AgriculturalPerformance profile
Jinma JM-750
The Jinma JM-750 is a powerful 2WD tractor designed for various farming tasks. It features a 75 hp diesel engine with four cylinders, cooled by liquid to keep it running smoothly. The engine runs at 2200 rpm, giving it plenty of power for tough jobs. This tractor has a manual transmission with 8 forward gears and 2 reverse gears, allowing the driver to choose the right speed for different tasks. The JM-750 is built on a 4x2 chassis and measures 157.9 inches long, 75.9 inches wide, and 101.1 inches tall. It weighs 6395 lb, making it a sturdy machine for farm work. The tractor comes with a category II hitch, which lets it connect to many different farm tools and equipment.
ManufacturerJinmaPower75 hpEngine4-cylTransManual
Quick specs
- Category
- Agricultural
- Engine Power Output
- 75hp
- Operating Weight
- 6,395 lb
- Transmission
- Manual
At a glance
How the JM-750 compares
vs. Agricultural medianDistribution
Engine Power (hp)
Across all Agricultural tractors
75 hp · 23rd
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The JM-750 ranks at the 23rd percentile for engine power among recorded agricultural tractors.
Overview
About the Jinma JM-750
The Jinma JM-750 is a powerful 2WD tractor designed for various farming tasks. It features a 75 hp diesel engine with four cylinders, cooled by liquid to keep it running smoothly. The engine runs at 2200 rpm, giving it plenty of power for tough jobs. This tractor has a manual transmission with 8 forward gears and 2 reverse gears, allowing the driver to choose the right speed for different tasks. The JM-750 is built on a 4x2 chassis and measures 157.9 inches long, 75.9 inches wide, and 101.1 inches tall. It weighs 6395 lb, making it a sturdy machine for farm work. The tractor comes with a category II hitch, which lets it connect to many different farm tools and equipment.
Full specifications
Every recorded spec
General
| Manufacturer | Jinma |
|---|---|
| Model | JM-750 |
| Category | Agricultural tractor |
| Type | 4x2 |
| Operating weight | 6,395lb |
Engine
| Make | Jinma |
|---|---|
| Power | 75hp |
| Cylinders | 4 |
Transmission
| Type | Manual |
|---|---|
| Forward gears | 8 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x2 |
|---|---|
| Drive | 2WD |
Dimensions
| Length | 157.9in |
|---|---|
| Width | 75.9in |
| Height | 101.1in |
| Operating weight | 6,395lb |
Head to head
JM-750 vs. Agricultural median
How the Jinma JM-750 compares to other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 75 hp | 110 hp | -32% | 23rd |
| Cylinders | 4 | 5.5 | -27% | 31st |
| Forward Gears | 8 | 16 | -50% | 16th |
| Operating Weight | 6,395 lb | 10,914 lb | -41% | 22nd |
| Length | 158 in | 173 in | -9% | 36th |
| Width | 75.9 in | 79.5 in | -5% | 41st |
| Height | 101 in | 111 in | -9% | 30th |
Medians and percentiles are computed from the agricultural tractors in our database with a recorded value for each spec (sample sizes 497–1,130 models).
Compare to tractors with similar specs
Commonly compared Jinma tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Jinma JM-720 | 72 hp | 6,395 lb | — | Compare → |
| Jinma JM-754 | 75 hp | — | — | Compare → |
| Jinma JM-724 | 72 hp | 7,034 lb | — | Compare → |
| Jinma JM-700 | 70 hp | 6,395 lb | — | Compare → |
| Jinma JM-704 | 70 hp | 7,034 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers D19 | 74.2 hp | 6,650 lb | 1961–1964 | Compare → |
| Barreiros R-545 | 77 hp | 7,720 lb | — | Compare → |
| AGCO LT75 | 78.98 hp | 9,600 lb | — | Compare → |
| AGCO GT65 | 71 hp | 5,335 lb | — | Compare → |
| Agco GT65A | 71 hp | 5,864.3 lb | — | Compare → |
Explore
Jinma siblings
Explore
Similar-spec models
Gallery
Jinma JM-750 photos
FAQ
Common questions
What is the engine power output of the Jinma JM-750?
Rated engine output for the Jinma JM-750 is 75 hp, delivered by a 4-cylinder engine.
Which transmission does the Jinma JM-750 use?
The Jinma JM-750 is equipped with a Manual transmission with 8 forward gears.
What three-point hitch category does the Jinma JM-750 use?
The Jinma JM-750 has a Category II three-point hitch.
What is the operating weight of the Jinma JM-750?
In working trim, the Jinma JM-750 comes in at roughly 6,395 lb.
How do I maintain a Jinma JM-750?
Routine service for the Jinma JM-750 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
