Utility tractorsSpec sheet
Yanmar YM1700
The Yanmar YM1700 is a compact utility tractor designed for small farms and light work. It has a 2WD chassis and a manual steering system, making it easy to handle in tight spaces. The tractor is powered by a Yanmar 2TR17 diesel engine with two cylinders and liquid cooling. This engine produces 17 horsepower, which is on the lower end compared to other tractors. The YM1700 features a gear transmission with 8 forward and 2 reverse speeds, giving operators good control over their work pace. It has agricultural tires on both front and rear, suitable for farm use. The tractor measures 94.1 inches long, 44.1 inches wide, and 68.3 inches tall, with a ground clearance of 13.2 inches. Weighing 1,918 pounds, it's lighter than many other tractors. The YM1700 comes with a Category I hitch, common for tractors of this size, and uses a 12-volt electrical system with an electric starter for easy operation.
Key specifications
- Category
- Utility
- Engine power
- 17hp
- Operating weight
- 1,918 lb
- Transmission
- Gear
Category comparison
YM1700 compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
17 hp · 5th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The YM1700 ranks at the 5th percentile for engine power among recorded utility tractors.
Overview
About the Yanmar YM1700
The Yanmar YM1700 is a compact utility tractor designed for small farms and light work. It has a 2WD chassis and a manual steering system, making it easy to handle in tight spaces. The tractor is powered by a Yanmar 2TR17 diesel engine with two cylinders and liquid cooling. This engine produces 17 horsepower, which is on the lower end compared to other tractors. The YM1700 features a gear transmission with 8 forward and 2 reverse speeds, giving operators good control over their work pace. It has agricultural tires on both front and rear, suitable for farm use. The tractor measures 94.1 inches long, 44.1 inches wide, and 68.3 inches tall, with a ground clearance of 13.2 inches. Weighing 1,918 pounds, it's lighter than many other tractors. The YM1700 comes with a Category I hitch, common for tractors of this size, and uses a 12-volt electrical system with an electric starter for easy operation.
Full specifications
Recorded specifications
General
| Manufacturer | Yanmar |
|---|---|
| Model | YM1700 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Operating weight | 1,918lb(870 kg) |
Engine
| Make | Yanmar |
|---|---|
| Model | 2TR17 |
| Power | 17hp(12.68 kW) |
| Cylinders | 2 |
| Displacement | 62.31ci(1.02 L) |
| Bore | 3.35in(84.99 mm) |
| Stroke | 3.54in(89.99 mm) |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 8 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Manual |
Dimensions
| Length | 94.1in(2,390 mm) |
|---|---|
| Width | 44.1in(1,120 mm) |
| Height | 68.3in(1,735 mm) |
| Operating weight | 1,918lb(870 kg) |
Closest alternatives
YM1700 compared with the nearest models by horsepower
Among utility tractors, the Yanmar YM1702 and the Yanmar YM1720 are closest to the Yanmar YM1700 in rated horsepower. The Yanmar YM1702 matches it on rated power and weighs 130 lb more. The Yanmar YM1720 matches it on rated power and weighs 150 lb more, at 122 lb per horsepower against 113 lb. Of the 3 models, the YM1700 has the lowest weight per horsepower at 113 lb per hp.
| Spec | Yanmar YM1700 | Yanmar YM1702 | Yanmar YM1720 |
|---|---|---|---|
| Engine power | 17 hp12.7 kW | 17 hp12.7 kW | 17 hp12.7 kW |
| Operating weight | 1,918 lb870 kg | 2,050 lb930 kg | 2,072 lb940 kg |
| Weight per hp | 113 lb/hp69 kg/kW | 121 lb/hp73 kg/kW | 122 lb/hp74 kg/kW |
| Displacement | 62.3 ci1.02 L | 60.7 ci0.99 L | 60.7 ci0.99 L |
| Cylinders | 2 | 3 | 3 |
| Transmission | Gear | Gear with creeper option | Partial Power Shift, Creeper |
| Drive | 2WD | 2WD | 2WD |
| Years built | - | 1982-1983 | 1982-1983 |
Calculators
Calculators for the YM1700
PTO power
About 14 to 15 PTO hp
Estimated from the 17 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 17 hp tractor can run
The calculator sizes mowers, tillers, discs, plows and balers for this tractor.
Ballast
131 lb per PTO hp as listed
The calculator gives the target weight and front/rear split for each job.
Units
17 hp is 12.7 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the Yanmar YM1700
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the Yanmar 2TR17Amazon
Fits the Yanmar 2TR17 2-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the Yanmar 2TR17Amazon
Fits the Yanmar 2TR17 2-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the Yanmar 2TR17Amazon
Fits the Yanmar 2TR17 2-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the Yanmar 2TR17Amazon
Fits the Yanmar 2TR17 2-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- Yanmar YM1700 service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- Yanmar YM1700 operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- Yanmar YM1700 service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
YM1700 vs. Utility median
Yanmar YM1700 compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 17 hp | 55 hp | -69% | 5th |
| Engine Displacement | 62.3 ci | 183 ci | -66% | 7th |
| Cylinders | 2 | 4 | -50% | 3rd |
| Forward Gears | 8 | 12 | -33% | 23rd |
| Operating Weight | 1,918 lb | 5,303 lb | -64% | 11th |
| Length | 94.1 in | 137 in | -31% | 6th |
| Width | 44.1 in | 66 in | -33% | 8th |
| Height | 68.3 in | 94.1 in | -27% | 15th |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 3,933–5,720 models).
Same manufacturer
Other Yanmar models
Other manufacturers
Models with similar horsepower
Gallery
Yanmar YM1700 photos
FAQ
Frequently asked questions
What is the engine power output of the Yanmar YM1700?
Rated engine output for the Yanmar YM1700 is 17 hp, delivered by a 2-cylinder engine. The engine displaces 62.31 ci.
Which transmission does the Yanmar YM1700 use?
The Yanmar YM1700 is equipped with a Gear transmission with 8 forward gears.
What hitch category is the Yanmar YM1700?
The Yanmar YM1700 uses a Category I hitch.
What is the operating weight of the Yanmar YM1700?
The Yanmar YM1700 has an operating weight of about 1,918 lb.
How do I maintain a Yanmar YM1700?
Routine service for the Yanmar YM1700 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
