UtilityPerformance profile
CaseIH DX29
The CaseIH DX29 is a utility tractor built for versatile farm work. It has a 4-wheel drive system, which helps it move well in tough conditions. The tractor uses a hydrostatic transmission, letting the driver change speeds smoothly without shifting gears. Under the hood, the DX29 has a Shibaura diesel engine with 3 cylinders. The engine is liquid-cooled and naturally aspirated, producing 29 horsepower at 2800 rpm. While its engine size is below average, it runs at a very high speed compared to other tractors. The DX29 has a Category I rear hitch for attaching various tools. It also comes with helpful features like glow plugs for easy starting in cold weather and a dual-element air cleaner to keep the engine running clean.
ManufacturerCaseIHPower29 hpEngine3-cylTransHydrostatic
Quick specs
- Category
- Utility
- Engine Power Output
- 29hp
- Transmission
- Hydrostatic
At a glance
How the DX29 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
29 hp · 21st
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The DX29 ranks at the 21st percentile for engine power among recorded utility tractors.
Overview
About the CaseIH DX29
The CaseIH DX29 is a utility tractor built for versatile farm work. It has a 4-wheel drive system, which helps it move well in tough conditions. The tractor uses a hydrostatic transmission, letting the driver change speeds smoothly without shifting gears. Under the hood, the DX29 has a Shibaura diesel engine with 3 cylinders. The engine is liquid-cooled and naturally aspirated, producing 29 horsepower at 2800 rpm. While its engine size is below average, it runs at a very high speed compared to other tractors. The DX29 has a Category I rear hitch for attaching various tools. It also comes with helpful features like glow plugs for easy starting in cold weather and a dual-element air cleaner to keep the engine running clean.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | DX29 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
Engine
| Make | Shibaura |
|---|---|
| Power | 29hp |
| Cylinders | 3 |
| Displacement | 81.2ci |
Transmission
| Type | Hydrostatic |
|---|
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
Head to head
DX29 vs. Utility median
How the CaseIH DX29 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 29 hp | 55 hp | -47% | 21st |
| Engine Displacement | 81.2 ci | 183 ci | -56% | 13th |
| Cylinders | 3 | 4 | -25% | 23rd |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 5,383–5,720 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH Farmall DX29 | 29 hp | 2,474 lb | — | Compare → |
| CaseIH Farmall 30B | 28 hp | 3,121 lb | — | Compare → |
| CaseIH 265 | 27 hp | 2,320 lb | — | Compare → |
| CaseIH 275 | 31 hp | 2,600 lb | — | Compare → |
| CaseIH Farmall DX31 | 31 hp | 2,544 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers D10 | 28.57 hp | 2,700 lb | 1959–1967 | Compare → |
| AGCO ST28A | 28.4 hp | 2,400 lb | — | Compare → |
| AGCO ST30x | 28.4 hp | 1,984 lb | — | Compare → |
| AGCO ST30 | 30.3 hp | 2,594 lb | — | Compare → |
| Allis Chalmers D272 | 27.5 hp | 2,060 lb | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH DX29 photos
FAQ
Common questions
How much horsepower does the CaseIH DX29 have?
The CaseIH DX29 produces 29 hp from its 3-cylinder engine. Engine displacement is 81.2 ci.
What hitch category is the CaseIH DX29?
The CaseIH DX29 uses a Category I hitch.
What transmission is in the CaseIH DX29?
Transmission on the CaseIH DX29 is Hydrostatic.
What maintenance does the CaseIH DX29 require?
Like any tractor, the CaseIH DX29 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
