Shibaura SU1301
The Shibaura SU1301 is a small utility tractor designed for light work. It has a 2WD drive system and a 4x2 chassis, making it suitable for basic farm tasks. The tractor is compact, measuring 82 inches long, 38 inches wide, and 70 inches tall. It's also lightweight at 1,283 pounds, which is below average for tractors. This tractor is powered by a Shibaura LEK 752C engine. It's a 2-cylinder diesel engine that's liquid-cooled and naturally aspirated. The engine has a very small displacement of 43.1 cubic inches, with a bore of 2.95 inches and a stroke of 3.15 inches. It produces 13 horsepower at 2,600 RPM, which is a low power output compared to many other tractors. The engine's RPM is above average, though. The SU1301 uses a 12-volt electrical system and has an electric starter for easy operation.
ManufacturerShibauraPower13 hpEngine2-cyl
Quick specs
- Category
- Utility
- Engine Power Output
- 13hp
- Operating Weight
- 1,283 lb
At a glance
How the SU1301 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
13 hp · 1st
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The SU1301 ranks at the 1st percentile for engine power among recorded utility tractors.
Overview
About the Shibaura SU1301
The Shibaura SU1301 is a small utility tractor designed for light work. It has a 2WD drive system and a 4x2 chassis, making it suitable for basic farm tasks. The tractor is compact, measuring 82 inches long, 38 inches wide, and 70 inches tall. It's also lightweight at 1,283 pounds, which is below average for tractors. This tractor is powered by a Shibaura LEK 752C engine. It's a 2-cylinder diesel engine that's liquid-cooled and naturally aspirated. The engine has a very small displacement of 43.1 cubic inches, with a bore of 2.95 inches and a stroke of 3.15 inches. It produces 13 horsepower at 2,600 RPM, which is a low power output compared to many other tractors. The engine's RPM is above average, though. The SU1301 uses a 12-volt electrical system and has an electric starter for easy operation.
Full specifications
Every recorded spec
General
| Manufacturer | Shibaura |
|---|---|
| Model | SU1301 |
| Category | Utility tractor |
| Type | 4x2 |
| Operating weight | 1,283lb |
Engine
| Make | Shibaura |
|---|---|
| Model | LEK 752C |
| Power | 13hp |
| Cylinders | 2 |
| Displacement | 43.1ci |
| Bore | 2.95in |
| Stroke | 3.15in |
Chassis & drive
| Chassis | 4x2 |
|---|---|
| Drive | 2WD |
Dimensions
| Length | 82in |
|---|---|
| Width | 38in |
| Height | 70in |
| Operating weight | 1,283lb |
Head to head
SU1301 vs. Utility median
How the Shibaura SU1301 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 13 hp | 55 hp | -76% | 1st |
| Engine Displacement | 43.1 ci | 183 ci | -76% | 1st |
| Cylinders | 2 | 4 | -50% | 3rd |
| Operating Weight | 1,283 lb | 5,303 lb | -76% | 3rd |
| Length | 82 in | 137 in | -40% | 3rd |
| Width | 38 in | 66 in | -42% | 2nd |
| Height | 70 in | 94.1 in | -26% | 16th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Shibaura tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Shibaura Ford 1100 | 13 hp | 1,231 lb | 1979–1982 | Compare → |
| Shibaura SE1340 | 13 hp | 1,122 lb | — | Compare → |
| Shibaura SU1341 | 13 hp | 1,417 lb | — | Compare → |
| Shibaura SD1300 | 12.8 hp | 1,168 lb | — | Compare → |
| Shibaura SP1440 | 14 hp | 1,091 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Bolens 1250 | 12.5 hp | 974 lb | 1967–1969 | Compare → |
| Cub Cadet 1315 | 12.5 hp | 985 lb | 1989–1991 | Compare → |
| Cub Cadet 1320 | 12.5 hp | 467 lb | 1989–1991 | Compare → |
| Cub Cadet 1330 | 12.5 hp | 489 lb | — | Compare → |
| Bolens 3212G | 12 hp | 463 lb | 1987–1992 | Compare → |
Explore
Shibaura siblings
Explore
Similar-spec models
Gallery
Shibaura SU1301 photos
FAQ
Common questions
What is the engine power output of the Shibaura SU1301?
Rated engine output for the Shibaura SU1301 is 13 hp, delivered by a 2-cylinder engine. The engine displaces 43.1 ci.
What is the operating weight of the Shibaura SU1301?
In working trim, the Shibaura SU1301 comes in at roughly 1,283 lb.
How do I maintain a Shibaura SU1301?
Routine service for the Shibaura SU1301 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
