Shibaura Ford 1100

Shibaura Ford 1100

Complete specifications and technical data for the Shibaura Ford 1100. Compare with similar tractors from Shibaura and other manufacturers.

Jump to Full Specifications List

Quick Specs

Category

Utility

Engine Power Output

13hp

Operating Weight

1,231 lb

Transmission

Gear shift

The Shibaura Ford 1100 is a small utility tractor made from 1979 to 1982. It has a 2WD chassis and a manual steering system. The tractor uses a gear shift transmission with 10 forward gears and 2 reve...

Photo Gallery

Image Gallery
Shibaura Ford 1100 Tractor
Shibaura Ford 1100 Tractor
Shibaura Ford 1100 Tractor
Shibaura Ford 1100 Tractor
Shibaura Ford 1100 Tractor

Specifications

Manufacturer
Shibaura
Model
Ford 1100
Category
Utility
Manufacturing Years
1979 - 1982
Manufacturer
Shibaura
Model
LEK752C2
Power Output
13hp
Rated RPM
2,600RPM
Cylinders
2
Displacement
43.1ci
Bore
2.95in
Stroke
3.15in

Engine Power Output Comparison of Shibaura Ford 1100 vs. Other Utility Tractors

Loading Chart...

Type
Gear shift
Length
94.9in
Width
42in
Height
79in
Operating Weight
1,231lb

Operating Weight Comparison of Shibaura Ford 1100 vs. Other Utility Tractors

Loading Chart...

System Type
Open center
Steering Type
Manual
Type
Rear, transmission
Speed 1
540rpm
Hitch Type
Three-Point Hitch Category I
Hitch Category
I
Hitch Position
Rear
Hitch Capacity
881lb
Chassis Type
4x2 2WD
Drive Type
2WD
Steering Type
Manual
Brake Type
Differential mechanical drum
Coolant
3.2qts
Type
ROPS

Compare to Other Tractors

Frequently Asked Questions

What years was the Shibaura Ford 1100 manufactured?

The Shibaura Ford 1100 was manufactured from 1979 - 1982.

What is the engine power output of the Shibaura Ford 1100?

The Shibaura Ford 1100 has an engine power output of 13 hp.

How many cylinders does the Shibaura Ford 1100 have?

The Shibaura Ford 1100 is equipped with a 2-cylinder engine.

What is the operating weight of the Shibaura Ford 1100?

The operating weight of the Shibaura Ford 1100 is approximately 1,231 lb.

What type of transmission does the Shibaura Ford 1100 have?

The Shibaura Ford 1100 is equipped with a Gear shift transmission.

What type of hydraulic system does the Shibaura Ford 1100 use?

The Shibaura Ford 1100 uses a Open center hydraulic system.

What hitch category is the Shibaura Ford 1100?

The Shibaura Ford 1100 is a Category I hitch.

What maintenance does the Shibaura Ford 1100 require?

Regular maintenance for the Shibaura Ford 1100 includes checking and changing engine oil, hydraulic fluid, filters, and performing routine inspections as recommended in the owner's manual. Always refer to the manufacturer's maintenance schedule for specific intervals and procedures.
