UtilityPerformance profile
CaseIH CS 63
The CaseIH CS 63 is a utility tractor built for farmers who need a reliable workhorse. It has a 2WD chassis and power steering, making it easy to handle in the field. The tractor comes with a synchronized transmission that offers 16 forward gears and 8 reverse gears, giving drivers plenty of options for different tasks. Under the hood, the CS 63 boasts a Perkins 903.27T engine. This 3-cylinder diesel engine is turbocharged and liquid-cooled, providing 63 horsepower at 2250 RPM. The engine's power output is above average compared to other tractors in its class. It has a displacement of 164.8 cubic inches, which is about average. The tractor weighs 5975 pounds, making it a sturdy machine for various farm jobs. It measures 140.6 inches long and 74.8 inches wide, with a cab height of 92.9 inches. The CS 63 rides on agricultural tires, with larger rear tires for better traction in the field.
ManufacturerCaseIHPower63 hpEngine3-cylTransSynchronized
Quick specs
- Category
- Utility
- Engine Power Output
- 63hp
- Operating Weight
- 5,975 lb
- Transmission
- Synchronized
At a glance
How the CS 63 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
63 hp · 57th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The CS 63 ranks at the 57th percentile for engine power among recorded utility tractors.
Overview
About the CaseIH CS 63
The CaseIH CS 63 is a utility tractor built for farmers who need a reliable workhorse. It has a 2WD chassis and power steering, making it easy to handle in the field. The tractor comes with a synchronized transmission that offers 16 forward gears and 8 reverse gears, giving drivers plenty of options for different tasks. Under the hood, the CS 63 boasts a Perkins 903.27T engine. This 3-cylinder diesel engine is turbocharged and liquid-cooled, providing 63 horsepower at 2250 RPM. The engine's power output is above average compared to other tractors in its class. It has a displacement of 164.8 cubic inches, which is about average. The tractor weighs 5975 pounds, making it a sturdy machine for various farm jobs. It measures 140.6 inches long and 74.8 inches wide, with a cab height of 92.9 inches. The CS 63 rides on agricultural tires, with larger rear tires for better traction in the field.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | CS 63 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Operating weight | 5,975lb |
Engine
| Make | Perkins |
|---|---|
| Model | 903.27T |
| Power | 63hp |
| Cylinders | 3 |
| Displacement | 164.8ci |
| Bore | 3.74in |
| Stroke | 5in |
Transmission
| Type | Synchronized |
|---|---|
| Forward gears | 16 |
| Reverse gears | 8 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power |
Dimensions
| Length | 140.6in |
|---|---|
| Width | 74.8in |
| Operating weight | 5,975lb |
Head to head
CS 63 vs. Utility median
How the CaseIH CS 63 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 63 hp | 55 hp | +15% | 57th |
| Engine Displacement | 165 ci | 183 ci | -10% | 44th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 16 | 12 | +33% | 73rd |
| Operating Weight | 5,975 lb | 5,303 lb | +13% | 56th |
| Length | 141 in | 137 in | +3% | 56th |
| Width | 74.8 in | 66 in | +13% | 70th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH C60 | 64 hp | 7,605 lb | — | Compare → |
| CaseIH Farmall 65A | 64 hp | 5,059 lb | — | Compare → |
| CaseIH Farmall 65C | 64 hp | 5,776 lb | — | Compare → |
| CaseIH JX70 | 62 hp | 5,152 lb | — | Compare → |
| CaseIH Farmall 70 | 65 hp | 5,152 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers D17 | 63 hp | 4,675 lb | 1957–1967 | Compare → |
| Allis Chalmers 6060 | 63.21 hp | 6,465 lb | 1980–1984 | Compare → |
| Barreiros 70.7 | 64 hp | 5,450 lb | — | Compare → |
| Belarus 500 | 65 hp | 6,100 lb | — | Compare → |
| Barreiros R-500 B | 60 hp | — | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH CS 63 photos
FAQ
Common questions
How much horsepower does the CaseIH CS 63 have?
The CaseIH CS 63 produces 63 hp from its 3-cylinder engine. Engine displacement is 164.8 ci.
How much does the CaseIH CS 63 weigh?
The CaseIH CS 63 weighs about 5,975 lb in operating condition.
What transmission is in the CaseIH CS 63?
Transmission on the CaseIH CS 63 is Synchronized, with 16 forward speeds.
What maintenance does the CaseIH CS 63 require?
Like any tractor, the CaseIH CS 63 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
