Agricultural tractorsSpec sheet
Landini Rex 65
The Landini Rex 65 is a versatile tractor designed for both agricultural and orchard/vineyard work. It features a 4x4 MFWD chassis with power steering, making it easy to maneuver in tight spaces. The tractor is equipped with a shuttle/creeper transmission, offering 24 forward and 12 reverse gears for precise speed control during various tasks. Under the hood, the Rex 65 boasts a Perkins 903-27T engine. This 3-cylinder, turbocharged diesel engine is liquid-cooled and delivers 65 hp of power. While its 164.8 ci displacement is below average for tractors in its class, the engine's power output is about average. The tractor's compact size, measuring 142.9 inches long, 52.4 inches wide, and 98.4 inches tall, makes it ideal for working in orchards and vineyards. It comes with a category II three-point hitch for attaching various implements, and the comfortable cab provides protection from the elements during long workdays.
ManufacturerLandiniPower65 hp(48.5 kW)Class60–100 HP tractors →Engine3-cylinderTransmissionShuttle/Creeper
Key specifications
- Category
- Agricultural
- Engine power
- 65hp
- Transmission
- Shuttle/Creeper
Category comparison
Rex 65 compared with its category
vs. Agricultural medianDistribution
Engine Power (hp)
All recorded Agricultural tractors
65 hp · 16th
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The Rex 65 ranks at the 16th percentile for engine power among recorded agricultural tractors.
Overview
About the Landini Rex 65
The Landini Rex 65 is a versatile tractor designed for both agricultural and orchard/vineyard work. It features a 4x4 MFWD chassis with power steering, making it easy to maneuver in tight spaces. The tractor is equipped with a shuttle/creeper transmission, offering 24 forward and 12 reverse gears for precise speed control during various tasks. Under the hood, the Rex 65 boasts a Perkins 903-27T engine. This 3-cylinder, turbocharged diesel engine is liquid-cooled and delivers 65 hp of power. While its 164.8 ci displacement is below average for tractors in its class, the engine's power output is about average. The tractor's compact size, measuring 142.9 inches long, 52.4 inches wide, and 98.4 inches tall, makes it ideal for working in orchards and vineyards. It comes with a category II three-point hitch for attaching various implements, and the comfortable cab provides protection from the elements during long workdays.
Full specifications
Recorded specifications
General
| Manufacturer | Landini |
|---|---|
| Model | Rex 65 |
| Category | Agricultural tractor |
| Type | 4x4 MFWD 4WD |
Engine
| Make | Perkins |
|---|---|
| Model | 903-27T |
| Power | 65hp(48.47 kW) |
| Cylinders | 3 |
| Displacement | 164.8ci(2.7 L) |
| Bore | 3.74in(95 mm) |
| Stroke | 5in(127 mm) |
Transmission
| Type | Shuttle/Creeper |
|---|---|
| Forward gears | 24 |
| Reverse gears | 12 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
| Cab | Cab |
Dimensions
| Length | 142.9in(3,630 mm) |
|---|---|
| Width | 52.4in(1,331 mm) |
| Height | 98.4in(2,499 mm) |
Closest alternatives
Rex 65 compared with the nearest models by horsepower
Among agricultural tractors, the Landini 6530F and the Landini 6560F are closest to the Landini Rex 65 in rated horsepower. The Landini 6530F matches it on rated power. The Landini 6560F matches it on rated power.
| Spec | Landini Rex 65 | Landini 6530F | Landini 6560F |
|---|---|---|---|
| Engine power | 65 hp48.5 kW | 65 hp48.5 kW | 65 hp48.5 kW |
| Displacement | 164.8 ci2.7 L | 236 ci3.87 L | 236 ci3.87 L |
| Cylinders | 3 | 4 | 4 |
| Transmission | Shuttle/Creeper | Syncromesh | Syncromesh |
| Drive | 4WD | 2WD | 2WD |
Calculators
Calculators for the Rex 65
PTO power
About 54 to 59 PTO hp
Estimated from the 65 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 65 hp tractor can run
Maximum size is about a 7.5 ft rotary cutter or a 6.5 ft tiller. The calculator also sizes discs, plows and balers.
Units
65 hp is 48.5 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
Rex 65 vs. Agricultural median
Landini Rex 65 compared with other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 65 hp | 110 hp | -41% | 16th |
| Engine Displacement | 165 ci | 336 ci | -51% | 8th |
| Cylinders | 3 | 5.5 | -45% | 8th |
| Forward Gears | 24 | 16 | +50% | 81st |
| Length | 143 in | 173 in | -17% | 22nd |
| Width | 52.4 in | 79.5 in | -34% | 15th |
| Height | 98.4 in | 111 in | -11% | 27th |
Medians and percentiles are calculated from the agricultural tractors in the database that have a recorded value for each specification (sample size 497–1,130 models).
Same manufacturer
Other Landini models
Other manufacturers
Models with similar horsepower
Gallery
Landini Rex 65 photos
FAQ
Frequently asked questions
How powerful is the Landini Rex 65?
The Landini Rex 65 has an engine power output of 65 hp. It is powered by a 3-cylinder engine displacing 164.8 ci.
What hitch category is the Landini Rex 65?
The Landini Rex 65 uses a Category II hitch.
What type of transmission does the Landini Rex 65 have?
The Landini Rex 65 uses a Shuttle/Creeper transmission offering 24 forward gears.
What routine service does the Landini Rex 65 need?
Regular maintenance for the Landini Rex 65 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
