Zetor 9020
The Zetor 9020 is a powerful 2WD tractor designed for farm work. It has a 4-cylinder diesel engine that's turbocharged and liquid-cooled. This engine puts out 93 hp at 2200 rpm, making it strong enough for many farming tasks. The tractor has a synchronized transmission with 12 forward and 12 reverse gears, giving the driver lots of options for different jobs. This tractor is big and sturdy. It's 152 inches long, 73 inches wide, and 105 inches tall. It weighs 7090 lb, which helps it stay stable during work. The Zetor 9020 has power steering and a three-point hitch at the back for attaching tools. It also has an open center hydraulic system and agricultural tires front and back. The driver sits in a ROPS (Roll-Over Protective Structure) for safety. The tractor starts with an electric starter, making it easy to get going in the morning.
ManufacturerZetorPower93 hpEngine4-cylTransSynchronized
Quick specs
- Category
- Agricultural
- Engine Power Output
- 93hp
- Operating Weight
- 7,090 lb
- Transmission
- Synchronized
At a glance
How the 9020 compares
vs. Agricultural medianDistribution
Engine Power (hp)
Across all Agricultural tractors
93 hp · 38th
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The 9020 ranks at the 38th percentile for engine power among recorded agricultural tractors.
Overview
About the Zetor 9020
The Zetor 9020 is a powerful 2WD tractor designed for farm work. It has a 4-cylinder diesel engine that's turbocharged and liquid-cooled. This engine puts out 93 hp at 2200 rpm, making it strong enough for many farming tasks. The tractor has a synchronized transmission with 12 forward and 12 reverse gears, giving the driver lots of options for different jobs. This tractor is big and sturdy. It's 152 inches long, 73 inches wide, and 105 inches tall. It weighs 7090 lb, which helps it stay stable during work. The Zetor 9020 has power steering and a three-point hitch at the back for attaching tools. It also has an open center hydraulic system and agricultural tires front and back. The driver sits in a ROPS (Roll-Over Protective Structure) for safety. The tractor starts with an electric starter, making it easy to get going in the morning.
Full specifications
Every recorded spec
General
| Manufacturer | Zetor |
|---|---|
| Model | 9020 |
| Category | Agricultural tractor |
| Type | 4x2 2WD |
| Operating weight | 7,090lb |
Engine
| Make | Zetor |
|---|---|
| Power | 93hp |
| Cylinders | 4 |
| Displacement | 254ci |
| Bore | 4.13in |
| Stroke | 4.72in |
Transmission
| Type | Synchronized |
|---|---|
| Forward gears | 12 |
| Reverse gears | 12 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power |
| Cab | ROPS |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Length | 152in |
|---|---|
| Width | 73in |
| Height | 105in |
| Operating weight | 7,090lb |
Head to head
9020 vs. Agricultural median
How the Zetor 9020 compares to other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 93 hp | 110 hp | -15% | 38th |
| Engine Displacement | 254 ci | 336 ci | -24% | 34th |
| Cylinders | 4 | 5.5 | -27% | 31st |
| Forward Gears | 12 | 16 | -25% | 33rd |
| Operating Weight | 7,090 lb | 10,914 lb | -35% | 25th |
| Length | 152 in | 173 in | -12% | 28th |
| Width | 73 in | 79.5 in | -8% | 37th |
| Height | 105 in | 111 in | -5% | 36th |
Medians and percentiles are computed from the agricultural tractors in our database with a recorded value for each spec (sample sizes 497–1,130 models).
Compare to tractors with similar specs
Commonly compared Zetor tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Zetor 9040 | 93 hp | 7,890 lb | — | Compare → |
| Zetor Forterra 100 | 96 hp | 10,274 lb | — | Compare → |
| Zetor Forterra 100 HSX | 96 hp | 10,494 lb | — | Compare → |
| Zetor Forterra 95 | 97 hp | 10,274 lb | — | Compare → |
| Zetor 10050 | 100 hp | 8,570 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 6080 | 93 hp | 6,500 lb | 1980–1985 | Compare → |
| Antonio Carraro SRX 10400 | 95 hp | 4,718 lb | — | Compare → |
| Antonio Carraro TGF 10400 | 95 hp | 5,247 lb | — | Compare → |
| Antonio Carraro TRG 10400 | 95 hp | 5,247 lb | — | Compare → |
| Antonio Carraro TRX 10400 | 95 hp | 4,828 lb | — | Compare → |
Explore
Zetor siblings
Explore
Similar-spec models
Gallery
Zetor 9020 photos
FAQ
Common questions
How powerful is the Zetor 9020?
The Zetor 9020 has an engine power output of 93 hp. It is powered by a 4-cylinder engine displacing 254 ci.
What hydraulics does the Zetor 9020 have?
The Zetor 9020 uses an Open Center hydraulic system.
What is the working weight of the Zetor 9020?
The operating weight of the Zetor 9020 is approximately 7,090 lb.
What type of transmission does the Zetor 9020 have?
The Zetor 9020 uses a Synchronized transmission offering 12 forward gears.
What routine service does the Zetor 9020 need?
Regular maintenance for the Zetor 9020 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
