UtilityPerformance profile
New Holland 5030
The New Holland 5030 is a utility tractor built from 1992 to 1998. It's a 2WD model with a 4x2 chassis and hydrostatic power steering. This tractor has a Ford engine with 4 cylinders and 62 horsepower, which is above average for its class. The engine is diesel-powered and naturally aspirated, with a displacement of 255 cubic inches. The 5030 features a partial power shift transmission with 16 forward and 8 reverse gears, giving operators good control over speed and power. It has a three-point hitch at the rear, capable of lifting 3,075 pounds, which is very high compared to similar tractors. The tractor's PTO runs at 540 rpm and is powered by the transmission. With a weight of 5,988 pounds and dimensions of 143.7 inches long, 69.5 inches wide, and 99.2 inches tall, this New Holland model is a sturdy and capable machine for various farm tasks.
ManufacturerNew HollandPower62 hpEngine4-cylTransPartial power shift
Quick specs
- Category
- Utility
- Engine Power Output
- 62hp
- Operating Weight
- 5,988 lb
- Transmission
- Partial power shift
At a glance
How the 5030 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
62 hp · 56th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 5030 ranks at the 56th percentile for engine power among recorded utility tractors.
Overview
About the New Holland 5030
The New Holland 5030 is a utility tractor built from 1992 to 1998. It's a 2WD model with a 4x2 chassis and hydrostatic power steering. This tractor has a Ford engine with 4 cylinders and 62 horsepower, which is above average for its class. The engine is diesel-powered and naturally aspirated, with a displacement of 255 cubic inches. The 5030 features a partial power shift transmission with 16 forward and 8 reverse gears, giving operators good control over speed and power. It has a three-point hitch at the rear, capable of lifting 3,075 pounds, which is very high compared to similar tractors. The tractor's PTO runs at 540 rpm and is powered by the transmission. With a weight of 5,988 pounds and dimensions of 143.7 inches long, 69.5 inches wide, and 99.2 inches tall, this New Holland model is a sturdy and capable machine for various farm tasks.
Full specifications
Every recorded spec
General
| Manufacturer | New Holland |
|---|---|
| Model | 5030 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Years built | 1992–1998 |
| Operating weight | 5,988lb |
Engine
| Make | Ford |
|---|---|
| Power | 62hp |
| Cylinders | 4 |
| Displacement | 255ci |
| Bore | 4.4in |
| Stroke | 4.2in |
Transmission
| Type | Partial power shift |
|---|---|
| Forward gears | 16 |
| Reverse gears | 8 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Hydrostatic power |
| Brakes | Differential wet disc |
| Cab | Two-post ROPS |
Hydraulics
| Type | Open center |
|---|
Power take-off
| Rear PTO | Transmission |
|---|---|
| PTO speed | 540rpm |
Dimensions
| Length | 143.7in |
|---|---|
| Width | 69.5in |
| Height | 99.2in |
| Operating weight | 5,988lb |
Capacities
| Cooling system | 3.3gal |
|---|
Head to head
5030 vs. Utility median
How the New Holland 5030 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 62 hp | 55 hp | +13% | 56th |
| Engine Displacement | 255 ci | 183 ci | +39% | 73rd |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 16 | 12 | +33% | 73rd |
| Operating Weight | 5,988 lb | 5,303 lb | +13% | 56th |
| Length | 144 in | 137 in | +5% | 59th |
| Width | 69.5 in | 66 in | +5% | 59th |
| Height | 99.2 in | 94.1 in | +5% | 64th |
| 3-Point Hitch Capacity | 3,075 lb | 3,197 lb | -4% | 47th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 1,083–5,720 models).
Compare to tractors with similar specs
Commonly compared New Holland tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| New Holland TL55E | 62 hp | — | 2002–2006 | Compare → |
| New Holland TL55E Exitus | 62 hp | 5,423 lb | — | Compare → |
| New Holland Workmaster 65 | 61.7 hp | 5,720 lb | — | Compare → |
| New Holland TL60E | 61 hp | — | 2006+ | Compare → |
| New Holland TN70A | 60.7 hp | 5,215 lb | 2004–2008 | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers D17 | 63 hp | 4,675 lb | 1957–1967 | Compare → |
| Allis Chalmers 6060 | 63.21 hp | 6,465 lb | 1980–1984 | Compare → |
| Barreiros 70.7 | 64 hp | 5,450 lb | — | Compare → |
| Barreiros R-500 B | 60 hp | — | — | Compare → |
| Belarus 5011 | 60 hp | — | — | Compare → |
Explore
New Holland siblings
Explore
Similar-spec models
Gallery
New Holland 5030 photos
FAQ
Common questions
What years was the New Holland 5030 manufactured?
Production of the New Holland 5030 ran from 1992 through 1998.
What hydraulics does the New Holland 5030 have?
The New Holland 5030 uses an Open center hydraulic system.
What three-point hitch category does the New Holland 5030 use?
The New Holland 5030 has a Category II/I three-point hitch rated to lift 3,075 lb.
How powerful is the New Holland 5030?
The New Holland 5030 has an engine power output of 62 hp. It is powered by a 4-cylinder engine displacing 255 ci.
What is the working weight of the New Holland 5030?
The operating weight of the New Holland 5030 is approximately 5,988 lb.
What type of transmission does the New Holland 5030 have?
The New Holland 5030 uses a Partial power shift transmission offering 16 forward gears.
What routine service does the New Holland 5030 need?
Regular maintenance for the New Holland 5030 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
