Sub-CompactPerformance profile

Yanmar EF230H

The Yanmar EF230H is a compact but powerful 4-wheel drive tractor. It's built for farmers who need a strong machine for various tasks. This tractor has a 3-cylinder diesel engine made by Yanmar. The engine is naturally aspirated and produces 29.5 horsepower at 2600 RPM. One of the EF230H's best features is its hydrostatic transmission. This means it has smooth, easy-to-control speed changes in both forward and reverse. The tractor is 115 inches long, 51.8 inches wide, and 78.7 inches tall. It weighs 2436.2 pounds, making it sturdy but not too heavy. The EF230H has agricultural tires and a Category 1 hitch at the rear for attaching tools. It also has a 63-inch wheelbase, which helps it stay stable during work.

ManufacturerYanmarPower29.5 hpEngine3-cylTransHydrostatic
Jump to specs ↓Compare →
Yanmar EF230H
Jump to Full Specifications List

Quick specs

Category
Sub-Compact
Engine Power Output
30hp
Operating Weight
2,436.2 lb
Transmission
Hydrostatic
Compare this model

At a glance

How the EF230H compares

vs. Sub-Compact median

Distribution

Engine Power (hp)

Across all Sub-Compact tractors

29.5 hp · 55th

This model

4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816

The EF230H ranks at the 55th percentile for engine power among recorded sub-compact tractors.

Overview

About the Yanmar EF230H

The Yanmar EF230H is a compact but powerful 4-wheel drive tractor. It's built for farmers who need a strong machine for various tasks. This tractor has a 3-cylinder diesel engine made by Yanmar. The engine is naturally aspirated and produces 29.5 horsepower at 2600 RPM. One of the EF230H's best features is its hydrostatic transmission. This means it has smooth, easy-to-control speed changes in both forward and reverse. The tractor is 115 inches long, 51.8 inches wide, and 78.7 inches tall. It weighs 2436.2 pounds, making it sturdy but not too heavy. The EF230H has agricultural tires and a Category 1 hitch at the rear for attaching tools. It also has a 63-inch wheelbase, which helps it stay stable during work.

Full specifications

Every recorded spec

General

ManufacturerYanmar
ModelEF230H
CategorySub-Compact tractor
Type4x4 MFWD 4WD
Operating weight2,436.2lb

Engine

MakeYanmar
Model3TNV84
Power29.5hp
Cylinders3
Displacement91.3ci

Transmission

TypeHydrostatic

Chassis & drive

Chassis4x4 MFWD 4WD
Drive4WD

Dimensions

Length115in
Width51.8in
Height78.7in
Operating weight2,436.2lb

Head to head

EF230H vs. Sub-Compact median

How the Yanmar EF230H compares to other Sub-Compact tractors

SpecThis modelSub-Compact medianDifferencePercentile
Engine Power29.5 hp26.9 hp+10%55th
Engine Displacement91.3 ci91.4 ci0%49th
Cylinders33at median50th
Operating Weight2,436 lb2,700 lb-10%45th
Length115 in113 in+1%52nd
Width51.8 in50.7 in+2%52nd
Height78.7 in78.4 in0%51st

Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 584–816 models).

Explore

Yanmar siblings

All Yanmar models →

Explore

Similar-spec models

FAQ

Common questions

How much horsepower does the Yanmar EF230H have?

The Yanmar EF230H produces 29.5 hp from its 3-cylinder engine. Engine displacement is 91.3 ci.

How much does the Yanmar EF230H weigh?

The Yanmar EF230H weighs about 2,436.2 lb in operating condition.

What transmission is in the Yanmar EF230H?

Transmission on the Yanmar EF230H is Hydrostatic.

What hitch category is the Yanmar EF230H?

The Yanmar EF230H uses a Category Category 1 hitch.

What maintenance does the Yanmar EF230H require?

Like any tractor, the Yanmar EF230H needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
