John Deere 5075GN
The John Deere 5075GN is a versatile tractor designed for orchards and vineyards. It's also great for general farm work. This tractor has a 2WD drive system and power steering, making it easy to handle. The engine, made by FPT, has 4 cylinders and runs on diesel fuel. It's cooled by a special fan system to keep it running smoothly. With 75 horsepower, this tractor has above-average power for its size. It has a 24-speed forward and 12-speed reverse transmission, giving the driver lots of options. The tractor is compact, measuring just 49.5 inches wide, perfect for working in tight spaces between trees or vines. It weighs 5,566 pounds, which is above average for similar tractors. The 5075GN comes with a strong hitch system and can be fitted with a cab or roll-over protection for safety. It also meets modern emission standards, making it good for the environment.
ManufacturerJohn DeerePower75 hpEngine4-cyl
Quick specs
- Category
- Agricultural
- Engine Power Output
- 75hp
- Operating Weight
- 5,566 lb
At a glance
How the 5075GN compares
vs. Agricultural medianDistribution
Engine Power (hp)
Across all Agricultural tractors
75 hp · 23rd
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The 5075GN ranks at the 23rd percentile for engine power among recorded agricultural tractors.
Overview
About the John Deere 5075GN
The John Deere 5075GN is a versatile tractor designed for orchards and vineyards. It's also great for general farm work. This tractor has a 2WD drive system and power steering, making it easy to handle. The engine, made by FPT, has 4 cylinders and runs on diesel fuel. It's cooled by a special fan system to keep it running smoothly. With 75 horsepower, this tractor has above-average power for its size. It has a 24-speed forward and 12-speed reverse transmission, giving the driver lots of options. The tractor is compact, measuring just 49.5 inches wide, perfect for working in tight spaces between trees or vines. It weighs 5,566 pounds, which is above average for similar tractors. The 5075GN comes with a strong hitch system and can be fitted with a cab or roll-over protection for safety. It also meets modern emission standards, making it good for the environment.
Full specifications
Every recorded spec
General
| Manufacturer | John Deere |
|---|---|
| Model | 5075GN |
| Category | Agricultural tractor |
| Type | 4x2 2WD |
| Operating weight | 5,566lb |
Engine
| Make | FPT |
|---|---|
| Power | 75hp |
| Cylinders | 4 |
| Displacement | 206.9ci |
| Bore | 3.9in |
| Stroke | 4.33in |
Transmission
| Forward gears | 24 |
|---|---|
| Reverse gears | 12 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power |
| Cab | ROPS / Cab |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Width | 49.5in |
|---|---|
| Operating weight | 5,566lb |
Head to head
5075GN vs. Agricultural median
How the John Deere 5075GN compares to other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 75 hp | 110 hp | -32% | 23rd |
| Engine Displacement | 207 ci | 336 ci | -38% | 17th |
| Cylinders | 4 | 5.5 | -27% | 31st |
| Forward Gears | 24 | 16 | +50% | 81st |
| Operating Weight | 5,566 lb | 10,914 lb | -49% | 16th |
| Width | 49.5 in | 79.5 in | -38% | 11th |
Medians and percentiles are computed from the agricultural tractors in our database with a recorded value for each spec (sample sizes 497–1,130 models).
Compare to tractors with similar specs
Commonly compared John Deere tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| John Deere 5520N | 75 hp | — | 2002–2004 | Compare → |
| John Deere 6100 | 75 hp | 8,160 lb | — | Compare → |
| John Deere 75F | 74 hp | 5,512 lb | — | Compare → |
| John Deere 76F | 76 hp | 4,189 lb | — | Compare → |
| John Deere 3380 | 73 hp | 10,141 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers D19 | 74.2 hp | 6,650 lb | 1961–1964 | Compare → |
| Barreiros R-545 | 77 hp | 7,720 lb | — | Compare → |
| AGCO LT75 | 78.98 hp | 9,600 lb | — | Compare → |
| AGCO GT65 | 71 hp | 5,335 lb | — | Compare → |
| Agco GT65A | 71 hp | 5,864.3 lb | — | Compare → |
Explore
John Deere siblings
Explore
Similar-spec models
Gallery
John Deere 5075GN photos
FAQ
Common questions
How much horsepower does the John Deere 5075GN have?
The John Deere 5075GN produces 75 hp from its 4-cylinder engine. Engine displacement is 206.9 ci.
How much does the John Deere 5075GN weigh?
The John Deere 5075GN weighs about 5,566 lb in operating condition.
What hydraulics does the John Deere 5075GN have?
The John Deere 5075GN uses an Open Center hydraulic system.
What three-point hitch category does the John Deere 5075GN use?
The John Deere 5075GN has a Category Category 3 three-point hitch.
What maintenance does the John Deere 5075GN require?
Like any tractor, the John Deere 5075GN needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
