Yanmar YM336
The Yanmar YM336 is a utility tractor that was made from 1980 to 1991. It's a 2WD tractor with power steering, which makes it easy to drive. The tractor has a three-speed power shift transmission with 12 forward gears and 3 reverse gears, giving the driver lots of options for different tasks. Under the hood, the YM336 has a Yanmar 3T84A-N engine. This engine is diesel-powered, liquid-cooled, and has 3 cylinders. It can produce 33 horsepower, which is below average for tractors. The engine size is also small compared to other tractors. However, the engine runs at a very high speed of 2600 rpm. The tractor has a three-point hitch at the back, which can lift up to 2115 lb. This lifting power is above average for tractors. The YM336 also has two PTO speeds: 540 rpm and 1000 rpm, making it versatile for different attachments. The tractor weighs 2627 lb, which is on the lighter side for tractors. It has a two-post ROPS (Roll-Over Protective Structure) for safety and uses agricultural tires for good traction in the fields.
ManufacturerYanmarPower33 hpEngine3-cylTransThree-speed power shift
Quick specs
- Category
- Utility
- Engine Power Output
- 33hp
- Operating Weight
- 2,627 lb
- Transmission
- Three-speed power shift
At a glance
How the YM336 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
33 hp · 25th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The YM336 ranks at the 25th percentile for engine power among recorded utility tractors.
Overview
About the Yanmar YM336
The Yanmar YM336 is a utility tractor that was made from 1980 to 1991. It's a 2WD tractor with power steering, which makes it easy to drive. The tractor has a three-speed power shift transmission with 12 forward gears and 3 reverse gears, giving the driver lots of options for different tasks. Under the hood, the YM336 has a Yanmar 3T84A-N engine. This engine is diesel-powered, liquid-cooled, and has 3 cylinders. It can produce 33 horsepower, which is below average for tractors. The engine size is also small compared to other tractors. However, the engine runs at a very high speed of 2600 rpm. The tractor has a three-point hitch at the back, which can lift up to 2115 lb. This lifting power is above average for tractors. The YM336 also has two PTO speeds: 540 rpm and 1000 rpm, making it versatile for different attachments. The tractor weighs 2627 lb, which is on the lighter side for tractors. It has a two-post ROPS (Roll-Over Protective Structure) for safety and uses agricultural tires for good traction in the fields.
Full specifications
Every recorded spec
General
| Manufacturer | Yanmar |
|---|---|
| Model | YM336 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Years built | 1980–1991 |
| Operating weight | 2,627lb |
Engine
| Make | Yanmar |
|---|---|
| Model | 3T84A-N |
| Power | 33hp |
| Cylinders | 3 |
| Displacement | 91.3ci |
| Bore | 3.31in |
| Stroke | 3.54in |
Transmission
| Type | Three-speed power shift |
|---|---|
| Forward gears | 12 |
| Reverse gears | 3 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power |
| Brakes | Mechanical drum |
| Cab | Two-post ROPS |
Power take-off
| PTO speed | 540rpm |
|---|
Dimensions
| Length | 122in |
|---|---|
| Width | 57.9in |
| Height | 77.2in |
| Operating weight | 2,627lb |
Head to head
YM336 vs. Utility median
How the Yanmar YM336 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 33 hp | 55 hp | -40% | 25th |
| Engine Displacement | 91.3 ci | 183 ci | -50% | 17th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 12 | 12 | at median | 50th |
| Operating Weight | 2,627 lb | 5,303 lb | -50% | 18th |
| Length | 122 in | 137 in | -11% | 30th |
| Width | 57.9 in | 66 in | -12% | 33rd |
| Height | 77.2 in | 94.1 in | -18% | 23rd |
| 3-Point Hitch Capacity | 2,115 lb | 3,197 lb | -34% | 24th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 1,083–5,720 models).
Compare to tractors with similar specs
Commonly compared Yanmar tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Yanmar FX335 | 33 hp | — | 1987–1992 | Compare → |
| Yanmar YM330 | 33 hp | 2,601 lb | 1978–1991 | Compare → |
| Yanmar FV-330 | 32.6 hp | — | 1992–1998 | Compare → |
| Yanmar EF334 | 33.5 hp | — | 2002–2004 | Compare → |
| Yanmar EF334V | 33.5 hp | 3,263 lb | 2005–2009 | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO ST32 | 33 hp | 2,642 lb | — | Compare → |
| AGCO ST33A | 33 hp | 2,400 lb | — | Compare → |
| AGCO ST34A | 33 hp | 3,000 lb | — | Compare → |
| AGCO ST35 | 33 hp | 3,168 lb | — | Compare → |
| Allis Chalmers U | 34.12 hp | 5,030 lb | — | Compare → |
Explore
Yanmar siblings
Explore
Similar-spec models
Gallery
Yanmar YM336 photos
FAQ
Common questions
What years was the Yanmar YM336 manufactured?
Production of the Yanmar YM336 ran from 1980 through 1991.
What is the working weight of the Yanmar YM336?
The operating weight of the Yanmar YM336 is approximately 2,627 lb.
What type of transmission does the Yanmar YM336 have?
The Yanmar YM336 uses a Three-speed power shift transmission offering 12 forward gears.
What hitch category is the Yanmar YM336?
The Yanmar YM336 uses a Category I hitch with a lift capacity of 2,115 lb.
How powerful is the Yanmar YM336?
The Yanmar YM336 has an engine power output of 33 hp. It is powered by a 3-cylinder engine displacing 91.3 ci.
What routine service does the Yanmar YM336 need?
Regular maintenance for the Yanmar YM336 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
