Shibaura SD4000
The Shibaura SD4000 is a utility tractor built for everyday farm work. It has a 2WD drive system and a gear transmission with 24 forward and 8 reverse speeds. This gives the driver lots of options for different tasks. The tractor is powered by a Shibaura LEP854A diesel engine with 4 cylinders. It's liquid-cooled and puts out 38.9 hp at 2400 rpm, which is average power for its class. This tractor is compact but sturdy. It measures 132.7 inches long, 59.8 inches wide, and 76.2 inches tall. It weighs 3377 pounds, making it lighter than many other utility tractors. The SD4000 has agricultural tires on both front and back, and a Category I hitch at the rear for attaching implements. It also has an open center hydraulic system and an electric starter. The engine size is below average for tractors, but it should be enough for most small to medium farm jobs.
ManufacturerShibauraPower38.9 hpEngine4-cylTransGear
Quick specs
- Category
- Utility
- Engine Power Output
- 39hp
- Operating Weight
- 3,377 lb
- Transmission
- Gear
At a glance
How the SD4000 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
38.9 hp · 32nd
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The SD4000 ranks at the 32nd percentile for engine power among recorded utility tractors.
Overview
About the Shibaura SD4000
The Shibaura SD4000 is a utility tractor built for everyday farm work. It has a 2WD drive system and a gear transmission with 24 forward and 8 reverse speeds. This gives the driver lots of options for different tasks. The tractor is powered by a Shibaura LEP854A diesel engine with 4 cylinders. It's liquid-cooled and puts out 38.9 hp at 2400 rpm, which is average power for its class. This tractor is compact but sturdy. It measures 132.7 inches long, 59.8 inches wide, and 76.2 inches tall. It weighs 3377 pounds, making it lighter than many other utility tractors. The SD4000 has agricultural tires on both front and back, and a Category I hitch at the rear for attaching implements. It also has an open center hydraulic system and an electric starter. The engine size is below average for tractors, but it should be enough for most small to medium farm jobs.
Full specifications
Every recorded spec
General
| Manufacturer | Shibaura |
|---|---|
| Model | SD4000 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Operating weight | 3,377lb |
Engine
| Make | Shibaura |
|---|---|
| Model | LEP854A |
| Power | 38.9hp |
| Cylinders | 4 |
| Displacement | 122ci |
| Bore | 3.35in |
| Stroke | 3.7in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 24 |
| Reverse gears | 8 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 132.7in |
|---|---|
| Width | 59.8in |
| Height | 76.2in |
| Operating weight | 3,377lb |
Head to head
SD4000 vs. Utility median
How the Shibaura SD4000 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 38.9 hp | 55 hp | -29% | 32nd |
| Engine Displacement | 122 ci | 183 ci | -33% | 29th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 24 | 12 | +100% | 92nd |
| Operating Weight | 3,377 lb | 5,303 lb | -36% | 28th |
| Length | 133 in | 137 in | -3% | 44th |
| Width | 59.8 in | 66 in | -9% | 36th |
| Height | 76.2 in | 94.1 in | -19% | 22nd |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Shibaura tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Shibaura SE4000 | 40 hp | 3,075 lb | — | Compare → |
| Shibaura SE4040 | 40 hp | 3,075 lb | — | Compare → |
| Shibaura ST440 | 40 hp | 3,219 lb | — | Compare → |
| Shibaura SD4340 | 43 hp | 3,600 lb | — | Compare → |
| Shibaura ST333 | 33 hp | 2,458 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Antonio Carraro Tigre 4000F | 38 hp | 2,756 lb | — | Compare → |
| Antonio Carraro TTR 4400 | 38 hp | 2,811 lb | — | Compare → |
| Advance-Rumely OilPull K 12/20 | 40 hp | 6,430 lb | — | Compare → |
| Allis Chalmers 160 | 40 hp | 4,674 lb | 1970–1975 | Compare → |
| Allis Chalmers 5040 | 40 hp | 3,858 lb | 1976–1980 | Compare → |
Explore
Shibaura siblings
Explore
Similar-spec models
Gallery
Shibaura SD4000 photos
FAQ
Common questions
What is the engine power output of the Shibaura SD4000?
Rated engine output for the Shibaura SD4000 is 38.9 hp, delivered by a 4-cylinder engine. The engine displaces 122 ci.
Which transmission does the Shibaura SD4000 use?
The Shibaura SD4000 is equipped with a Gear transmission with 24 forward gears.
What type of hydraulic system does the Shibaura SD4000 use?
Hydraulics on the Shibaura SD4000 are Open center.
What is the operating weight of the Shibaura SD4000?
In working trim, the Shibaura SD4000 comes in at roughly 3,377 lb.
How do I maintain a Shibaura SD4000?
Routine service for the Shibaura SD4000 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
