
- Category
- Agricultural
- Engine Power Output
- 162hp
- Operating Weight
- 14,330 lb
- Transmission
- Partial Power Shift
At a glance
How the XTX165 compares
vs. Agricultural medianDistribution
Engine Power (hp)
Across all Agricultural tractors
162 hp · 72nd
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The XTX165 ranks at the 72nd percentile for engine power among recorded agricultural tractors.
Overview
About the McCormick Intl XTX165
The McCormick Intl XTX165 is a powerful 4WD tractor built for tough farm work. It has a strong diesel engine with 6 cylinders and 162 horsepower. This engine is turbocharged and liquid-cooled, which helps it run smoothly in various conditions. The tractor has a partial power shift transmission with 48 forward gears and 40 reverse gears, giving the driver lots of options for different tasks. This tractor is big and sturdy, measuring 205 inches long, 98 inches wide, and 114 inches tall. It weighs 14,330 pounds, making it a heavy-duty machine. The XTX165 has large 38-inch tires on both the front and back, which helps it handle rough terrain. It also has a closed center hydraulic system and a category 3 hitch at the rear for attaching various farm tools. The driver sits in a comfortable cab, protected from the elements while working.
Full specifications
Every recorded spec
General
| Manufacturer | McCormick Intl |
|---|---|
| Model | XTX165 |
| Category | Agricultural tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 14,330lb |
Engine
| Make | McCormick Intl |
|---|---|
| Power | 162hp |
| Cylinders | 6 |
| Displacement | 410.6ci |
Transmission
| Type | Partial Power Shift |
|---|---|
| Forward gears | 48 |
| Reverse gears | 40 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Cab | Cab |
Hydraulics
| Type | Closed Center |
|---|
Dimensions
| Length | 205in |
|---|---|
| Width | 98in |
| Height | 114in |
| Operating weight | 14,330lb |
Tires
| Rear | 38 |
|---|
Head to head
XTX165 vs. Agricultural median
How the McCormick Intl XTX165 compares to other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 162 hp | 110 hp | +47% | 72nd |
| Engine Displacement | 411 ci | 336 ci | +22% | 70th |
| Cylinders | 6 | 5.5 | +9% | 74th |
| Forward Gears | 48 | 16 | +200% | 99th |
| Operating Weight | 14,330 lb | 10,914 lb | +31% | 67th |
| Length | 205 in | 173 in | +19% | 81st |
| Width | 98 in | 79.5 in | +23% | 79th |
| Height | 114 in | 111 in | +3% | 60th |
Medians and percentiles are computed from the agricultural tractors in our database with a recorded value for each spec (sample sizes 497–1,130 models).
Compare to tractors with similar specs
Commonly compared McCormick Intl tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| McCormick Intl XTX145 | 145 hp | 14,330 lb | — | Compare → |
| McCormick Intl X6.440 | 130 hp | 10,362 lb | — | Compare → |
| McCormick Intl TTX210 | 198 hp | 15,884 lb | — | Compare → |
| McCormick Intl F120 | 110.2 hp | 5,600 lb | — | Compare → |
| McCormick Intl F110 | 102 hp | 6,316 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO RT155A | 162.5 hp | — | — | Compare → |
| Agrinar T-160 | 161 hp | 13,450 lb | — | Compare → |
| Allis Chalmers HD16A | 163 hp | 31,500 lb | — | Compare → |
| AGCO DT160 | 160 hp | 18,500 lb | 2002–2004 | Compare → |
| Belarus 1507 | 165 hp | 20,283 lb | — | Compare → |
Explore
McCormick Intl siblings
Explore
Similar-spec models
Gallery
McCormick Intl XTX165 photos
FAQ
Common questions
How much horsepower does the McCormick Intl XTX165 have?
The McCormick Intl XTX165 produces 162 hp from its 6-cylinder engine. Engine displacement is 410.6 ci.
What transmission is in the McCormick Intl XTX165?
Transmission on the McCormick Intl XTX165 is Partial Power Shift, with 48 forward speeds.
What type of hydraulic system does the McCormick Intl XTX165 use?
Hydraulics on the McCormick Intl XTX165 are Closed Center.
What size tires does the McCormick Intl XTX165 use?
Factory rubber for the McCormick Intl XTX165 is 38 rear tires.
What hitch category is the McCormick Intl XTX165?
The McCormick Intl XTX165 uses a Category 3 hitch.
How much does the McCormick Intl XTX165 weigh?
The McCormick Intl XTX165 weighs about 14,330 lb in operating condition.
What maintenance does the McCormick Intl XTX165 require?
Like any tractor, the McCormick Intl XTX165 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
