Agricultural tractorsSpec sheet
SAME Antares II 130
The SAME Antares II 130 is a powerful 4WD tractor built for tough farm work. It has a strong diesel engine made by SAME with 6 cylinders and 127 horsepower. This engine is air-cooled and turbocharged, which helps it perform well in various conditions. The tractor has a big fuel tank, so you can work for a long time without stopping. This tractor is easy to drive with 18 forward gears and 18 reverse gears. It has a total of 54 gears, giving you lots of options for different jobs. The Antares II 130 is quite big, measuring about 15 feet long and 9 feet tall. It weighs 11,245 pounds, which helps it stay stable during heavy work. The tractor has big agricultural radial tires, with 420/70R30 in the front and 520/70R38 in the back. These tires give good traction in the field and a smooth ride on the road.
Key specifications
- Category
- Agricultural
- Engine power
- 127hp
- Operating weight
- 11,245 lb
Category comparison
Antares II 130 compared with its category
vs. Agricultural medianDistribution
Engine Power (hp)
All recorded Agricultural tractors
127 hp · 59th
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The Antares II 130 ranks at the 59th percentile for engine power among recorded agricultural tractors.
Overview
About the SAME Antares II 130
The SAME Antares II 130 is a powerful 4WD tractor built for tough farm work. It has a strong diesel engine made by SAME with 6 cylinders and 127 horsepower. This engine is air-cooled and turbocharged, which helps it perform well in various conditions. The tractor has a big fuel tank, so you can work for a long time without stopping. This tractor is easy to drive with 18 forward gears and 18 reverse gears. It has a total of 54 gears, giving you lots of options for different jobs. The Antares II 130 is quite big, measuring about 15 feet long and 9 feet tall. It weighs 11,245 pounds, which helps it stay stable during heavy work. The tractor has big agricultural radial tires, with 420/70R30 in the front and 520/70R38 in the back. These tires give good traction in the field and a smooth ride on the road.
Full specifications
Recorded specifications
General
| Manufacturer | SAME |
|---|---|
| Model | Antares II 130 |
| Category | Agricultural tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 11,245lb(5,101 kg) |
Engine
| Make | SAME |
|---|---|
| Power | 127hp(94.7 kW) |
| Cylinders | 6 |
| Displacement | 366.12ci(6 L) |
| Bore | 4.13in(105 mm) |
| Stroke | 4.54in(115.3 mm) |
Transmission
| Forward gears | 18 |
|---|---|
| Reverse gears | 18 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
Dimensions
| Length | 180.71in(4,590 mm) |
|---|---|
| Height | 110.63in(2,810 mm) |
| Operating weight | 11,245lb(5,101 kg) |
Closest alternatives
Antares II 130 compared with the nearest models by horsepower
The closest agricultural models to the SAME Antares II 130 by rated horsepower are the Farmall 1026 and the Landini Legend 130. The Farmall 1026 matches it on rated power and weighs 150 lb less. The Landini Legend 130 matches it on rated power and weighs 880 lb more.
| Spec | SAME Antares II 130 | Farmall 1026 | Landini Legend 130 |
|---|---|---|---|
| Engine power | 127 hp94.7 kW | 127 hp94.7 kW | 127 hp94.7 kW |
| Operating weight | 11,245 lb5,101 kg | 11,100 lb5,035 kg | 12,128 lb5,501 kg |
| Weight per hp | 89 lb/hp54 kg/kW | 87 lb/hp53 kg/kW | 95 lb/hp58 kg/kW |
| Displacement | 366.1 ci6 L | 406.9 ci6.67 L | 366.1 ci6 L |
| Cylinders | 6 | 6 | 6 |
| Drive | 4WD | - | 4WD |
Calculators
Calculators for the Antares II 130
PTO power
About 105 to 114 PTO hp
Estimated from the 127 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 127 hp tractor can run
Maximum size is about a 15 ft rotary cutter or a 13 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
103 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
127 hp is 94.7 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the SAME Antares II 130
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the SAMEAmazon
Fits the SAME 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the SAMEAmazon
Fits the SAME 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the SAMEAmazon
Fits the SAME 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the SAMEAmazon
Fits the SAME 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- SAME Antares II 130 service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- SAME Antares II 130 operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- SAME Antares II 130 service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
Antares II 130 vs. Agricultural median
SAME Antares II 130 compared with other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 127 hp | 110 hp | +15% | 59th |
| Engine Displacement | 366 ci | 336 ci | +9% | 59th |
| Cylinders | 6 | 5.5 | +9% | 74th |
| Forward Gears | 18 | 16 | +13% | 68th |
| Operating Weight | 11,245 lb | 10,914 lb | +3% | 52nd |
| Length | 181 in | 173 in | +5% | 59th |
| Height | 111 in | 111 in | 0% | 50th |
Medians and percentiles are calculated from the agricultural tractors in the database that have a recorded value for each specification (sample size 795–1,130 models).
Same manufacturer
Other SAME models
Other manufacturers
Models with similar horsepower
Gallery
SAME Antares II 130 photos
FAQ
Frequently asked questions
What is the engine power output of the SAME Antares II 130?
Rated engine output for the SAME Antares II 130 is 127 hp, delivered by a 6-cylinder engine. The engine displaces 366.12 ci.
What is the operating weight of the SAME Antares II 130?
The SAME Antares II 130 has an operating weight of about 11,245 lb.
How do I maintain a SAME Antares II 130?
Routine service for the SAME Antares II 130 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
