Hinomoto E202
The Hinomoto E202 is a compact diesel tractor that packs a punch. It's powered by a Toyosha CS112 engine, which is liquid-cooled and has 3 cylinders. This engine can produce 19.7 hp at 2500 rpm, making it suitable for various farm tasks. The E202 measures 108 inches long, 48 inches wide, and 73 inches tall. It weighs 1905 lb, which is fairly light for a tractor of its size. The tractor has a 6-speed forward and 2-speed reverse transmission, giving the operator good control over speed and power. It also features a Category 3 hitch, which allows it to work with a wide range of attachments. With its compact size and decent power, the Hinomoto E202 is a versatile choice for small to medium-sized farms.
ManufacturerHinomotoPower19.7 hpEngine3-cyl
Quick specs
- Category
- Lawn and Garden
- Engine Power Output
- 20hp
- Operating Weight
- 1,905 lb
At a glance
How the E202 compares
vs. Lawn and Garden medianDistribution
Engine Power (hp)
Across all Lawn and Garden tractors
19.7 hp · 54th
This model
4
Median 18 hp
28
This modelLawn and Garden tractorsMediann = 380
The E202 ranks at the 54th percentile for engine power among recorded lawn and garden tractors.
Overview
About the Hinomoto E202
The Hinomoto E202 is a compact diesel tractor that packs a punch. It's powered by a Toyosha CS112 engine, which is liquid-cooled and has 3 cylinders. This engine can produce 19.7 hp at 2500 rpm, making it suitable for various farm tasks. The E202 measures 108 inches long, 48 inches wide, and 73 inches tall. It weighs 1905 lb, which is fairly light for a tractor of its size. The tractor has a 6-speed forward and 2-speed reverse transmission, giving the operator good control over speed and power. It also features a Category 3 hitch, which allows it to work with a wide range of attachments. With its compact size and decent power, the Hinomoto E202 is a versatile choice for small to medium-sized farms.
Full specifications
Every recorded spec
General
| Manufacturer | Hinomoto |
|---|---|
| Model | E202 |
| Category | Lawn and Garden tractor |
| Operating weight | 1,905lb |
Engine
| Make | Toyosha |
|---|---|
| Model | CS112 |
| Power | 19.7hp |
| Cylinders | 3 |
| Displacement | 68.7ci |
| Bore | 2.95in |
| Stroke | 3.35in |
Transmission
| Forward gears | 6 |
|---|---|
| Reverse gears | 2 |
Dimensions
| Length | 108in |
|---|---|
| Width | 48in |
| Height | 73in |
| Operating weight | 1,905lb |
Head to head
E202 vs. Lawn and Garden median
How the Hinomoto E202 compares to other Lawn and Garden tractors
| Spec | This model | Lawn and Garden median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 19.7 hp | 18 hp | +9% | 54th |
| Engine Displacement | 68.7 ci | 41.1 ci | +67% | 86th |
| Cylinders | 3 | 2 | +50% | 87th |
| Forward Gears | 6 | 6 | at median | 50th |
| Operating Weight | 1,905 lb | 738 lb | +158% | 85th |
| Length | 108 in | 71.7 in | +51% | 92nd |
| Width | 48 in | 43.3 in | +11% | 66th |
| Height | 73 in | 42.9 in | +70% | 90th |
Medians and percentiles are computed from the lawn and garden tractors in our database with a recorded value for each spec (sample sizes 152–380 models).
Compare to tractors with similar specs
Commonly compared Hinomoto tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Hinomoto C172 | 19.7 hp | 1,280 lb | — | Compare → |
| Hinomoto E2002 | 20 hp | 2,033 lb | — | Compare → |
| Hinomoto E21 | 21 hp | 1,973 lb | — | Compare → |
| Hinomoto E14 | 13.8 hp | 1,538 lb | — | Compare → |
| Hinomoto E2802 | 35 hp | 2,755 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 620 | 19.5 hp | 1,499 lb | 1973–1975 | Compare → |
| Allis Chalmers 720 | 19.5 hp | 1,299 lb | 1975–1983 | Compare → |
| Bolens HT20 | 19.5 hp | 1,091 lb | 1973–1978 | Compare → |
| Ag King AK2040 | 20 hp | 2,470 lb | — | Compare → |
| Ariens GT20 | 20 hp | 959 lb | 1988–1995 | Compare → |
Explore
Hinomoto siblings
Explore
Similar-spec models
Gallery
Hinomoto E202 photos
FAQ
Common questions
What is the engine power output of the Hinomoto E202?
Rated engine output for the Hinomoto E202 is 19.7 hp, delivered by a 3-cylinder engine. The engine displaces 68.7 ci.
What hitch category is the Hinomoto E202?
The Hinomoto E202 uses a Category Category 3 hitch.
What is the operating weight of the Hinomoto E202?
In working trim, the Hinomoto E202 comes in at roughly 1,905 lb.
How do I maintain a Hinomoto E202?
Routine service for the Hinomoto E202 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
