Steiger Cougar IV CM-280

Steiger Cougar IV CM-280

Complete specifications and technical data for the Steiger Cougar IV CM-280. Compare with similar tractors from Steiger and other manufacturers.

Jump to Full Specifications List

Quick Specs

Category

Utility

Engine Power Output

280hp

Operating Weight

25,011 lb

Transmission

Gear

The Steiger Cougar IV CM-280 is a powerful utility tractor built for tough jobs. It has a strong 4x4 drive system and can turn easily with its special steering. The tractor has a big Caterpillar diese...

Photo Gallery

Image Gallery
Steiger Cougar IV CM-280 Tractor
Steiger Cougar IV CM-280 Tractor
Steiger Cougar IV CM-280 Tractor

Specifications

Manufacturer
Steiger
Model
Cougar IV CM-280
Category
Utility
Manufacturer
Caterpillar
Model
3406
Power Output
280hp
Rated RPM
2,100RPM
Cylinders
6
Displacement
893ci
Bore
5.4in
Stroke
6.5in

Engine Power Output Comparison of Steiger Cougar IV CM-280 vs. Other Utility Tractors

Loading Chart...

Type
Gear
Length
253.6in
Width
96in
Height
155.8in
Operating Weight
25,011lb

Operating Weight Comparison of Steiger Cougar IV CM-280 vs. Other Utility Tractors

Loading Chart...

System Type
Open center
Steering Type
Articulated power
Hitch Type
Three-Point Hitch
Hitch Category
III
Hitch Position
Rear
Chassis Type
4x4 articulated 4WD
Drive Type
4WD
Steering Type
Articulated power
Coolant
70qts
Type
Cab

Compare to Other Tractors

Frequently Asked Questions

What is the engine power output of the Steiger Cougar IV CM-280?

The Steiger Cougar IV CM-280 has an engine power output of 280 hp.

How many cylinders does the Steiger Cougar IV CM-280 have?

The Steiger Cougar IV CM-280 is equipped with a 6-cylinder engine.

What is the operating weight of the Steiger Cougar IV CM-280?

The operating weight of the Steiger Cougar IV CM-280 is approximately 25,011 lb.

What type of transmission does the Steiger Cougar IV CM-280 have?

The Steiger Cougar IV CM-280 is equipped with a Gear transmission.

What type of hydraulic system does the Steiger Cougar IV CM-280 use?

The Steiger Cougar IV CM-280 uses a Open center hydraulic system.

What hitch category is the Steiger Cougar IV CM-280?

The Steiger Cougar IV CM-280 is a Category III hitch.

What maintenance does the Steiger Cougar IV CM-280 require?

Regular maintenance for the Steiger Cougar IV CM-280 includes checking and changing engine oil, hydraulic fluid, filters, and performing routine inspections as recommended in the owner's manual. Always refer to the manufacturer's maintenance schedule for specific intervals and procedures.
