CaseIH STX530
The CaseIH STX530 is a powerful four-wheel drive tractor built for heavy-duty farm work. It has a strong 4x4 articulated chassis and uses hydrostatic power steering for easy control. The tractor comes with a full power shift transmission that offers 16 forward gears and 2 reverse gears, giving farmers lots of options for different tasks. Under the hood, the STX530 boasts a Cummins QSX15 engine. This diesel engine is turbocharged and liquid-cooled, with 6 cylinders and 24 valves. It produces an impressive 530 horsepower at 2100 RPM, making it suitable for tough jobs. The tractor weighs 54,000 pounds, which helps it grip the ground well. It has a three-point hitch at the back, rated as category IVN, for attaching various farm tools. The hydraulic system is pressure flow compensated, and the brakes are electro-hydraulic wet disc type for reliable stopping power.
ManufacturerCaseIHPower530 hpEngine6-cylTransFull power shift
Quick specs
- Category
- Four-Wheel Drive
- Engine Power Output
- 530hp
- Operating Weight
- 54,000 lb
- Transmission
- Full power shift
At a glance
How the STX530 compares
vs. Four-Wheel Drive medianDistribution
Engine Power (hp)
Across all Four-Wheel Drive tractors
530 hp · 81st
This model
84
Median 375 hp
549
This modelFour-Wheel Drive tractorsMediann = 162
The STX530 ranks at the 81st percentile for engine power among recorded four-wheel drive tractors.
Overview
About the CaseIH STX530
The CaseIH STX530 is a powerful four-wheel drive tractor built for heavy-duty farm work. It has a strong 4x4 articulated chassis and uses hydrostatic power steering for easy control. The tractor comes with a full power shift transmission that offers 16 forward gears and 2 reverse gears, giving farmers lots of options for different tasks. Under the hood, the STX530 boasts a Cummins QSX15 engine. This diesel engine is turbocharged and liquid-cooled, with 6 cylinders and 24 valves. It produces an impressive 530 horsepower at 2100 RPM, making it suitable for tough jobs. The tractor weighs 54,000 pounds, which helps it grip the ground well. It has a three-point hitch at the back, rated as category IVN, for attaching various farm tools. The hydraulic system is pressure flow compensated, and the brakes are electro-hydraulic wet disc type for reliable stopping power.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | STX530 |
| Category | Four-Wheel Drive tractor |
| Type | 4x4 articulated 4WD |
| Operating weight | 54,000lb |
Engine
| Make | Cummins |
|---|---|
| Model | QSX15 |
| Power | 530hp |
| Cylinders | 6 |
| Displacement | 912ci |
| Bore | 5.39in |
| Stroke | 6.65in |
Transmission
| Type | Full power shift |
|---|---|
| Forward gears | 16 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x4 articulated 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
| Brakes | Electro-hydraulic wet disc |
Hydraulics
| Type | Pressure flow compensated |
|---|
Dimensions
| Operating weight | 54,000lb |
|---|
Head to head
STX530 vs. Four-Wheel Drive median
How the CaseIH STX530 compares to other Four-Wheel Drive tractors
| Spec | This model | Four-Wheel Drive median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 530 hp | 375 hp | +41% | 81st |
| Engine Displacement | 912 ci | 826 ci | +10% | 78th |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 16 | 16 | at median | 50th |
| Operating Weight | 54,000 lb | 37,428 lb | +44% | 93rd |
Medians and percentiles are computed from the four-wheel drive tractors in our database with a recorded value for each spec (sample sizes 132–162 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH Steiger 540 | 535 hp | 43,855 lb | — | Compare → |
| CaseIH Steiger 550 | 550 hp | 44,046 lb | — | Compare → |
| CaseIH Steiger 500 | 500 hp | 39,492 lb | — | Compare → |
| CaseIH STX500 | 500 hp | 54,000 lb | — | Compare → |
| CaseIH Steiger 485 | 485 hp | 38,500 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Challenger MT865C | 533.87 hp | 43,125 lb | — | Compare → |
| Baldwin DM525 | 525 hp | — | — | Compare → |
| Baldwin DP525 | 525 hp | — | — | Compare → |
| Big Bud 525/20 | 525 hp | — | — | Compare → |
| Big Bud 525/50 | 525 hp | 52,000 lb | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH STX530 photos
FAQ
Common questions
What is the engine power output of the CaseIH STX530?
Rated engine output for the CaseIH STX530 is 530 hp, delivered by a 6-cylinder engine. The engine displaces 912 ci.
What hitch category is the CaseIH STX530?
The CaseIH STX530 uses a Category IVN hitch.
What is the operating weight of the CaseIH STX530?
In working trim, the CaseIH STX530 comes in at roughly 54,000 lb.
Which transmission does the CaseIH STX530 use?
The CaseIH STX530 is equipped with a Full power shift transmission with 16 forward gears.
What type of hydraulic system does the CaseIH STX530 use?
Hydraulics on the CaseIH STX530 are Pressure flow compensated.
How do I maintain a CaseIH STX530?
Routine service for the CaseIH STX530 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
