UtilityPerformance profile
Yanmar F320
The Yanmar F320 is a utility tractor that packs a lot of power in a compact size. It has a 32 hp diesel engine with three cylinders, which is average for its class. The engine is made by Yanmar, a well-known Japanese company that's been making tractors for many years. This tractor is easy to drive, with a synchromesh transmission that has 9 forward gears and 3 reverse gears. It's small enough to fit in tight spaces, measuring about 129 inches long, 57 inches wide, and 92 inches tall. The F320 weighs 2,977 pounds, which is on the lighter side for tractors. It has a rear hitch for attaching tools and a wheelbase of 67.5 inches, making it stable and easy to maneuver. The rear tires are 24 inches in diameter, helping it handle different types of ground.
ManufacturerYanmarPower32 hpEngine3-cylTransSynchromesh
Quick specs
- Category
- Utility
- Engine Power Output
- 32hp
- Operating Weight
- 2,977 lb
- Transmission
- Synchromesh
At a glance
How the F320 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
32 hp · 24th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The F320 ranks at the 24th percentile for engine power among recorded utility tractors.
Overview
About the Yanmar F320
The Yanmar F320 is a utility tractor that packs a lot of power in a compact size. It has a 32 hp diesel engine with three cylinders, which is average for its class. The engine is made by Yanmar, a well-known Japanese company that's been making tractors for many years. This tractor is easy to drive, with a synchromesh transmission that has 9 forward gears and 3 reverse gears. It's small enough to fit in tight spaces, measuring about 129 inches long, 57 inches wide, and 92 inches tall. The F320 weighs 2,977 pounds, which is on the lighter side for tractors. It has a rear hitch for attaching tools and a wheelbase of 67.5 inches, making it stable and easy to maneuver. The rear tires are 24 inches in diameter, helping it handle different types of ground.
Full specifications
Every recorded spec
General
| Manufacturer | Yanmar |
|---|---|
| Model | F320 |
| Category | Utility tractor |
| Operating weight | 2,977lb |
Engine
| Make | Yanmar |
|---|---|
| Power | 32hp |
| Cylinders | 3 |
| Displacement | 91.3ci |
| Bore | 3.31in |
| Stroke | 3.54in |
Transmission
| Type | Synchromesh |
|---|---|
| Forward gears | 9 |
| Reverse gears | 3 |
Dimensions
| Length | 128.9in |
|---|---|
| Width | 57.3in |
| Height | 91.9in |
| Operating weight | 2,977lb |
Head to head
F320 vs. Utility median
How the Yanmar F320 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 32 hp | 55 hp | -42% | 24th |
| Engine Displacement | 91.3 ci | 183 ci | -50% | 17th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 9 | 12 | -25% | 35th |
| Operating Weight | 2,977 lb | 5,303 lb | -44% | 22nd |
| Length | 129 in | 137 in | -6% | 40th |
| Width | 57.3 in | 66 in | -13% | 32nd |
| Height | 91.9 in | 94.1 in | -2% | 45th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Yanmar tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Yanmar EX3200 | 32 hp | 2,550 lb | — | Compare → |
| Yanmar FX32D | 32 hp | — | — | Compare → |
| Yanmar YM3220 | 32 hp | 3,219 lb | 1982–1983 | Compare → |
| Yanmar FV-330 | 32.6 hp | — | 1992–1998 | Compare → |
| Yanmar SX3100 | 31.2 hp | 2,030 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO ST32 | 33 hp | 2,642 lb | — | Compare → |
| AGCO ST33A | 33 hp | 2,400 lb | — | Compare → |
| AGCO ST34A | 33 hp | 3,000 lb | — | Compare → |
| AGCO ST35 | 33 hp | 3,168 lb | — | Compare → |
| Allis Chalmers 5030 | 31 hp | 2,530 lb | 1979–1985 | Compare → |
Explore
Yanmar siblings
Explore
Similar-spec models
Gallery
Yanmar F320 photos
FAQ
Common questions
How powerful is the Yanmar F320?
The Yanmar F320 has an engine power output of 32 hp. It is powered by a 3-cylinder engine displacing 91.3 ci.
What is the working weight of the Yanmar F320?
The operating weight of the Yanmar F320 is approximately 2,977 lb.
What type of transmission does the Yanmar F320 have?
The Yanmar F320 uses a Synchromesh transmission offering 9 forward gears.
What routine service does the Yanmar F320 need?
Regular maintenance for the Yanmar F320 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
