IMT 539
The IMT 539 is a compact 2WD tractor designed for various farming tasks. It features a manual steering system and a straightforward transmission with 6 forward gears and 2 reverse gears. This setup gives farmers good control over their work in different field conditions. The tractor is powered by an IMT M33/T diesel engine. This engine has 3 cylinders and is naturally aspirated, meaning it doesn't use a turbocharger. It produces 39 horsepower at 2000 RPM, which is suitable for small to medium-sized farms. The engine has a displacement of 152.6 cubic inches, with a bore of 3.6 inches and a stroke of 5 inches. The IMT 539 rides on agricultural tires, with 6.00-16 tires in front and larger 11.2-28 tires in the rear for better traction. It measures 116.9 inches long and 79.9 inches tall, making it compact enough to work in tight spaces. With an operating weight of 3594 pounds, it's sturdy enough for most farm jobs without being too heavy.
ManufacturerIMTPower39 hpEngine3-cylTransManual
Quick specs
- Category
- Sub-Compact
- Engine Power Output
- 39hp
- Operating Weight
- 3,594 lb
- Transmission
- Manual
At a glance
How the 539 compares
vs. Sub-Compact medianDistribution
Engine Power (hp)
Across all Sub-Compact tractors
39 hp · 73rd
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The 539 ranks at the 73rd percentile for engine power among recorded sub-compact tractors.
Overview
About the IMT 539
The IMT 539 is a compact 2WD tractor designed for various farming tasks. It features a manual steering system and a straightforward transmission with 6 forward gears and 2 reverse gears. This setup gives farmers good control over their work in different field conditions. The tractor is powered by an IMT M33/T diesel engine. This engine has 3 cylinders and is naturally aspirated, meaning it doesn't use a turbocharger. It produces 39 horsepower at 2000 RPM, which is suitable for small to medium-sized farms. The engine has a displacement of 152.6 cubic inches, with a bore of 3.6 inches and a stroke of 5 inches. The IMT 539 rides on agricultural tires, with 6.00-16 tires in front and larger 11.2-28 tires in the rear for better traction. It measures 116.9 inches long and 79.9 inches tall, making it compact enough to work in tight spaces. With an operating weight of 3594 pounds, it's sturdy enough for most farm jobs without being too heavy.
Full specifications
Every recorded spec
General
| Manufacturer | IMT |
|---|---|
| Model | 539 |
| Category | Sub-Compact tractor |
| Type | 4x2 2WD |
| Operating weight | 3,594lb |
Engine
| Make | IMT |
|---|---|
| Model | M33/T |
| Power | 39hp |
| Cylinders | 3 |
| Displacement | 152.6ci |
| Bore | 3.6in |
| Stroke | 5in |
Transmission
| Type | Manual |
|---|---|
| Forward gears | 6 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Manual |
Dimensions
| Length | 116.9in |
|---|---|
| Height | 79.9in |
| Operating weight | 3,594lb |
Tires
| Front | 6.00-16 |
|---|---|
| Rear | 11.2-28 |
Head to head
539 vs. Sub-Compact median
How the IMT 539 compares to other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 39 hp | 26.9 hp | +45% | 73rd |
| Engine Displacement | 153 ci | 91.4 ci | +67% | 85th |
| Cylinders | 3 | 3 | at median | 50th |
| Forward Gears | 6 | 9 | -33% | 18th |
| Operating Weight | 3,594 lb | 2,700 lb | +33% | 68th |
| Length | 117 in | 113 in | +3% | 55th |
| Height | 79.9 in | 78.4 in | +2% | 53rd |
Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 616–816 models).
Compare to tractors with similar specs
Commonly compared IMT tractors
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Advance-Rumely OilPull K 12/20 | 40 hp | 6,430 lb | — | Compare → |
| Allis Chalmers 160 | 40 hp | 4,674 lb | 1970–1975 | Compare → |
| Allis Chalmers 5040 | 40 hp | 3,858 lb | 1976–1980 | Compare → |
| Allis Chalmers 6140 | 40 hp | 4,000 lb | 1982–1985 | Compare → |
| Allis Chalmers D15 Series I | 40 hp | 3,990 lb | 1960–1963 | Compare → |
Explore
IMT siblings
Explore
Similar-spec models
Gallery
IMT 539 photos
FAQ
Common questions
What is the engine power output of the IMT 539?
Rated engine output for the IMT 539 is 39 hp, delivered by a 3-cylinder engine. The engine displaces 152.6 ci.
Which transmission does the IMT 539 use?
The IMT 539 is equipped with a Manual transmission with 6 forward gears.
What are the factory tire sizes for the IMT 539?
The IMT 539 comes with 6.00-16 front tires and 11.2-28 rear tires.
What is the operating weight of the IMT 539?
In working trim, the IMT 539 comes in at roughly 3,594 lb.
How do I maintain a IMT 539?
Routine service for the IMT 539 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
