UtilityPerformance profile
Kubota L2500
The Kubota L2500 is a utility tractor made from 1998 to 2000. It's a compact machine, measuring 103.5 inches long, 50 inches wide, and 83.1 inches tall. This tractor has a 2WD drive system and weighs 2700 lb, which is lighter than many other tractors. The L2500 is powered by a Kubota D1403 diesel engine. This engine has 3 cylinders and is liquid-cooled. It produces 28.2 hp, which is below average for tractors. The engine runs at a very high 2800 rpm. The tractor has an 8-speed forward and 2-speed reverse transmission. It features a three-point hitch at the rear, which can lift up to 1998 lb. This lifting capacity is above average. The tractor also has a 540 rpm PTO for powering attachments. For the operator's safety, it comes with an open station and a two-post rollover protection system (ROPS).
ManufacturerKubotaPower28.2 hpEngine3-cylTransSliding gear
Quick specs
- Category
- Utility
- Engine Power Output
- 28hp
- Operating Weight
- 2,700 lb
- Transmission
- Sliding gear
At a glance
How the L2500 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
28.2 hp · 20th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The L2500 ranks at the 20th percentile for engine power among recorded utility tractors.
Overview
About the Kubota L2500
The Kubota L2500 is a utility tractor made from 1998 to 2000. It's a compact machine, measuring 103.5 inches long, 50 inches wide, and 83.1 inches tall. This tractor has a 2WD drive system and weighs 2700 lb, which is lighter than many other tractors. The L2500 is powered by a Kubota D1403 diesel engine. This engine has 3 cylinders and is liquid-cooled. It produces 28.2 hp, which is below average for tractors. The engine runs at a very high 2800 rpm. The tractor has an 8-speed forward and 2-speed reverse transmission. It features a three-point hitch at the rear, which can lift up to 1998 lb. This lifting capacity is above average. The tractor also has a 540 rpm PTO for powering attachments. For the operator's safety, it comes with an open station and a two-post rollover protection system (ROPS).
Full specifications
Every recorded spec
General
| Manufacturer | Kubota |
|---|---|
| Model | L2500 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Years built | 1998–2000 |
| Operating weight | 2,700lb |
Engine
| Make | Kubota |
|---|---|
| Model | D1403 |
| Power | 28.2hp |
| Cylinders | 3 |
| Displacement | 85ci |
| Bore | 3.15in |
| Stroke | 3.64in |
Transmission
| Type | Sliding gear |
|---|---|
| Forward gears | 8 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Manual |
| Brakes | Mechanical wet disc |
| Cab | Open operator station with two-post ROPS |
Hydraulics
| Type | Open center |
|---|
Power take-off
| PTO speed | 540rpm |
|---|
Dimensions
| Length | 103.5in |
|---|---|
| Width | 50in |
| Height | 83.1in |
| Operating weight | 2,700lb |
Capacities
| Cooling system | 1.6gal |
|---|
Head to head
L2500 vs. Utility median
How the Kubota L2500 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 28.2 hp | 55 hp | -49% | 20th |
| Engine Displacement | 85 ci | 183 ci | -54% | 14th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 8 | 12 | -33% | 23rd |
| Operating Weight | 2,700 lb | 5,303 lb | -49% | 19th |
| Length | 104 in | 137 in | -24% | 11th |
| Width | 50 in | 66 in | -24% | 17th |
| Height | 83.1 in | 94.1 in | -12% | 30th |
| 3-Point Hitch Capacity | 1,998 lb | 3,197 lb | -38% | 22nd |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 1,083–5,720 models).
Compare to tractors with similar specs
Commonly compared Kubota tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Kubota GL281 | 28.6 hp | — | 1996–2001 | Compare → |
| Kubota GL29 | 28.6 hp | 2,624 lb | 1990–1992 | Compare → |
| Kubota ST-30 | 28.7 hp | — | 1997–2001 | Compare → |
| Kubota FT28 | 27.6 hp | 2,116 lb | 2012–2015 | Compare → |
| Kubota GL280 | 27.6 hp | — | 1993–1995 | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO ST28A | 28.4 hp | 2,400 lb | — | Compare → |
| AGCO ST30x | 28.4 hp | 1,984 lb | — | Compare → |
| Allis Chalmers D10 | 28.57 hp | 2,700 lb | 1959–1967 | Compare → |
| Allis Chalmers D272 | 27.5 hp | 2,060 lb | — | Compare → |
| Ascot Universal 300 | 27.5 hp | 3,800 lb | — | Compare → |
Explore
Kubota siblings
Explore
Similar-spec models
Gallery
Kubota L2500 photos
FAQ
Common questions
When was the Kubota L2500 made?
The Kubota L2500 was manufactured from 1998 to 2000.
What is the engine power output of the Kubota L2500?
Rated engine output for the Kubota L2500 is 28.2 hp, delivered by a 3-cylinder engine. The engine displaces 85 ci.
What is the operating weight of the Kubota L2500?
In working trim, the Kubota L2500 comes in at roughly 2,700 lb.
Which transmission does the Kubota L2500 use?
The Kubota L2500 is equipped with a Sliding gear transmission with 8 forward gears.
What hydraulics does the Kubota L2500 have?
The Kubota L2500 uses an Open center hydraulic system.
What three-point hitch category does the Kubota L2500 use?
The Kubota L2500 has a Category I three-point hitch rated to lift 1,998 lb.
How do I maintain a Kubota L2500?
Routine service for the Kubota L2500 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
