Row Crop tractorsSpec sheet
CaseIH Magnum 275
The CaseIH Magnum 275 is a powerful row crop tractor built for serious farming. It has a strong 8.9L 6-cylinder diesel engine that puts out 275 horsepower. This engine is very large compared to most tractors, giving it lots of power for tough jobs. The tractor has a full powershift transmission with 23 forward gears and 6 reverse gears, making it easy to find the right speed for any task. This Magnum model is a 4-wheel drive tractor with power steering, which helps it handle well in the field. It has a cab for the driver's comfort and safety. The tractor weighs 21,570 pounds, which is heavier than average and helps it grip the ground well. It has a Category III/IIIN hitch on the back for attaching big implements. The hydraulic system is pressure-flow compensated (PFC), which means it can handle heavy lifting and multiple hydraulic tasks at once. With its mix of power, size, and features, the CaseIH Magnum 275 is well-suited for large farms and demanding fieldwork.
ManufacturerCaseIHPower275 hp(205.1 kW)Class150–300 HP tractors →Engine6-cylinderTransmissionFull powershift
Key specifications
- Category
- Row Crop
- Engine power
- 275hp
- Operating weight
- 21,570 lb
- Transmission
- Full powershift
Category comparison
Magnum 275 compared with its category
vs. Row Crop medianDistribution
Engine Power (hp)
All recorded Row Crop tractors
275 hp · 91st
This model
12
Median 138 hp
283
This modelRow Crop tractorsMediann = 1,206
The Magnum 275 ranks at the 91st percentile for engine power among recorded row crop tractors.
Overview
About the CaseIH Magnum 275
The CaseIH Magnum 275 is a powerful row crop tractor built for serious farming. It has a strong 8.9L 6-cylinder diesel engine that puts out 275 horsepower. This engine is very large compared to most tractors, giving it lots of power for tough jobs. The tractor has a full powershift transmission with 23 forward gears and 6 reverse gears, making it easy to find the right speed for any task. This Magnum model is a 4-wheel drive tractor with power steering, which helps it handle well in the field. It has a cab for the driver's comfort and safety. The tractor weighs 21,570 pounds, which is heavier than average and helps it grip the ground well. It has a Category III/IIIN hitch on the back for attaching big implements. The hydraulic system is pressure-flow compensated (PFC), which means it can handle heavy lifting and multiple hydraulic tasks at once. With its mix of power, size, and features, the CaseIH Magnum 275 is well-suited for large farms and demanding fieldwork.
Full specifications
Recorded specifications
General
| Manufacturer | CaseIH |
|---|---|
| Model | Magnum 275 |
| Category | Row Crop tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 21,570lb(9,784 kg) |
Engine
| Make | CNH |
|---|---|
| Model | 8.9L 6-cyl diesel |
| Power | 275hp(205.1 kW) |
| Cylinders | 6 |
| Displacement | 540ci(8.85 L) |
| Bore | 4.49in(114 mm) |
| Stroke | 5.69in(144.5 mm) |
Transmission
| Type | Full powershift |
|---|---|
| Forward gears | 23 |
| Reverse gears | 6 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
| Cab | Cab |
Hydraulics
| Type | PFC |
|---|
Dimensions
| Height | 128.5in(3,264 mm) |
|---|---|
| Operating weight | 21,570lb(9,784 kg) |
Capacities
| Cooling system | 6.5gal(24.61 L) |
|---|
Closest alternatives
Magnum 275 compared with the nearest models by horsepower
The closest row crop models to the CaseIH Magnum 275 by rated horsepower are the CaseIH MX275 Magnum and the New Holland TG275. The CaseIH MX275 Magnum matches it on rated power at almost the same operating weight. The New Holland TG275 matches it on rated power at almost the same operating weight. Of the 3 models, the Magnum 275 has the highest weight per horsepower at 78 lb per hp.
| Spec | CaseIH Magnum 275 | CaseIH MX275 Magnum | New Holland TG275 |
|---|---|---|---|
| Engine power | 275 hp205.1 kW | 275 hp205.1 kW | 275 hp205.1 kW |
| Operating weight | 21,570 lb9,784 kg | 21,570 lb9,784 kg | 21,535 lb9,768 kg |
| Weight per hp | 78 lb/hp48 kg/kW | 78 lb/hp48 kg/kW | 78 lb/hp48 kg/kW |
| Displacement | 540 ci8.85 L | 543 ci8.9 L | 506.5 ci8.3 L |
| Cylinders | 6 | 6 | 6 |
| Transmission | Full powershift | Powershift | Full power shift |
| Drive | 4WD | 4WD | 4WD |
Calculators
Calculators for the Magnum 275
PTO power
About 228 to 248 PTO hp
Estimated from the 275 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 275 hp tractor can run
Maximum size is about a 32.5 ft rotary cutter or a 28 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
91 lb per PTO hp as listed
Heavy draft work calls for 110 to 125 lb/hp. The calculator gives the ballast to add.
Units
275 hp is 205.1 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
Magnum 275 vs. Row Crop median
CaseIH Magnum 275 compared with other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 275 hp | 138 hp | +99% | 91st |
| Engine Displacement | 540 ci | 391 ci | +38% | 95th |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 23 | 16 | +44% | 74th |
| Operating Weight | 21,570 lb | 12,307 lb | +75% | 88th |
| Height | 129 in | 114 in | +13% | 88th |
Medians and percentiles are calculated from the row crop tractors in the database that have a recorded value for each specification (sample size 1,140–1,417 models).
Same manufacturer
Other CaseIH models
Other manufacturers
Models with similar horsepower
Gallery
CaseIH Magnum 275 photos
FAQ
Frequently asked questions
What is the engine power output of the CaseIH Magnum 275?
Rated engine output for the CaseIH Magnum 275 is 275 hp, delivered by a 6-cylinder engine. The engine displaces 540 ci.
What is the operating weight of the CaseIH Magnum 275?
The CaseIH Magnum 275 has an operating weight of about 21,570 lb.
Which transmission does the CaseIH Magnum 275 use?
The CaseIH Magnum 275 is equipped with a Full powershift transmission with 23 forward gears.
What hydraulics does the CaseIH Magnum 275 have?
The CaseIH Magnum 275 uses a PFC hydraulic system.
What three-point hitch category does the CaseIH Magnum 275 use?
The CaseIH Magnum 275 has a Category III/IIIN three-point hitch.
How do I maintain a CaseIH Magnum 275?
Routine service for the CaseIH Magnum 275 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
