John Deere 930VU
The John Deere 930VU is a compact tractor designed for orchards and vineyards. It's a 2WD model with a manual steering system, making it easy to maneuver in tight spaces. The tractor has a 12-speed transmission with 8 forward and 4 reverse gears, giving farmers good control over their work speed. Under the hood, the 930VU has a John Deere diesel engine with 3 cylinders. The engine is liquid-cooled and produces 40.2 hp at 2500 rpm, which is enough power for most orchard tasks. It has a below-average engine displacement of 164.5 ci, but its rated rpm is very high compared to other tractors. The tractor's compact size, measuring 97.6 inches long, 38.6 inches wide, and 45.3 inches high at the hood, makes it perfect for working between tree rows. It comes with agricultural tires, a rear-mounted Type I hitch, and an open center hydraulic system for attaching various implements.
ManufacturerJohn DeerePower40.2 hpEngine3-cyl
Quick specs
- Category
- Agricultural
- Engine Power Output
- 40hp
At a glance
How the 930VU compares
vs. Agricultural medianDistribution
Engine Power (hp)
Across all Agricultural tractors
40.2 hp · 6th
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The 930VU ranks at the 6th percentile for engine power among recorded agricultural tractors.
Overview
About the John Deere 930VU
The John Deere 930VU is a compact tractor designed for orchards and vineyards. It's a 2WD model with a manual steering system, making it easy to maneuver in tight spaces. The tractor has a 12-speed transmission with 8 forward and 4 reverse gears, giving farmers good control over their work speed. Under the hood, the 930VU has a John Deere diesel engine with 3 cylinders. The engine is liquid-cooled and produces 40.2 hp at 2500 rpm, which is enough power for most orchard tasks. It has a below-average engine displacement of 164.5 ci, but its rated rpm is very high compared to other tractors. The tractor's compact size, measuring 97.6 inches long, 38.6 inches wide, and 45.3 inches high at the hood, makes it perfect for working between tree rows. It comes with agricultural tires, a rear-mounted Type I hitch, and an open center hydraulic system for attaching various implements.
Full specifications
Every recorded spec
General
| Manufacturer | John Deere |
|---|---|
| Model | 930VU |
| Category | Agricultural tractor |
| Type | 4x2 2WD |
Engine
| Make | John Deere |
|---|---|
| Power | 40.2hp |
| Cylinders | 3 |
| Displacement | 164.5ci |
| Bore | 4.02in |
| Stroke | 4.33in |
Transmission
| Forward gears | 8 |
|---|---|
| Reverse gears | 4 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Manual |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Length | 97.6in |
|---|---|
| Width | 38.6in |
| Height | 45.3in |
Capacities
| Cooling system | 2.65gal |
|---|
Head to head
930VU vs. Agricultural median
How the John Deere 930VU compares to other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 40.2 hp | 110 hp | -63% | 6th |
| Engine Displacement | 165 ci | 336 ci | -51% | 8th |
| Cylinders | 3 | 5.5 | -45% | 8th |
| Forward Gears | 8 | 16 | -50% | 16th |
| Length | 97.6 in | 173 in | -44% | 2nd |
| Width | 38.6 in | 79.5 in | -51% | 2nd |
| Height | 45.3 in | 111 in | -59% | 2nd |
Medians and percentiles are computed from the agricultural tractors in our database with a recorded value for each spec (sample sizes 497–1,130 models).
Compare to tractors with similar specs
Commonly compared John Deere tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| John Deere 1445F | 41.4 hp | 4,057 lb | — | Compare → |
| John Deere 1420 | 43 hp | 2,350 lb | — | Compare → |
| John Deere 1020 VU | 44 hp | 3,770 lb | — | Compare → |
| John Deere 1546F | 45 hp | 4,905 lb | — | Compare → |
| John Deere 45R | 35 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO ST40 | 40.1 hp | 3,323 lb | — | Compare → |
| AGCO ST41A | 40.1 hp | 3,000 lb | — | Compare → |
| Advance-Rumely OilPull K 12/20 | 40 hp | 6,430 lb | — | Compare → |
| Allis Chalmers 160 | 40 hp | 4,674 lb | 1970–1975 | Compare → |
| Allis Chalmers 5040 | 40 hp | 3,858 lb | 1976–1980 | Compare → |
Explore
John Deere siblings
Explore
Similar-spec models
Gallery
John Deere 930VU photos
FAQ
Common questions
How much horsepower does the John Deere 930VU have?
The John Deere 930VU produces 40.2 hp from its 3-cylinder engine. Engine displacement is 164.5 ci.
What type of hydraulic system does the John Deere 930VU use?
Hydraulics on the John Deere 930VU are Open Center.
What maintenance does the John Deere 930VU require?
Like any tractor, the John Deere 930VU needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
