John Deere 6500L
The John Deere 6500L is a powerful orchard and vineyard tractor designed for agricultural use. It features a 2WD drive system and a partial power shift transmission with 16 forward and 16 reverse gears, giving farmers plenty of options for different tasks. The tractor is equipped with a John Deere 4045 engine, which is a 4-cylinder, turbocharged diesel engine that delivers an impressive 114 hp at 2300 rpm. This engine power is very high compared to other tractors in its class. At 162.7 inches long and 96.1 inches tall, the 6500L is built to navigate through orchards and vineyards with ease. It has a substantial operating weight of 7,740 lb, which is above average for similar tractors. The tractor comes with agricultural tires on both front and rear, and it features a Category II hitch at the rear for attaching various implements. The 6500L also boasts a closed center pressure flow compensated hydraulic system and a comfortable cab for the operator. With its electric starter and liquid-cooled engine, this John Deere tractor is ready to tackle tough farming jobs efficiently and reliably.
ManufacturerJohn DeerePower114 hpEngine4-cylTransPartial power shift
Quick specs
- Category
- Agricultural
- Engine Power Output
- 114hp
- Operating Weight
- 7,740 lb
- Transmission
- Partial power shift
At a glance
How the 6500L compares
vs. Agricultural medianDistribution
Engine Power (hp)
Across all Agricultural tractors
114 hp · 52nd
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The 6500L ranks at the 52nd percentile for engine power among recorded agricultural tractors.
Overview
About the John Deere 6500L
The John Deere 6500L is a powerful orchard and vineyard tractor designed for agricultural use. It features a 2WD drive system and a partial power shift transmission with 16 forward and 16 reverse gears, giving farmers plenty of options for different tasks. The tractor is equipped with a John Deere 4045 engine, which is a 4-cylinder, turbocharged diesel engine that delivers an impressive 114 hp at 2300 rpm. This engine power is very high compared to other tractors in its class. At 162.7 inches long and 96.1 inches tall, the 6500L is built to navigate through orchards and vineyards with ease. It has a substantial operating weight of 7,740 lb, which is above average for similar tractors. The tractor comes with agricultural tires on both front and rear, and it features a Category II hitch at the rear for attaching various implements. The 6500L also boasts a closed center pressure flow compensated hydraulic system and a comfortable cab for the operator. With its electric starter and liquid-cooled engine, this John Deere tractor is ready to tackle tough farming jobs efficiently and reliably.
Full specifications
Every recorded spec
General
| Manufacturer | John Deere |
|---|---|
| Model | 6500L |
| Category | Agricultural tractor |
| Type | 4x2 2WD |
| Operating weight | 7,740lb |
Engine
| Make | John Deere |
|---|---|
| Model | 4045 |
| Power | 114hp |
| Cylinders | 4 |
| Displacement | 276ci |
| Bore | 4.19in |
| Stroke | 5in |
Transmission
| Type | Partial power shift |
|---|---|
| Forward gears | 16 |
| Reverse gears | 16 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Cab | Cab |
Hydraulics
| Type | Closed center pressure flow compensated |
|---|
Dimensions
| Length | 162.7in |
|---|---|
| Height | 96.1in |
| Operating weight | 7,740lb |
Capacities
| Cooling system | 2.9gal |
|---|
Head to head
6500L vs. Agricultural median
How the John Deere 6500L compares to other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 114 hp | 110 hp | +4% | 52nd |
| Engine Displacement | 276 ci | 336 ci | -18% | 41st |
| Cylinders | 4 | 5.5 | -27% | 31st |
| Forward Gears | 16 | 16 | at median | 50th |
| Operating Weight | 7,740 lb | 10,914 lb | -29% | 30th |
| Length | 163 in | 173 in | -6% | 41st |
| Height | 96.1 in | 111 in | -13% | 25th |
Medians and percentiles are computed from the agricultural tractors in our database with a recorded value for each spec (sample sizes 795–1,130 models).
Compare to tractors with similar specs
Commonly compared John Deere tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| John Deere 6510L | 114 hp | 7,740 lb | — | Compare → |
| John Deere 5115ML | 115 hp | 7,950 lb | — | Compare → |
| John Deere 5125ML | 118.68 hp | 8,625 lb | — | Compare → |
| John Deere 5120M | 120 hp | — | — | Compare → |
| John Deere 6800 | 120 hp | 11,000 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Belarus 1025 MIG | 115 hp | 9,469 lb | — | Compare → |
| Agco LT95A | 111.6 hp | 11,070 lb | — | Compare → |
| AGCO RT110A | 116.9 hp | 12,200 lb | — | Compare → |
| Allis Chalmers 7000 | 117 hp | 9,550 lb | 1975–1979 | Compare → |
| AGCO LT85A | 110.1 hp | 10,605 lb | — | Compare → |
Explore
John Deere siblings
Explore
Similar-spec models
Gallery
John Deere 6500L photos
FAQ
Common questions
What is the engine power output of the John Deere 6500L?
Rated engine output for the John Deere 6500L is 114 hp, delivered by a 4-cylinder engine. The engine displaces 276 ci.
Which transmission does the John Deere 6500L use?
The John Deere 6500L is equipped with a Partial power shift transmission with 16 forward gears.
What type of hydraulic system does the John Deere 6500L use?
Hydraulics on the John Deere 6500L are Closed center pressure flow compensated.
What hitch category is the John Deere 6500L?
The John Deere 6500L uses a Category Category 3 hitch.
What is the operating weight of the John Deere 6500L?
In working trim, the John Deere 6500L comes in at roughly 7,740 lb.
How do I maintain a John Deere 6500L?
Routine service for the John Deere 6500L covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
