UtilityPerformance profile
TYM 2810
The TYM 2810 is a utility tractor made from 2002 to 2006. It's a compact but capable machine, perfect for small farms and big gardens. The tractor has a 4-wheel drive system and hydrostatic power steering, making it easy to control in tight spaces. Under the hood, the TYM 2810 has a Daedong 3A139 diesel engine. This engine has 3 cylinders and puts out 28 horsepower, which is below average for tractors but enough for many tasks. It's cooled by liquid and doesn't use a turbocharger. The tractor has a 12-speed transmission for both forward and reverse, giving the driver lots of options. It also has a three-point hitch in the back for attaching tools, and a power take-off (PTO) that spins at 540 rpm for running equipment. The TYM 2810 weighs 3,064 pounds, which is on the lighter side for tractors, and it's 51.8 inches wide and 93.1 inches tall.
ManufacturerTYMPower28 hpEngine3-cylTransSynchromesh shuttle
Quick specs
- Category
- Utility
- Engine Power Output
- 28hp
- Operating Weight
- 3,064 lb
- Transmission
- Synchromesh shuttle
At a glance
How the 2810 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
28 hp · 20th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 2810 ranks at the 20th percentile for engine power among recorded utility tractors.
Overview
About the TYM 2810
The TYM 2810 is a utility tractor made from 2002 to 2006. It's a compact but capable machine, perfect for small farms and big gardens. The tractor has a 4-wheel drive system and hydrostatic power steering, making it easy to control in tight spaces. Under the hood, the TYM 2810 has a Daedong 3A139 diesel engine. This engine has 3 cylinders and puts out 28 horsepower, which is below average for tractors but enough for many tasks. It's cooled by liquid and doesn't use a turbocharger. The tractor has a 12-speed transmission for both forward and reverse, giving the driver lots of options. It also has a three-point hitch in the back for attaching tools, and a power take-off (PTO) that spins at 540 rpm for running equipment. The TYM 2810 weighs 3,064 pounds, which is on the lighter side for tractors, and it's 51.8 inches wide and 93.1 inches tall.
Full specifications
Every recorded spec
General
| Manufacturer | TYM |
|---|---|
| Model | 2810 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Years built | 2002–2006 |
| Operating weight | 3,064lb |
Engine
| Make | Daedong |
|---|---|
| Model | 3A139 |
| Power | 28hp |
| Cylinders | 3 |
| Displacement | 85ci |
| Bore | 3.15in |
| Stroke | 3.64in |
Transmission
| Type | Synchromesh shuttle |
|---|---|
| Forward gears | 12 |
| Reverse gears | 12 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
| Brakes | Wet disc |
| Cab | Open |
Hydraulics
| Type | Open center |
|---|
Power take-off
| Rear PTO | Independent |
|---|---|
| PTO speed | 540rpm |
Dimensions
| Width | 51.8in |
|---|---|
| Height | 93.1in |
| Operating weight | 3,064lb |
Capacities
| Cooling system | 3.35gal |
|---|
Head to head
2810 vs. Utility median
How the TYM 2810 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 28 hp | 55 hp | -49% | 20th |
| Engine Displacement | 85 ci | 183 ci | -54% | 14th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 12 | 12 | at median | 50th |
| Operating Weight | 3,064 lb | 5,303 lb | -42% | 24th |
| Width | 51.8 in | 66 in | -22% | 20th |
| Height | 93.1 in | 94.1 in | -1% | 48th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared TYM tractors
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO ST28A | 28.4 hp | 2,400 lb | — | Compare → |
| AGCO ST30x | 28.4 hp | 1,984 lb | — | Compare → |
| Allis Chalmers D272 | 27.5 hp | 2,060 lb | — | Compare → |
| Ascot Universal 300 | 27.5 hp | 3,800 lb | — | Compare → |
| Allis Chalmers D10 | 28.57 hp | 2,700 lb | 1959–1967 | Compare → |
Explore
TYM siblings
Explore
Similar-spec models
Gallery
TYM 2810 photos
FAQ
Common questions
When was the TYM 2810 made?
The TYM 2810 was manufactured from 2002 to 2006.
What is the engine power output of the TYM 2810?
Rated engine output for the TYM 2810 is 28 hp, delivered by a 3-cylinder engine. The engine displaces 85 ci.
What is the operating weight of the TYM 2810?
In working trim, the TYM 2810 comes in at roughly 3,064 lb.
Which transmission does the TYM 2810 use?
The TYM 2810 is equipped with a Synchromesh shuttle transmission with 12 forward gears.
What hydraulics does the TYM 2810 have?
The TYM 2810 uses an Open center hydraulic system.
What three-point hitch category does the TYM 2810 use?
The TYM 2810 has a Category I three-point hitch.
How do I maintain a TYM 2810?
Routine service for the TYM 2810 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
