UtilityPerformance profile
Yanmar FX17
The Yanmar FX17 is a utility tractor designed for various farm tasks. It has a 2WD drive system, which means it's best suited for flat or gently sloping terrain. The tractor comes with a three-speed power shift transmission, offering 9 forward gears and 3 reverse gears. This gives the operator good control over speed and power for different jobs. Under the hood, the FX17 has a Yanmar diesel engine with 3 cylinders. The engine is liquid-cooled, which helps it run smoothly in different weather conditions. It produces 17 horsepower, which is on the lower end compared to other tractors. The engine size is also smaller than average, measuring 60.7 cubic inches. Despite its compact size, the FX17 is equipped with an electric starter for easy operation. Overall, this tractor is a good choice for small farms or light-duty work where a simple, reliable machine is needed.
ManufacturerYanmarPower17 hpEngine3-cylTransThree-speed power shift
Quick specs
- Category
- Utility
- Engine Power Output
- 17hp
- Transmission
- Three-speed power shift
At a glance
How the FX17 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
17 hp · 5th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The FX17 ranks at the 5th percentile for engine power among recorded utility tractors.
Overview
About the Yanmar FX17
The Yanmar FX17 is a utility tractor designed for various farm tasks. It has a 2WD drive system, which means it's best suited for flat or gently sloping terrain. The tractor comes with a three-speed power shift transmission, offering 9 forward gears and 3 reverse gears. This gives the operator good control over speed and power for different jobs. Under the hood, the FX17 has a Yanmar diesel engine with 3 cylinders. The engine is liquid-cooled, which helps it run smoothly in different weather conditions. It produces 17 horsepower, which is on the lower end compared to other tractors. The engine size is also smaller than average, measuring 60.7 cubic inches. Despite its compact size, the FX17 is equipped with an electric starter for easy operation. Overall, this tractor is a good choice for small farms or light-duty work where a simple, reliable machine is needed.
Full specifications
Every recorded spec
General
| Manufacturer | Yanmar |
|---|---|
| Model | FX17 |
| Category | Utility tractor |
| Type | 4x2 2WD |
Engine
| Make | Yanmar |
|---|---|
| Power | 17hp |
| Cylinders | 3 |
| Displacement | 60.7ci |
| Bore | 2.95in |
| Stroke | 2.75in |
Transmission
| Type | Three-speed power shift |
|---|---|
| Forward gears | 9 |
| Reverse gears | 3 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
Head to head
FX17 vs. Utility median
How the Yanmar FX17 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 17 hp | 55 hp | -69% | 5th |
| Engine Displacement | 60.7 ci | 183 ci | -67% | 6th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 9 | 12 | -25% | 35th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 4,941–5,720 models).
Compare to tractors with similar specs
Commonly compared Yanmar tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Yanmar Ke-170H | 17 hp | 1,649 lb | — | Compare → |
| Yanmar YM1700 | 17 hp | 1,918 lb | — | Compare → |
| Yanmar YM1702 | 17 hp | 2,050 lb | 1982–1983 | Compare → |
| Yanmar YM1720 | 17 hp | 2,072 lb | 1982–1983 | Compare → |
| Yanmar YM177 | 17 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Ariens GT17 | 17 hp | 926 lb | 1979–1987 | Compare → |
| Bolens G172 | 17 hp | 1,056 lb | — | Compare → |
| Bolens G174 | 17 hp | 1,144 lb | — | Compare → |
| Bolens H1704 | 17 hp | 1,268 lb | — | Compare → |
| Allis Chalmers 616 | 16.5 hp | 1,499 lb | 1972–1973 | Compare → |
Explore
Yanmar siblings
Explore
Similar-spec models
Gallery
Yanmar FX17 photos
FAQ
Common questions
How powerful is the Yanmar FX17?
The Yanmar FX17 has an engine power output of 17 hp. It is powered by a 3-cylinder engine displacing 60.7 ci.
What type of transmission does the Yanmar FX17 have?
The Yanmar FX17 uses a Three-speed power shift transmission offering 9 forward gears.
What routine service does the Yanmar FX17 need?
Regular maintenance for the Yanmar FX17 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
