UtilityPerformance profile
Steiger Cougar IV CM-280
The Steiger Cougar IV CM-280 is a powerful utility tractor built for tough jobs. It has a strong 4x4 drive system and can turn easily with its special steering. The tractor has a big Caterpillar diesel engine with 6 cylinders and 280 horsepower. This engine is very large compared to most tractors, making it great for heavy work. This tractor is big and heavy, weighing 25,011 pounds. It has a gear transmission with 20 forward speeds and 4 reverse speeds, giving the driver lots of options. The Cougar IV CM-280 has a comfortable cab for the driver and big 38-inch tires for working in fields. It also has a three-point hitch in the back for attaching tools. The tractor is about 21 feet long, 8 feet wide, and 13 feet tall, making it a large machine that can handle big farm tasks.
ManufacturerSteigerPower280 hpEngine6-cylTransGear
Quick specs
- Category
- Utility
- Engine Power Output
- 280hp
- Operating Weight
- 25,011 lb
- Transmission
- Gear
At a glance
How the Cougar IV CM-280 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
280 hp · 96th
This model
9
Median 55 hp
177
280
This modelUtility tractorsMediann = 5,383
The Cougar IV CM-280 ranks at the 96th percentile for engine power among recorded utility tractors.
Overview
About the Steiger Cougar IV CM-280
The Steiger Cougar IV CM-280 is a powerful utility tractor built for tough jobs. It has a strong 4x4 drive system and can turn easily with its special steering. The tractor has a big Caterpillar diesel engine with 6 cylinders and 280 horsepower. This engine is very large compared to most tractors, making it great for heavy work. This tractor is big and heavy, weighing 25,011 pounds. It has a gear transmission with 20 forward speeds and 4 reverse speeds, giving the driver lots of options. The Cougar IV CM-280 has a comfortable cab for the driver and big 38-inch tires for working in fields. It also has a three-point hitch in the back for attaching tools. The tractor is about 21 feet long, 8 feet wide, and 13 feet tall, making it a large machine that can handle big farm tasks.
Full specifications
Every recorded spec
General
| Manufacturer | Steiger |
|---|---|
| Model | Cougar IV CM-280 |
| Category | Utility tractor |
| Type | 4x4 articulated 4WD |
| Operating weight | 25,011lb |
Engine
| Make | Caterpillar |
|---|---|
| Model | 3406 |
| Power | 280hp |
| Cylinders | 6 |
| Displacement | 893ci |
| Bore | 5.4in |
| Stroke | 6.5in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 20 |
| Reverse gears | 4 |
Chassis & drive
| Chassis | 4x4 articulated 4WD |
|---|---|
| Drive | 4WD |
| Steering | Articulated power |
| Cab | Cab |
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 253.6in |
|---|---|
| Width | 96in |
| Height | 155.8in |
| Operating weight | 25,011lb |
Capacities
| Cooling system | 17.5gal |
|---|
Head to head
Cougar IV CM-280 vs. Utility median
How the Steiger Cougar IV CM-280 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 280 hp | 55 hp | +409% | 96th |
| Engine Displacement | 893 ci | 183 ci | +388% | 98th |
| Cylinders | 6 | 4 | +50% | 93rd |
| Forward Gears | 20 | 12 | +67% | 86th |
| Operating Weight | 25,011 lb | 5,303 lb | +372% | 96th |
| Length | 254 in | 137 in | +86% | 97th |
| Width | 96 in | 66 in | +45% | 95th |
| Height | 156 in | 94.1 in | +66% | 99th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Steiger tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Steiger 9150 | 280 hp | 23,000 lb | — | Compare → |
| Steiger Cougar 1000 | 280 hp | 23,000 lb | — | Compare → |
| Steiger Cougar CR-1280 | 280 hp | 23,400 lb | — | Compare → |
| Steiger Cougar III PTA-280 | 280 hp | 27,600 lb | — | Compare → |
| Steiger Cougar IV CS-280 | 280 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH 9150 | 280 hp | 23,000 lb | — | Compare → |
| AGCO DT240A | 290 hp | 19,951 lb | 2005–2008 | Compare → |
| AGCO DT250B | 290 hp | 25,960 lb | 2009–2010 | Compare → |
| Baldwin DM300 | 290 hp | — | — | Compare → |
| AGCO DT225B | 266.3 hp | 25,795 lb | 2009–2010 | Compare → |
Explore
Steiger siblings
Explore
Similar-spec models
Gallery
Steiger Cougar IV CM-280 photos
FAQ
Common questions
How powerful is the Steiger Cougar IV CM-280?
The Steiger Cougar IV CM-280 has an engine power output of 280 hp. It is powered by a 6-cylinder engine displacing 893 ci.
What hitch category is the Steiger Cougar IV CM-280?
The Steiger Cougar IV CM-280 uses a Category III hitch.
What is the working weight of the Steiger Cougar IV CM-280?
The operating weight of the Steiger Cougar IV CM-280 is approximately 25,011 lb.
What type of transmission does the Steiger Cougar IV CM-280 have?
The Steiger Cougar IV CM-280 uses a Gear transmission offering 20 forward gears.
What type of hydraulic system does the Steiger Cougar IV CM-280 use?
Hydraulics on the Steiger Cougar IV CM-280 are Open center.
What routine service does the Steiger Cougar IV CM-280 need?
Regular maintenance for the Steiger Cougar IV CM-280 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
