CaseIH Farmall 65A

CaseIH Farmall 65A

Complete specifications and technical data for the CaseIH Farmall 65A. Compare with similar tractors from CaseIH and other manufacturers.

Jump to Full Specifications List

Quick Specs

Category

Utility

Engine Power Output

64hp

Operating Weight

5,059 lb

Transmission

8-speed partially synchronized

The CaseIH Farmall 65A is a utility tractor built for various farm tasks. It has a 2WD drive system and hydrostatic power steering, making it easy to control. The tractor uses an 8-speed transmission ...

Photo Gallery

Image Gallery
CaseIH Farmall 65A Tractor
CaseIH Farmall 65A Tractor
CaseIH Farmall 65A Tractor

Specifications

Manufacturer
CaseIH
Model
Farmall 65A
Category
Utility
Manufacturer
FPT (Fiat Powertrain Technologies)
Power Output
64hp
Rated RPM
2,500RPM
Cylinders
4
Displacement
195ci
Bore
4.09in
Stroke
4.53in

Engine Power Output Comparison of CaseIH Farmall 65A vs. Other Utility Tractors

Loading Chart...

Type
8-speed partially synchronized
Length
137.2in
Width
78.4in
Height
96.9in
Operating Weight
5,059lb

Operating Weight Comparison of CaseIH Farmall 65A vs. Other Utility Tractors

Loading Chart...

System Type
Open center fixed displacement gear pump
Steering Type
Hydrostatic Power
Front Tread Width
7.5in
Rear Tread
16.9in
Adjustable Tread
No
Hitch Type
Rear Type
Hitch Category
II/I
Hitch Position
Rear
Chassis Type
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic Power
Coolant
8.5qts

Compare to Other Tractors

Frequently Asked Questions

What is the engine power output of the CaseIH Farmall 65A?

The CaseIH Farmall 65A has an engine power output of 64 hp.

How many cylinders does the CaseIH Farmall 65A have?

The CaseIH Farmall 65A is equipped with a 4-cylinder engine.

What is the operating weight of the CaseIH Farmall 65A?

The operating weight of the CaseIH Farmall 65A is approximately 5,059 lb.

What type of transmission does the CaseIH Farmall 65A have?

The CaseIH Farmall 65A is equipped with a 8-speed partially synchronized transmission.

What type of hydraulic system does the CaseIH Farmall 65A use?

The CaseIH Farmall 65A uses a Open center fixed displacement gear pump hydraulic system.

What hitch category is the CaseIH Farmall 65A?

The CaseIH Farmall 65A is a Category II/I hitch.

What maintenance does the CaseIH Farmall 65A require?

Regular maintenance for the CaseIH Farmall 65A includes checking and changing engine oil, hydraulic fluid, filters, and performing routine inspections as recommended in the owner's manual. Always refer to the manufacturer's maintenance schedule for specific intervals and procedures.
