Zetor 9741
The Zetor 9741 is a powerful and versatile tractor designed for serious farm work. It features a 4x4 MFWD (Mechanical Front Wheel Drive) system, giving it excellent traction in various field conditions. The tractor is equipped with a Zetor-made diesel engine that's turbocharged for extra power. This 4-cylinder engine has a displacement of 253.6 cubic inches and produces 90 horsepower at 2200 RPM, making it suitable for a wide range of agricultural tasks. The Zetor 9741 comes with a three-speed power shift transmission, offering 24 forward gears and 18 reverse gears. This gives operators plenty of options for different working speeds. The tractor has power steering for easy handling and a comfortable cab for the operator. It's a sizeable machine, measuring 170 inches long, 87 inches wide, and 108 inches tall, with an operating weight of 9100 pounds. The tractor is fitted with 12.4-24 front tires and larger 16.9-38 rear tires, providing good stability and traction. It also features an open center hydraulic system and a category II/I hitch, making it compatible with various implements.
ManufacturerZetorPower90 hpEngine4-cylTransThree-speed power shift
Quick specs
- Category
- Row Crop
- Engine Power Output
- 90hp
- Operating Weight
- 9,100 lb
- Transmission
- Three-speed power shift
At a glance
How the 9741 compares
vs. Row Crop medianDistribution
Engine Power (hp)
Across all Row Crop tractors
90 hp · 18th
This model
12
Median 138 hp
283
This modelRow Crop tractorsMediann = 1,206
The 9741 ranks at the 18th percentile for engine power among recorded row crop tractors.
Overview
About the Zetor 9741
The Zetor 9741 is a powerful and versatile tractor designed for serious farm work. It features a 4x4 MFWD (Mechanical Front Wheel Drive) system, giving it excellent traction in various field conditions. The tractor is equipped with a Zetor-made diesel engine that's turbocharged for extra power. This 4-cylinder engine has a displacement of 253.6 cubic inches and produces 90 horsepower at 2200 RPM, making it suitable for a wide range of agricultural tasks. The Zetor 9741 comes with a three-speed power shift transmission, offering 24 forward gears and 18 reverse gears. This gives operators plenty of options for different working speeds. The tractor has power steering for easy handling and a comfortable cab for the operator. It's a sizeable machine, measuring 170 inches long, 87 inches wide, and 108 inches tall, with an operating weight of 9100 pounds. The tractor is fitted with 12.4-24 front tires and larger 16.9-38 rear tires, providing good stability and traction. It also features an open center hydraulic system and a category II/I hitch, making it compatible with various implements.
Full specifications
Every recorded spec
General
| Manufacturer | Zetor |
|---|---|
| Model | 9741 |
| Category | Row Crop tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 9,100lb |
Engine
| Make | Zetor |
|---|---|
| Power | 90hp |
| Cylinders | 4 |
| Displacement | 253.6ci |
| Bore | 4.13in |
| Stroke | 4.72in |
Transmission
| Type | Three-speed power shift |
|---|---|
| Forward gears | 24 |
| Reverse gears | 18 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
| Cab | Cab |
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 170in |
|---|---|
| Width | 87in |
| Height | 108in |
| Operating weight | 9,100lb |
Tires
| Front | 12.4-24 |
|---|---|
| Rear | 16.9-38 |
Head to head
9741 vs. Row Crop median
How the Zetor 9741 compares to other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 90 hp | 138 hp | -35% | 18th |
| Engine Displacement | 254 ci | 391 ci | -35% | 17th |
| Cylinders | 4 | 6 | -33% | 17th |
| Forward Gears | 24 | 16 | +50% | 81st |
| Operating Weight | 9,100 lb | 12,307 lb | -26% | 27th |
| Length | 170 in | 180 in | -5% | 36th |
| Width | 87 in | 91.2 in | -5% | 41st |
| Height | 108 in | 114 in | -5% | 32nd |
Medians and percentiles are computed from the row crop tractors in our database with a recorded value for each spec (sample sizes 806–1,417 models).
Compare to tractors with similar specs
Commonly compared Zetor tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Zetor 9211 | 90 hp | 8,874 lb | — | Compare → |
| Zetor 9245 | 90 hp | 9,634 lb | — | Compare → |
| Zetor 8011 | 85 hp | 8,157 lb | — | Compare → |
| Zetor 8045 | 85 hp | 9,149 lb | — | Compare → |
| Zetor 10145 | 95.63 hp | 9,524 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 6080 | 93 hp | 6,500 lb | 1980–1985 | Compare → |
| Antonio Carraro Mach 2 | 87 hp | 6,504 lb | — | Compare → |
| Antonio Carraro Mach 4 | 87 hp | 6,725 lb | — | Compare → |
| Antonio Carraro SRH 9800 Infinity | 87 hp | — | — | Compare → |
| Antonio Carraro SRX 9800 | 87 hp | 4,850 lb | — | Compare → |
Explore
Zetor siblings
Explore
Similar-spec models
Gallery
Zetor 9741 photos
FAQ
Common questions
What is the engine power output of the Zetor 9741?
Rated engine output for the Zetor 9741 is 90 hp, delivered by a 4-cylinder engine. The engine displaces 253.6 ci.
What are the factory tire sizes for the Zetor 9741?
The Zetor 9741 comes with 12.4-24 front tires and 16.9-38 rear tires.
What three-point hitch category does the Zetor 9741 use?
The Zetor 9741 has a Category II/I three-point hitch.
What is the operating weight of the Zetor 9741?
In working trim, the Zetor 9741 comes in at roughly 9,100 lb.
Which transmission does the Zetor 9741 use?
The Zetor 9741 is equipped with a Three-speed power shift transmission with 24 forward gears.
What hydraulics does the Zetor 9741 have?
The Zetor 9741 uses an Open center hydraulic system.
How do I maintain a Zetor 9741?
Routine service for the Zetor 9741 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
