UtilityPerformance profile
Massey Ferguson 1417
The Massey Ferguson 1417 is a compact utility tractor built from 2003 to 2005. It's a small but capable machine, perfect for light farm work and yard maintenance. This tractor has a 4-wheel drive system, which helps it move easily on different types of ground. Under the hood, the 1417 has a 3-cylinder diesel engine made by Iseki. The engine is liquid-cooled and produces 16.6 horsepower, which is on the lower end compared to other tractors. It has a 6-speed forward and 2-speed reverse transmission, giving the operator good control over speed. The tractor is quite small, measuring 100.2 inches long, 39 inches wide, and 74.4 inches tall with the roll-over protection system. It weighs 1422 pounds, making it lighter than many other tractors. The 1417 also features power steering, a Category I hitch, and an open center hydraulic system, which are useful for attaching and operating various implements.
ManufacturerMassey FergusonPower16.6 hpEngine3-cyl
Quick specs
- Category
- Utility
- Engine Power Output
- 17hp
- Operating Weight
- 1,422 lb
At a glance
How the 1417 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
16.6 hp · 4th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 1417 ranks at the 4th percentile for engine power among recorded utility tractors.
Overview
About the Massey Ferguson 1417
The Massey Ferguson 1417 is a compact utility tractor built from 2003 to 2005. It's a small but capable machine, perfect for light farm work and yard maintenance. This tractor has a 4-wheel drive system, which helps it move easily on different types of ground. Under the hood, the 1417 has a 3-cylinder diesel engine made by Iseki. The engine is liquid-cooled and produces 16.6 horsepower, which is on the lower end compared to other tractors. It has a 6-speed forward and 2-speed reverse transmission, giving the operator good control over speed. The tractor is quite small, measuring 100.2 inches long, 39 inches wide, and 74.4 inches tall with the roll-over protection system. It weighs 1422 pounds, making it lighter than many other tractors. The 1417 also features power steering, a Category I hitch, and an open center hydraulic system, which are useful for attaching and operating various implements.
Full specifications
Every recorded spec
General
| Manufacturer | Massey Ferguson |
|---|---|
| Model | 1417 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Years built | 2003–2005 |
| Operating weight | 1,422lb |
Engine
| Make | Iseki |
|---|---|
| Power | 16.6hp |
| Cylinders | 3 |
| Displacement | 56.6ci |
Transmission
| Forward gears | 6 |
|---|---|
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 100.2in |
|---|---|
| Width | 39in |
| Height | 74.4in |
| Operating weight | 1,422lb |
Head to head
1417 vs. Utility median
How the Massey Ferguson 1417 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 16.6 hp | 55 hp | -70% | 4th |
| Engine Displacement | 56.6 ci | 183 ci | -69% | 4th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 6 | 12 | -50% | 11th |
| Operating Weight | 1,422 lb | 5,303 lb | -73% | 4th |
| Length | 100 in | 137 in | -27% | 9th |
| Width | 39 in | 66 in | -41% | 3rd |
| Height | 74.4 in | 94.1 in | -21% | 19th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Massey Ferguson tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Massey Ferguson 1010 | 16 hp | 1,420 lb | 1982–1994 | Compare → |
| Massey Ferguson 1205 | 16 hp | 1,580 lb | 1997–2003 | Compare → |
| Massey Ferguson 1210 | 18 hp | 2,010 lb | 1993–1995 | Compare → |
| Massey Ferguson 1215 | 18 hp | 1,460 lb | 1996–2003 | Compare → |
| Massey Ferguson 205 | 20 hp | 1,905 lb | 1978–1984 | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 616 | 16.5 hp | 1,499 lb | 1972–1973 | Compare → |
| Ariens GT17 | 17 hp | 926 lb | 1979–1987 | Compare → |
| Bolens G172 | 17 hp | 1,056 lb | — | Compare → |
| Bolens G174 | 17 hp | 1,144 lb | — | Compare → |
| Bolens H1704 | 17 hp | 1,268 lb | — | Compare → |
Explore
Massey Ferguson siblings
Explore
Similar-spec models
Gallery
Massey Ferguson 1417 photos
FAQ
Common questions
When was the Massey Ferguson 1417 made?
The Massey Ferguson 1417 was manufactured from 2003 to 2005.
What is the engine power output of the Massey Ferguson 1417?
Rated engine output for the Massey Ferguson 1417 is 16.6 hp, delivered by a 3-cylinder engine. The engine displaces 56.6 ci.
What is the operating weight of the Massey Ferguson 1417?
In working trim, the Massey Ferguson 1417 comes in at roughly 1,422 lb.
What hydraulics does the Massey Ferguson 1417 have?
The Massey Ferguson 1417 uses an Open center hydraulic system.
What three-point hitch category does the Massey Ferguson 1417 use?
The Massey Ferguson 1417 has a Category Category 3 three-point hitch.
How do I maintain a Massey Ferguson 1417?
Routine service for the Massey Ferguson 1417 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
