UtilityPerformance profile
CaseIH Puma 115
The CaseIH Puma 115 is a powerful utility tractor built for tough farm work. It has a strong 6-cylinder diesel engine that makes 115 horsepower. This engine is very big for its class, with 411 cubic inches of displacement. The tractor is also quite heavy, weighing 13,230 pounds, which helps it handle big jobs. This Puma model has four-wheel drive and hydrostatic power steering, making it easy to control in different conditions. It has an 18-speed transmission with 6 reverse gears, giving the driver lots of options. The hydraulic system is advanced, using a closed center design that saves fuel. For safety, it has wet disc brakes that work well even in muddy conditions. The tractor also has a 12-volt electrical system and an air-cooled engine for better performance.
ManufacturerCaseIHPower115 hpEngine6-cylTrans18-speed partial power shift
Quick specs
- Category
- Utility
- Engine Power Output
- 115hp
- Operating Weight
- 13,230 lb
- Transmission
- 18-speed partial power shift
At a glance
How the Puma 115 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
115 hp · 88th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The Puma 115 ranks at the 88th percentile for engine power among recorded utility tractors.
Overview
About the CaseIH Puma 115
The CaseIH Puma 115 is a powerful utility tractor built for tough farm work. It has a strong 6-cylinder diesel engine that makes 115 horsepower. This engine is very big for its class, with 411 cubic inches of displacement. The tractor is also quite heavy, weighing 13,230 pounds, which helps it handle big jobs. This Puma model has four-wheel drive and hydrostatic power steering, making it easy to control in different conditions. It has an 18-speed transmission with 6 reverse gears, giving the driver lots of options. The hydraulic system is advanced, using a closed center design that saves fuel. For safety, it has wet disc brakes that work well even in muddy conditions. The tractor also has a 12-volt electrical system and an air-cooled engine for better performance.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | Puma 115 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 13,230lb |
Engine
| Make | CNH |
|---|---|
| Power | 115hp |
| Cylinders | 6 |
| Displacement | 411ci |
| Bore | 4.09in |
| Stroke | 5.2in |
Transmission
| Type | 18-speed partial power shift |
|---|---|
| Forward gears | 18 |
| Reverse gears | 6 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic Power |
| Brakes | Hydraulic wet disc |
Hydraulics
| Type | Closed center pressure flow compensated (PFC) |
|---|
Dimensions
| Height | 118.3in |
|---|---|
| Operating weight | 13,230lb |
Head to head
Puma 115 vs. Utility median
How the CaseIH Puma 115 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 115 hp | 55 hp | +109% | 88th |
| Engine Displacement | 411 ci | 183 ci | +124% | 91st |
| Cylinders | 6 | 4 | +50% | 93rd |
| Forward Gears | 18 | 12 | +50% | 83rd |
| Operating Weight | 13,230 lb | 5,303 lb | +149% | 92nd |
| Height | 118 in | 94.1 in | +26% | 94th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 4,321–5,720 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH MXU115 Value | 116 hp | — | — | Compare → |
| CaseIH Farmall 120U | 117 hp | 10,031 lb | — | Compare → |
| CaseIH Luxxum 120 | 117 hp | 9,678 lb | — | Compare → |
| CaseIH 5250 Maxxum | 112 hp | 9,810 lb | 1992–1997 | Compare → |
| CaseIH Farmall 105A | 112 hp | 7,304 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Belarus 1025 MIG | 115 hp | 9,469 lb | — | Compare → |
| AGCO RT110A | 116.9 hp | 12,200 lb | — | Compare → |
| Allis Chalmers 7000 | 117 hp | 9,550 lb | 1975–1979 | Compare → |
| Agco LT95A | 111.6 hp | 11,070 lb | — | Compare → |
| Allis Chalmers 8010 | 119 hp | 12,630 lb | 1982–1985 | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH Puma 115 photos
FAQ
Common questions
How much horsepower does the CaseIH Puma 115 have?
The CaseIH Puma 115 produces 115 hp from its 6-cylinder engine. Engine displacement is 411 ci.
How much does the CaseIH Puma 115 weigh?
The CaseIH Puma 115 weighs about 13,230 lb in operating condition.
What transmission is in the CaseIH Puma 115?
Transmission on the CaseIH Puma 115 is 18-speed partial power shift, with 18 forward speeds.
What type of hydraulic system does the CaseIH Puma 115 use?
Hydraulics on the CaseIH Puma 115 are Closed center pressure flow compensated (PFC).
What maintenance does the CaseIH Puma 115 require?
Like any tractor, the CaseIH Puma 115 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
