Utility tractorsSpec sheet
New Holland T4050
The New Holland T4050 is a powerful utility tractor built for tough farm work. It has a strong 4-cylinder diesel engine made by Iveco. This engine can produce 90 horsepower, which is above average for tractors in its class. The T4050 has a 4-wheel drive system, making it great for working in muddy or uneven fields. This tractor has a mechanical shuttle transmission with 12 forward and 12 reverse gears. This gives the driver lots of options for different tasks. The T4050 weighs 7,320 pounds, which is on the heavier side for utility tractors. It has a hydrostatic power steering system, making it easy to control. The tractor also has an open center hydraulic system, which is good for running attachments. With its 138.6-inch length and strong engine, the T4050 is a versatile machine that can handle many farm jobs with ease.
ManufacturerNew HollandPower90 hp(67.1 kW)Class60–100 HP tractors →Engine4-cylinderTransmissionMechanical shuttle
Key specifications
- Category
- Utility
- Engine power
- 90hp
- Operating weight
- 7,320 lb
- Transmission
- Mechanical shuttle
Category comparison
T4050 compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
90 hp · 78th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The T4050 ranks at the 78th percentile for engine power among recorded utility tractors.
Overview
About the New Holland T4050
The New Holland T4050 is a powerful utility tractor built for tough farm work. It has a strong 4-cylinder diesel engine made by Iveco. This engine can produce 90 horsepower, which is above average for tractors in its class. The T4050 has a 4-wheel drive system, making it great for working in muddy or uneven fields. This tractor has a mechanical shuttle transmission with 12 forward and 12 reverse gears. This gives the driver lots of options for different tasks. The T4050 weighs 7,320 pounds, which is on the heavier side for utility tractors. It has a hydrostatic power steering system, making it easy to control. The tractor also has an open center hydraulic system, which is good for running attachments. With its 138.6-inch length and strong engine, the T4050 is a versatile machine that can handle many farm jobs with ease.
Full specifications
Recorded specifications
General
| Manufacturer | New Holland |
|---|---|
| Model | T4050 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 7,320lb(3,320 kg) |
Engine
| Make | Iveco Diesel |
|---|---|
| Model | Iveco Diesel |
| Power | 90hp(67.11 kW) |
| Cylinders | 4 |
| Displacement | 274ci(4.49 L) |
Transmission
| Type | Mechanical shuttle |
|---|---|
| Forward gears | 12 |
| Reverse gears | 12 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 138.6in(3,520 mm) |
|---|---|
| Operating weight | 7,320lb(3,320 kg) |
Closest alternatives
T4050 compared with the nearest models by horsepower
Among utility tractors, the New Holland TL5050 and the New Holland TN95A are closest to the New Holland T4050 in rated horsepower. The New Holland TL5050 matches it on rated power and weighs 300 lb less. The New Holland TN95A matches it on rated power and weighs 1,200 lb less, carrying 68 lb per horsepower against 81 lb. Of the 3 models, the T4050 has the highest weight per horsepower at 81 lb per hp.
| Spec | New Holland T4050 | New Holland TL5050 | New Holland TN95A |
|---|---|---|---|
| Engine power | 90 hp67.1 kW | 90 hp67.1 kW | 90 hp67.1 kW |
| Operating weight | 7,320 lb3,320 kg | 7,022 lb3,185 kg | 6,118 lb2,775 kg |
| Weight per hp | 81 lb/hp49 kg/kW | 78 lb/hp47 kg/kW | 68 lb/hp41 kg/kW |
| Displacement | 274 ci4.49 L | 253.6 ci4.16 L | 274 ci4.49 L |
| Cylinders | 4 | 4 | 4 |
| Transmission | Mechanical shuttle | Shuttle Command | Partially synchronized with power shuttle |
| Drive | 4WD | 2WD | MFWD 4WD |
| Years built | - | 2007-2011 | 2004-2008 |
Calculators
Calculators for the T4050
PTO power
About 75 to 81 PTO hp
Estimated from the 90 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 90 hp tractor can run
Maximum size is about a 10.5 ft rotary cutter or a 9 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
95 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
90 hp is 67.1 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
T4050 vs. Utility median
New Holland T4050 compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 90 hp | 55 hp | +64% | 78th |
| Engine Displacement | 274 ci | 183 ci | +50% | 79th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 12 | 12 | at median | 50th |
| Operating Weight | 7,320 lb | 5,303 lb | +38% | 70th |
| Length | 139 in | 137 in | +1% | 53rd |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 4,659–5,720 models).
Same manufacturer
Other New Holland models
Other manufacturers
Models with similar horsepower
Gallery
New Holland T4050 photos
FAQ
Frequently asked questions
How much horsepower does the New Holland T4050 have?
The New Holland T4050 produces 90 hp from its 4-cylinder engine. Engine displacement is 274 ci.
What transmission is in the New Holland T4050?
Transmission on the New Holland T4050 is Mechanical shuttle, with 12 forward speeds.
What type of hydraulic system does the New Holland T4050 use?
Hydraulics on the New Holland T4050 are Open center.
What hitch category is the New Holland T4050?
The New Holland T4050 uses a Category II/I hitch.
How much does the New Holland T4050 weigh?
The New Holland T4050 weighs about 7,320 lb in operating condition.
What maintenance does the New Holland T4050 require?
The New Holland T4050 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
