UtilityPerformance profile
McCormick Intl B80 Max
The McCormick Intl B80 Max is a utility tractor built for farm work. It has a 2WD drive system and a mechanical shuttle transmission with 24 forward gears and 12 reverse gears. This gives the driver lots of options for different tasks. The tractor is powered by a Perkins 1104D-44 diesel engine. This engine has 4 cylinders and is liquid-cooled. It can produce 74 horsepower, which is above average for tractors like this. The engine size is also above average, measuring 268 cubic inches. The B80 Max weighs 7,326 pounds, making it a sturdy machine for tough jobs. It has a category II hitch, which lets it work with many farm tools. The B80 Max is 162.8 inches long, 81.2 inches wide, and 100 inches tall. It has ag tires in the front and back, perfect for field work. The tractor starts with an electric starter, making it easy to get going. With its mix of power and features, the McCormick Intl B80 Max is a solid choice for farmers who need a reliable utility tractor.
ManufacturerMcCormick IntlPower74 hpEngine4-cylTransMechanical shuttle
Quick specs
- Category
- Utility
- Engine Power Output
- 74hp
- Operating Weight
- 7,326 lb
- Transmission
- Mechanical shuttle
At a glance
How the B80 Max compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
74 hp · 66th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The B80 Max ranks at the 66th percentile for engine power among recorded utility tractors.
Overview
About the McCormick Intl B80 Max
The McCormick Intl B80 Max is a utility tractor built for farm work. It has a 2WD drive system and a mechanical shuttle transmission with 24 forward gears and 12 reverse gears. This gives the driver lots of options for different tasks. The tractor is powered by a Perkins 1104D-44 diesel engine. This engine has 4 cylinders and is liquid-cooled. It can produce 74 horsepower, which is above average for tractors like this. The engine size is also above average, measuring 268 cubic inches. The B80 Max weighs 7,326 pounds, making it a sturdy machine for tough jobs. It has a category II hitch, which lets it work with many farm tools. The B80 Max is 162.8 inches long, 81.2 inches wide, and 100 inches tall. It has ag tires in the front and back, perfect for field work. The tractor starts with an electric starter, making it easy to get going. With its mix of power and features, the McCormick Intl B80 Max is a solid choice for farmers who need a reliable utility tractor.
Full specifications
Every recorded spec
General
| Manufacturer | McCormick Intl |
|---|---|
| Model | B80 Max |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Operating weight | 7,326lb |
Engine
| Make | Perkins |
|---|---|
| Model | 1104D-44 |
| Power | 74hp |
| Cylinders | 4 |
| Displacement | 268ci |
| Bore | 4.13in |
| Stroke | 5in |
Transmission
| Type | Mechanical shuttle |
|---|---|
| Forward gears | 24 |
| Reverse gears | 12 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
Dimensions
| Length | 162.8in |
|---|---|
| Width | 81.2in |
| Height | 100in |
| Operating weight | 7,326lb |
Head to head
B80 Max vs. Utility median
How the McCormick Intl B80 Max compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 74 hp | 55 hp | +35% | 66th |
| Engine Displacement | 268 ci | 183 ci | +46% | 75th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 24 | 12 | +100% | 92nd |
| Operating Weight | 7,326 lb | 5,303 lb | +38% | 70th |
| Length | 163 in | 137 in | +19% | 80th |
| Width | 81.2 in | 66 in | +23% | 84th |
| Height | 100 in | 94.1 in | +6% | 66th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared McCormick Intl tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| McCormick Intl C80 Max | 74 hp | — | — | Compare → |
| McCormick Intl T80 Max | 74 hp | 8,378 lb | — | Compare → |
| McCormick Intl C80L | 73.7 hp | 5,190 lb | — | Compare → |
| McCormick Intl X10.75M | 74.4 hp | 7,749 lb | — | Compare → |
| McCormick Intl C70 | 73 hp | 5,941 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers D19 | 74.2 hp | 6,650 lb | 1961–1964 | Compare → |
| AGCO GT65 | 71 hp | 5,335 lb | — | Compare → |
| Agco GT65A | 71 hp | 5,864.3 lb | — | Compare → |
| Antonio Carraro SX 7800S | 71 hp | 4,773 lb | — | Compare → |
| Antonio Carraro TGF 7800S | 71 hp | 5,093 lb | — | Compare → |
Explore
McCormick Intl siblings
Explore
Similar-spec models
Gallery
McCormick Intl B80 Max photos
FAQ
Common questions
How much horsepower does the McCormick Intl B80 Max have?
The McCormick Intl B80 Max produces 74 hp from its 4-cylinder engine. Engine displacement is 268 ci.
How much does the McCormick Intl B80 Max weigh?
The McCormick Intl B80 Max weighs about 7,326 lb in operating condition.
What transmission is in the McCormick Intl B80 Max?
Transmission on the McCormick Intl B80 Max is Mechanical shuttle, with 24 forward speeds.
What three-point hitch category does the McCormick Intl B80 Max use?
The McCormick Intl B80 Max has a Category II three-point hitch.
What maintenance does the McCormick Intl B80 Max require?
Like any tractor, the McCormick Intl B80 Max needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
